XML Configuration
Record: Export System
Configuration Page
Settings
Export to browser
Export to local file
Export secrets
Lines to Export
Groups to Export

XML Status Record: Export System Status

If you click XML Status Record at the top of an XML page, the XML Status Record:
Export System Status page displays. Here you can export the current system status in
XML format. The XML data can be exported to the browser window or to a file on the
filesystem.
IntelliBox-I/O 2100 User Guide

Table 12-4 Configuration Record: Export System Configuration Page

Description
Select this option to export the XCR data in the selected
fields to a web browser.
Select this option to export the XCR data to the
filesystem on the IntelliBox filesystem. If you select this
option, enter a file name for the XML configuration
record.
Check to export secrets when exporting and http
authentication uri groups, SSH and SSL certificates so
that the configuration may later be restored.
Check the instances to be exported in the event trak,
line, lpd, serial, tunnel and terminal groups.
Check the configuration groups that are to be exported
to the XML configuration record. If no groups are
checked, all groups will be exported.
12: Advanced Settings
131
