DV CAMCORDER
GY-DV700W
* The illustration shows the GY-DV700W DV Camcorder with the optional lens viewfinder attached.
Thank you for purchasing this JVC product. Before operating
this unit, please read the instructions carefully to ensure the
best possible performance.
For Customer Use :
Enter below the Serial No. which is located on the body.
Retain this information for future reference.
Model No. GY-DV700W
Serial No.
INSTRUCTIONS
yyy
yyy
This instruction manual is made from 100% recycled paper.
INTRODUCTION
CONTROLS,
INDICATORS AND
CONNECTORS
BASIC SYSTEM
CONNECTIONS AND
ADJUSTMENTS
POWER SUPPLY
PREPARATIONS
SETTING AND
ADJUSTMENTS
BEFORE SHOOTING
SHOOTING
OPERATION
PLAYBACK MODE
TIME CODE
OPERATION
S.S.F. (Super Scene
Finder)
USING EXTERNAL
COMPONENTS
SETUP MENU
FEATURES OF THE
CAMERA SECTION
OTHERS
SC96991-001
Advertisement
Table of Contents
Related Manuals for JVC GY-DV700WUCL - Cineline Dv Camcorder
Summary of Contents for JVC GY-DV700WUCL - Cineline Dv Camcorder
- Page 1 CAMERA SECTION OTHERS * The illustration shows the GY-DV700W DV Camcorder with the optional lens viewfinder attached. Thank you for purchasing this JVC product. Before operating this unit, please read the instructions carefully to ensure the best possible performance. For Customer Use : Enter below the Serial No.
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS 1. Read all of these instructions. 2. Save these instructions for later use. 3. All warnings on the product and in the operating instructions should be adhered to. 4. Unplug this appliance system from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. -
Page 3: Safety Precautions
The battery used in this device may present a fire or chemical burn CAUTION hazard if mistreated. Do not recharge, disassemble, heat avobe 100 C CHANGES OR MODIFICATIONS NOT APPROVED BY JVC (212 F) or incinerate. COULD VOID USER’S AUTHORITY TO OPERATE THE Replace battery with Matsushita Electric CR2032, use of another EQUIPMENT. -
Page 4: Main Features
(including another GY-DV700W) are Other use may infringe on the rights of copyright holders. ● JVC cannot assume liabilities that may derive from the recorded or played back on this camcorder. ● The transient section between scenes recorded on other... -
Page 5: Table Of Contents
CONTENTS INTRODUCTION BASIC OPERATIONS MAIN FEATURES ............... 4 5. PREPARATIONS Turning the Power ON ..........39 1. INTRODUCTION Cassette Loading and Unloading ......40 Main Unit Configuration ..........6 Setting the Date and Time ........41 Precautions for Proper Use ........7 Routine and Periodical Maintenance ...... -
Page 6: Introduction
1. INTRODUCTION 1. INTRODUCTION 1-1 Main Unit Configuration 11. USING EXTERNAL COMPONENTS The GY-DV700W configuration is as shown below. 11-1 Connecting a Video Component with DV Connector 64 11-2 Connecting a PC ............65 12. SETUP MENU 12-1 VCR Setup Menu ............. 66 •... -
Page 7: Precautions For Proper Use
(inspection) to prevent troubles that may be caused by the sudden occurrence of failure. As the replacement, adjustment and servicing of parts require advanced skill and equipment, please consult the person in charge of professional video equipment at your nearest JVC-authorized service agent. -
Page 8: Precautions For Use Of Head Cleaning Tape
• or cost, please contact the person in charge of professional ● If this kind of indication appears, please stop the recording. video equipment at your nearest JVC-authorized service Head cleaning is required. This indicator disappears when agent. the POWER is turned OFF, or when the cleaning tape is played back. -
Page 9: Videocassette To Be Used
1. INTRODUCTION 1-5 Videocassette to be Used ● Use JVC’s videocassette tapes marked with MiniDV for ● Videocassette tapes marked MiniDV are provided with this unit. a switch on the back for use in preventing accidental Please use DVM60 or DVM30 type videocassettes. -
Page 10: Controls, Indicators And Connectors
2. CONTROLS, INDICATORS AND CONNECTORS 2-1 Front Section [LENS] Lens control connector Connect 12-pin lens control cable from lens. Pin No. Function Pin No. Function RET switch IRIS position VCR trigger IRIS A/R INPUT EXTENDER position Lens AUTO/MANU control ZOOM position IRIS control —... - Page 11 2. CONTROLS, INDICATORS AND CONNECTORS 2-1 Front Section (Cont’d) CAUTION: • As the automatic shutter is activated here, flicker may appear on the screen depending on the lighting conditions (such as a fluorescent lamp, etc.) • This operation is not possible in the LOLUX mode. [TAKE] button The Super Scene Finder (S.S.F.) function retains the time code data for IN point and OUT point or CUE point in the...
