XML Status Record:
Export System Status
Page Settings
Export to browser
Export to local file
Lines to Export
Groups to Export
IntelliBox-I/O 2100 User Guide
Figure 12-7 XML Status Record: Export System Status Page

Table 12-5 XML Status Record: Export System Status Page

Description
Select this option to export the XML status record to a web
browser.
Select this option to export the XML status record to a
filesystem. If you select this option, enter a file name for the
XML status record.
Check the instances to be exported in the event trak, line,
lpd, serial, tunnel and terminal groups.
Check the configuration groups that are to be exported into
the XML status record. If no groups are checked, all groups
will be exported.
12: Advanced Settings
