Figure 9-8 Http Authentication Page; Table 9-7 Http Authentication Page - Lantronix I/O 2100 User Manual

HTTP
Authentication
Page Settings
URI
Realm
AuthType
Username
Password
IntelliBox-I/O 2100 User Guide

Figure 9-8 HTTP Authentication Page

Table 9-7 HTTP Authentication Page

Description
Enter the Uniform Resource Identifier (URI) of the resource that will
participate in the authentication process. Default is /.
Enter the domain, or realm, used for HTTP operations. Default is
<config>.
Select an authorization type. Different types of authorization offer
varying levels of security. Choices are (from least to most secure):
None = no authentication necessary.
Basic = encodes passwords using Base64.
Digest = encodes passwords using MD5. (default)
SSL = page can only be accessed over SSL (no password).
SSL/Basic = page can only be accessed over SSL (encodes
passwords using Base64).
SSL/Digest = page can only be accessed over SSL (encodes
passwords using MD5).
SSL alone does not require a password, but all data transferred to and
from the HTTP Server is encrypted. There is no reason to create an
authentication directive using None, unless you want to override a
parent directive that uses some other AuthType. Multiple users can be
configured within a single authentication directive.
Enter the name of the user who will participate in the authentication.
Default is admin.
Enter the password that will be associated with the username. Default
is PASS.
9: Services Settings
89