-
Page 12: Right Side Section
2. CONTROLS, INDICATORS AND CONNECTORS 2-2 Right Side Section [Camera Setting Section] OPERATE/WARNING RESET MONITOR SELECT FILTER 1 3200k ALARM 2 5600k+1/8ND 3 5600k 4 5600k+1/64ND SHUTTER STATUS MONITOR MENU CH-1 AUDIO CH-2 LEVEL AUTO IRIS FULL AUTO BLACK LOLUX BACK L STRETCH NORMAL... - Page 13 2. CONTROLS, INDICATORS AND CONNECTORS 2-2 Right Side Section [Camera Setting Section] When the AUTO KNEE function is OFF, the point where [AUTO IRIS] Auto iris level switch the KNEE function takes effect (knee point) can be set using This switch selects the automatic iris adjustment KNEE POINT in PROCESS MENU SCREEN.
- Page 14 2. CONTROLS, INDICATORS AND CONNECTORS 2-2 Right Side Section (Cont'd) [Audio Setting Section] OPERATE/WARNING LIGHT RESET AUTO MONITOR MANUAL FILTER SELECT COUNTER AUDIO SELECT 1 3200k ALARM 2 5600k+1/8ND AUDIO INPUT 3 5600k CH-1 CH-2 4 5600k+1/64ND AUDIO CH-1 CH-2 FRONT SHUTTER STATUS...
- Page 15 2. CONTROLS, INDICATORS AND CONNECTORS 2-2 Right Side Section (Cont'd) [VCR Setup Block] CH-1 AUDIO CH-2 TC GENERATOR LEVEL CH-1 CH-2 OPERATE/WARNING PRESET FREE AUTO LIGHT REGEN MANUAL RESET AUDIO SELECT MONITOR AUDIO INPUT FILTER SELECT COUNTER 1 3200k ALARM CH-1 CH-2 CONTINUE...
- Page 16 2. CONTROLS, INDICATORS AND CONNECTORS 2-2 Right Side Section (Cont'd) [VCR Display Section] CH 1 AUTO OFF DEW OVER 40 30 0 dB OPERATE/WARNING LIGHT SERVO CH 2 OVER RESET MONITOR SLAVE HOLD FILTER SELECT COUNTER 1 3200k ALARM 2 5600k+1/8ND AUD LOCK 3 5600k 4 5600k+1/64ND...
- Page 17 2. CONTROLS, INDICATORS AND CONNECTORS 2-2 Right Side Section (Cont'd) & Warning indicators Tape transport direction indicators [AUTO OFF] indicator One of the indicators lights according to the REV FWD Lights when a non-recoverable error (e.g. tape winding tape transport direction. error, drum stopped, etc.) occurs with the unit.
