12
CONNECTION AND INSTALLATION

I Advanced connections

Position and
UTC time data
(NMEA0183)
CAUTION:
Any connected external unit, such as
PC, printer, etc., must be properly grounded. We
suggest using a wide copper strap. (p. 51)
➥ When a PC is connected, the PC being operated at
any given time has priority.
➥ When a PC is connected, the controller not being
operated is inhibited for a specified time after the PC
is operated. This time can be programmed by your
dealer. The default inhibit time is 5 sec.
➥ When a PC is connected, operating the PC auto-
matically updates settings on the controller.
50
Modem, NBDP (Narrow
Band Direct Printing),
FAX systems
12 V or 24 V
battery
Printer
(IBM ® centronics or compatible)
Personal
computer
