CPU Frequency and Host Bus Frequency
The following table shows the jumper settings for the CPU frequency and its corresponding host bus
frequency. IN denotes the jumper is installed on both pins.
CPU Frequency Jumper
J48
J47
J50
J49
Host Bus Frequency Jumper
J23
J24
J33
J34
CPU Voltage
The 200 MHz CPU uses a clock voltage of 3.3 volts, and the 266 MHz and 300 MHz CPU use a clock
voltage of 2.5 volts.
WARNING Double-check voltage jumper settings before starting the system! Setting a high voltage for a
266 MHz or 300 MHz processor will destroy the processor.
The following table shows voltage jumper settings. IN denotes the jumper is installed on both pins.
Jumper
J19
J39
BIOS Password Clear
J16 on the system board (near the parallel port) enables or disables the BIOS password stored in
CMOS RAM. By default, the jumper is not installed, and the password (if present) is enabled. If the
jumper is installed, the password is cleared, allowing the AMIBIOS Setup program to be accessed
without entering a password. You may need to remove the PCI option boards (if installed) to access
J16.

Cable Routing and Pinouts

From
J12, Fan Power
J17, MIDI
J22, Audio
J22, Audio
J30, Floppy
J32, Primary EIDE
200 MHz
OUT
IN
IN
IN
66 MHz
IN
IN
200 MHz/3.3v 266 MHz/2.5v
IN OUT
OUT IN
Cable
MCBLZ660
MCBL038A
MCBLZ630
MCBL122A
MCBLZ380
MCBL121
233 MHz 266 MHz
OUT IN
IN OUT
OUT IN
IN IN
66 MHz 66 MHz
IN IN
IN IN
300 MHz/2.5v
OUT
IN
To
Internal bay disk drive fan
External MIDI port
SCSI CD-ROM drive
EIDE CD-ROM drive
Floppy disk drive
EIDE CD-ROM drive
55
300 MHz
IN
OUT
OUT
IN
60 MHz
IN
IN