-
Page 18: Left Side Section
SELECT must be set to "RS232C". Setup Menu item No. 403 U-BIT SLAVE to “TC&UB”. For details, please consult your JVC dealer. * When the REC/FREE switch (8 on page 15) is set to REC, or the VCR Setup Menu item No. 398 SSF MODE Note: is set to “CUE MODE”... -
Page 19: Top Section
2. CONTROLS, INDICATORS AND CONNECTORS 2-4 Top Section EJECT PUSH OPEN STOP PLAY STILL i y r u e t [EJECT] switch [REW] button Slide to the side when inserting or ejecting the Press to rewind the tape. videocassette. Sliding this switch opens the cassette cover. •... -
Page 20: Rear Section
2. CONTROLS, INDICATORS AND CONNECTORS 2-5 Rear Section PUSH DV CAMCORDER GY-DV700 Y/C OUT MONITOR OUT LINE OUT SYNC IN TEST OUTPUT CH-1 CH-2 CH-1 AUDIO IN CH-2 TALLY EARPHONE LINE LINE REMOTE +48V +48V DC INPUT TC IN TC OUT DC OUTPUT BREAKER Bottom side... - Page 21 It blinks during the transition to the record mode. nearest JVC-authorized service agent. • Use the VCR Setup Menu item No. 082 BACK TALLY MODE to select whether or not the lamp should light and the lighting pattern.
-
Page 22: Counter Display Contents
2. CONTROLS, INDICATORS AND CONNECTORS 2-6 Counter Display Contents The counter display shows the following 4 types of information. OPERATE/WARNING LIGHT CH 1 AUTO OFF DEW OVER Tape counter display RESET 40 30 0 dB CH 2 SERVO OVER The counter display usually functions as a tape counter SLAVE HOLD AUD LOCK... -
Page 23: Lens (Optional)
2. CONTROLS, INDICATORS AND CONNECTORS 2-7 Lens (optional) 8.7BW To adjust the focus of the macro image, rotate this ring in the direction of arrow until the object is focused. Note : The back-focus knob is located close to the macro ring, be careful not to mistake the back-focus knob for the macro ring. -
Page 24: Inch Viewfinder (Optional)
2. CONTROLS, INDICATORS AND CONNECTORS 2-8 1.5-Inch Viewfinder (optional) VF-P116W Eyepiece Blocks light to viewfinder screen and holds eye optics. The Eyepiece can be opened to view the screen directly. Eyepiece focusing ring Rotate this ring to adjust the viewing angle. Be sure to adjust this ring because the viewing angle af- fects the lens focus adjustment. -
Page 25: Indications In Viewfinder
2. CONTROLS, INDICATORS AND CONNECTORS 2-9 Indications in Viewfinder WARNING LED INDICATORS INSIDE THE VIEWFINDER The viewfinder has two LED indicators below the screen. These LEDs light or blink to indicate the present status of the camera or the VCR. ●... - Page 26 2. CONTROLS, INDICATORS AND CONNECTORS 2-9 Indications in Viewfinder (Cont'd) ACCU - FOCUS ACCU - FOCUS SCENE F I L E WH I TE BA L F I L TER 3 . 2 K SHUT TER 1 / 1 0 GA I N 6 d B I R I S L EVE L...
- Page 27 2. CONTROLS, INDICATORS AND CONNECTORS 2-9 Indications in Viewfinder (Cont'd) ● Status 1 In addition to the information on the Status 0 screen, this screen displays audio indicators and information on remaining tape, voltage and lens F-number. Function Display position Display Shows the input level of the audio input channel.
- Page 28 2-9 Indications in Viewfinder (Cont'd) Alarm Message Display ACCU - FOCUS Alarm message display The following alarm messages are displayed on the status 0 and status 1 screens. CH1 - - - - + - - F 5 . 6 CH2 - - - - + - - STBY <...
- Page 29 2-9 Indication in Viewfinder (Cont'd) Safety Zone Three types of safety zone items can be displayed in the viewfinder. Select the required one with the SAFETY ZONE item on the VF DISPLAY menu screen. The CENTER MARK item can be used to select whether the safety zone center mark indicator should be displayed or not (ON/OFF).
