Summary of Contents for Icom IC-M87
- Page 1 INSTRUCTION MANUAL VHF MARINE TRANSCEIVER iM87...
- Page 2 FEATURES ☞ 22 free channels for PMR use Thank you for choosing this Icom product. This product is de- signed and built with Icom’s state of the art technology and The IC-M87 has 22 free channels reserved for PMR use craftsmanship.
- Page 3 3. Your call sign or other indication of the vessel. Contact your Icom distributor or your dealer for advice. 4. “LOCATED AT ...... ” (your position) 5. The nature of the distress and assistance re- quired.
- Page 4 –15°C or above with non-Icom transceivers or non-Icom chargers. Only Icom +55°C: Marine, below –25°C or above +55°C: PMR. battery packs are tested and approved for use with Icom CAUTION: DO NOT modify the transceiver. The specifications transceivers or charged with Icom chargers.
- Page 5 • The use of Icom transceiver with any equipment that is not manufactured or approved by Icom. Icom, Icom Inc. and Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, United Kingdom, Germany, France, Spain, Russia, Australia, New Zealand, and/or other countries.
- Page 6 MAY BE PRESENT. • DO NOT CHARGE THE BATTERY IN HAZARDOUS Repair of Icom transceivers should only be carried out by LOCATION. authorized Icom distributors. In particular, repair of ATEX ap-...
- Page 7 DISPOSAL Hereby, Icom Inc. declares that the versions The crossed-out wheeled-bin symbol on your of IC-M87 which have the “CE” symbol on the product, literature, or packaging reminds you that product, comply with the essential requirements in the European Union, all electrical and...
- Page 8 TABLE OF CONTENTS PREFACE ................i 6 DUALWATCH/TRI-WATCH ..........15 ■ Description ..............15 IMPORTANT ................i ■ Operation..............15 EXPLICIT DEFINITIONS ............i FEATURES ................i 7 LAND (PMR) CHANNEL OPERATION ......16 IN CASE OF EMERGENCY ..........ii ■ LAND (PMR) Channel group ........16 RECOMMENDATION ............
- Page 9 OPERATING RULES D Priorities (2) OPERATOR’S LICENSE A restricted Radiotelephone Operator Permit is the license • Read all rules and regulations pertaining to priorities and most often held by small vessel radio operators when a radio keep an up-to-date copy handy. Safety and distress calls is not required for safety purposes.
- Page 10 SUPPLIED ACCESSORIES AND ATTACHMENTS Supplied accessories w Clip the belt clip to a part of your belt and insert the stop- per to the belt clip. The following accessories are supplied: Qty. • Swivel belt clip ....... . . 1 •...
- Page 11 SUPPLIED ACCESSORIES AND ATTACHMENTS D Flexible antenna To remove: Turn the transceiver upside down, and then lift up to release Connect the supplied flexible antenna the transceiver from the belt clip. to the antenna connector. CAUTION: • NEVER carry the transceiver by holding the antenna.
- Page 12 PANEL DESCRIPTION ■ Front, top and side panels q VOLUME CONTROL [VOL] Turns power ON and adjusts the audio level. w ANTENNA CONNECTOR (p. 3) Connects the supplied antenna. e SPEAKER-MICROPHONE CONNECTOR [SP MIC] (p. 28) Connects the optional speaker-microphone. [SP MIC] jack cover NOTE: KEEP the [SP MIC] jack cover attached to the...
- Page 13 A-6409H-1EU-12 Printed in Japan © 2005–2018 Icom Inc. 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan Printed on recycled paper with soy ink.
