CONNECTIONS AND MAINTENANCE
n Mounting the transceiver

D Using the supplied mounting bracket

The unversal mountng bracket suppled wth your trans-
cever allows overhead or onboard mountng.
• Mount the transcever securely wth the 4 suppled screws
(M5 × 20) to a surface whch s more than 10 mm thck and
can support more than 5 kg.
• Mount the transcever so that the face of the transcever s
at 90° to your lne of sght when operatng t.
CAUTION: KEEP the transcever and mcrophone at least
1 meter away from your vessel's magnetc navgaton
compass.
NOTE:
• Check the nstallaton angle; the functon dsplay may
not be easy-to-read at some angles.
• When mountng the transcever on the place that s
prone to strong vbraton, use the suppled sponges be-
tween the transcever and mountng bracket for reducng
the effect of the vbraton.
114
• OVERHEAD MOUNTING
Sponge*
* Sponges reduce the
vibration effects.
See NOTE at left.
• MOUNTING ON THE BOARD
Sponge*
These screws are shown
a mounting example only.
Not supplied with acces-
sories.