-
Page 30: Basic System Connections And Adjustments
3. BASIC SYSTEM CONNECTIONS AND ADJUSTMENTS 3-1 Basic System For information on connection with the individual attachments, refer to the page explaining the respective connection methods. MONITOR BATTERY NP-1B TYPE EARPHONE BATTERY CHARGER MICROPHONE MV-P615 BATTERY SHOULDER BELT NP-1B TYPE MIC HOLDER KA-A50 1.5"... -
Page 31: Attaching The Zoom Lens (Optional)
3. BASIC SYSTEM CONNECTIONS AND ADJUSTMENTS 3-2 Attaching the Zoom Lens (optional) Loosen the mount ring. Connect the cable connector. Attach the lens with its pin aligned with the hole in the mount. Tighten the mount ring. CAUTION: Be sure to tighten the mount ring completely. Incomplete tightening may result in the lens dropping off or disturbed back focus. -
Page 32: Attaching The Microphone (Provided)
3. BASIC SYSTEM CONNECTIONS AND ADJUSTMENTS 3-4 Attaching the Microphone (provided) Provided Microphone Connecting the provided microphone to the viewfinder. The provided microphone is a phantom microphone. 1.3. Loosen the stopper screw on the viewfinder. Attach the microphone to the attachment guide on the viewfinder as illustrated. -
Page 33: Attaching The Tripod Base (Provided)
3. BASIC SYSTEM CONNECTIONS AND ADJUSTMENTS 3-6 Attaching the Tripod Base (provided) Use the provided tripod base to place the camera on a tripod. Attach the tripod base on the tripod by using the hole that balances the unit most optimally. While pushing the safety lever, pull the lock lever toward Tripod mounting holes the front until the front mount clip clicks into place. -
Page 34: Inserting And Replacing Backup Lithium Batteries
3. BASIC SYSTEM CONNECTIONS AND ADJUSTMENTS 3-7 Inserting and Replacing Backup Lithium Batteries The GY-DV700W uses a lithium battery for backup of the time code data and time date data. Install the provided lithium battery before actually using the unit. ●... -
Page 35: Power Supply
The GY-DV700W is operable with AC power supply or battery pack. 4-1 AC Operation Use the JVC AA-P250 AC power adapter (max. rated output 12.5 V DC, 3.5 A) as the AC power supply. Do not use any power source with large fluctuations in the power source voltage, or power sources generating noise, such as ripples. -
Page 36: Attaching A Flat Shape Type Battery Pack
4. POWER SUPPLY 4-2 Battery Pack Operation (Cont'd) Attaching a Flat Shape Type Battery Pack Open the battery case cover while pushing the lock release lever. Insert the battery pack into the battery case with its electrodes facing the unit. Close the battery case cover. -
Page 37: Using An Anton-Bauer Battery Pack
4. POWER SUPPLY 4-2 Battery Pack Operation (Cont'd) Using an Anton-Bauer Battery Pack To use an Anton-Bauer battery pack (Propack 13/14, Trimpack 13/14, Magnum 13/14, Compack 13/14 Series), it is necessary to detach the battery case from the GY-DV700W and replace it with the Anton-Bauer battery holder. Use the following battery holder. •... -
Page 38: Remaining Battery Power Display/Precautions For The Battery Pack
4. POWER SUPPLY 4-2 Battery Pack Operation (Cont'd) REMAINING BATTERY POWER DISPLAY WARNING To display the remaining battery power accurately, set the indicator VCR Setup Menu item No. 396 BATTERY TYPE according Remaining battery to the type of the battery pack in use. power indication See page 22. -
Page 39: Preparations
5. PREPARATIONS 5-1 Turning the Power ON AUTO IRIS FULL AUTO BLACK LOLUX BACK L STRETCH NORMAL NORMAL SPOT L COMPRESS OPERATE/WARNING LIGHT RESET MONITOR FILTER SELECT COUNTER 1 3200k ALARM 2 5600k+1/8ND 3 5600k 4 5600k+1/64ND SHUTTER STATUS MONITOR MENU AUDIO CH-1... -
Page 40: Cassette Loading And Unloading
5. PREPARATIONS 5-2 Cassette Loading and UnLoading Cassette rear switch EJECT Videocassette EJECT switch STOP PLAY STILL POWER Cassette VTR switch POWER switch cover • A cassette cannot be loaded or unloaded while the GY-DV700W is in POWER OFF mode. •... -
