XML: Import
System
Configuration
Page Settings
Import >
Configuration from
External file
Import >
Configuration from
Filesystem
Import > Line(s) from
single line Settings
on the Filesystem
Groups and
Instances to Import
Whole Groups to
Import
IntelliBox-I/O 2100 User Guide

Table 12-6 XML: Import System Configuration Page

Description
Click the Configuration from External file radio button. Then, enter the
path and file name of the entire external XCR file you want to import or
use the Browse button to select the XCR file.
Click the Configuration from Filesystem radio button. Then, complete
the following fields:
Enter the Filename of the XCR file that has certain groups you want to
import.
Check the Lines to Import to indicate the instances to be imported in the
event trak, line, lpd, serial, tunnel and terminal groups.
Check or uncheck the Whole Groups to Import.
Enter content in the Text List.
Click the Import button.
Click the Line(s) from single line Settings on the Filesystem radio
button. Then, complete the following fields:
Enter the Filename of the XCR file that has certain groups you want to
import.
Check the Lines to Import to indicate the instances to be imported in the
event trak, line, lpd, serial, tunnel and terminal groups.
Check or uncheck the Whole Groups to Import.
Click the Import button.
If required, enter the filter string for importing specific instances of a
group.
Check the configuration groups that are to be imported into the XML
configuration record. If no groups are checked, all groups will be
imported.
12: Advanced Settings
134
