Modbus – Configuration Page
If you click Configuration at the top of one of the Modbus – Statistics page, the Modbus
Configuration page displays. Modbus Configuration enables you to add a Modbus
server.
The Modbus server, if enabled, is active on TCP port 502. You have the option of using
an additional port.
Modbus –
Configuration
Page Settings
TCP Server State
Additional TCP
Server Port
Response
Timeout
IntelliBox-I/O 2100 User Guide
7: Network, Serial Line, Tunnel, and Modbus Settings
Figure 7-13 Modbus – Configuration Page
Table 7-11 Modbus – Configuration Page
Description
Select whether to enable a second Modbus server to have access.
Choices are:
On = Modbus server is enabled. (default)
Off = Modbus server is disabled.
Enter the number of the TCP port on which the IntelliBox additional server
listens for connections.
Indicate the response timeout in milliseconds. Must be a minimum of 10
msec.
75
