2
PANEL DESCRIPTION
t TIME ZONE INDICATOR
➥ Shows the current tme data when a GPS recever s
connected.
• "??" and the last receved tme data may blnk alternately
every 2 sec. nstead of current tme data when the GPS cur-
rent tme data s nvald.
• "??" and the last receved tme data may blnk alternately
every 2 sec. nstead of current tme data 4 hours after the
tme data s nput manually, up untl 23.5 hours have past.
➥ "No Time" appears when no GPS recever s con-
nected and no tme data s nput manually.
➥ " " appears when a GPS recever s connected.
y POSITION INDICATOR
➥ Shows the GPS poston data.
• "??" and the last receved poston data may blnk alternately
every 2 sec. nstead of poston data when the GPS poston
data s nvald. In such a case, the last poston data s held
for up to 23.5 hours.
• "??" and the last receved poston data may blnk alternately
every 2 sec. nstead of poston data 4 hours after the pos-
ton data s nput manually, up untl 23.5 hours have past.
➥ "No Position" appears when no GPS recever s
connected and no poston data s nput manually.
u SCAN INDICATOR
➥ "PRI-SCAN 16" appears durng Prorty scan;
"NORMAL SCAN" appears durng Normal scan.
(p. 16)
➥ "DUAL 16" appears durng Dualwatch; "TRI 16" ap-
pears durng Tr-watch. (p. 14)
6
i TAG CHANNEL INDICATOR (p. 16)
Appears when a TAG channel s selected.
o BUSY/TRANSMIT INDICATOR
➥ "BUSY" appears when recevng a sgnal or when the
squelch opens. (p. 8)
➥ "TX" appears whle transmttng. (p. 9)
!0 POWER INDICATOR (p. 8)
➥ "25W" appears when hgh power s selected.
➥ "1W" appears when low power s selected.
!1 DUPLEX INDICATOR (p. 8)
Appears when a duplex channel s selected.
!2 CHANNEL GROUP INDICATOR (p. 8)
Indcates when an Internatonal "INT" channel s n use.
(Depends on verson)