Page 41: Setting The Date And Time
5. PREPARATIONS 5-3 Setting the Date and Time The date and time of the built-in clock should be set. During shooting, the date and time data are recorded in the sub-time code area on the tape. During playback, the data are shown on the counter display. Powered by the backup lithium battery, the set date and time data continue to count even when the power is switched off. -
Page 42: Setting And Adjustments Before Shooting
6. SETTING AND ADJUSTMENTS BEFORE SHOOTING 6-1 Camera Settings POWER ON 1 First place a charged battery pack in the battery case on the rear section of the unit. If battery pack is not used, connect DC power to the DC INPUT connector on the rear section of the unit using the AC power adapter (AA- OPER RESET... -
Page 43: Viewfinder Adjustment
6. SETTING AND ADJUSTMENTS BEFORE SHOOTING 6-2 Viewfinder Adjustment Visibility adjustment Visibility adjustment Rotate the eyepiece focusing ring so that the viewfinder screen image is clearly visible. Brightness and contrast adjustment When the ambient brightness changes, the brightness and contrast of the viewfinder screen can be adjusted with the CONT and BRIGHT controls. -
Page 44: Back Focus Adjustment
6. SETTING AND ADJUSTMENTS BEFORE SHOOTING 6-4 Back Focus Adjustment It is only necessary to perform this when the lens is attached for the first time or when focusing is not correct in both the telephoto and wide-angle positions. Adjust the viewfinder for sharpness first. -
Page 45: White Balance Adjustment
6. SETTING AND ADJUSTMENTS BEFORE SHOOTING 6-5 White Balance Adjustment Since the color of light (color temperature) varies depending on the light source, it is necessary to re-adjust the white balance when the main light source illuminating the subject changes. Note: When a subject illuminated by a halogen lamp with a color temperature of 3,200K is shot while the color temperature conversion filter setting is set to 5,600K, a proper white balance adjustment and (FAW) Full Time Auto White balance may not be... -
Page 46: Switch Settings Of The Vcr Section
6. SETTING AND ADJUSTMENTS BEFORE SHOOTING 6-6 Switch Settings of the VCR Section REC/FREE PRESET/REGEN switch switch OPERATE/WARNING CH-1 AUDIO CH-2 LIGHT TC GENERATOR RESET CH-1 CH-2 LEVEL MONITOR PRESET FREE AUTO FILTER SELECT COUNTER REGEN 1 3200k MANUAL ALARM 2 5600k+1/8ND 3 5600k AUDIO SELECT... -
Page 47: Audio Input Signal Selection
6. SETTING AND ADJUSTMENTS BEFORE SHOOTING 6-8 Audio Input Signal Selection OPERATE/WARNING LIGHT RESET MONITOR FILTER SELECT COUNTER 1 3200k ALARM 2 5600k+1/8ND 3 5600k 4 5600k+1/64ND SHUTTER STATUS MONITOR CH-1 AUDIO CH-2 AUDIO MENU CH-1 AUDIO CH-2 LINE/MIC LINE/MIC LEVEL AUTO IRIS FULL AUTO BLACK... -
Page 48: Audio Input Level Adjustment
6. SETTING AND ADJUSTMENTS BEFORE SHOOTING 6-9 Audio Input Level Adjustment CH-1 Audio CH-2 Audio select switch select switch OPERATE/WARNING LIGHT RESET AUTO MONITOR MANUAL FILTER COUNTER SELECT 1 3200k AUDIO SELECT ALARM 2 5600k+1/8ND 3 5600k AUDIO INPUT 4 5600k+1/64ND CH-1 CH-2 SHUTTER... -
Page 49: Monitoring Audio During Recording
6. SETTING AND ADJUSTMENTS BEFORE SHOOTING 6-10 Monitoring Audio during Recording OPERATE/WARNING LIGHT RESET MONITOR FILTER SELECT COUNTER 1 3200k ALARM 2 5600k+1/8ND 3 5600k 4 5600k+1/64ND SHUTTER STATUS MONITOR MENU CH-1 AUDIO CH-2 LEVEL AUTO IRIS FULL AUTO BLACK LOLUX BACK L STRETCH... -
Page 50: Shooting Operation
7. SHOOTING OPERATION 7-1 Basic Recording Operation Set the POWER switch to ON. “WIDE” “DEW” Power is supplied to the unit. CH 1 OVER AUTO OFF DEW Check that the condensation indicator "DEW" does not 40 30 0 dB SERVO CH 2 OVER appear on the display. - Page 51 7. SHOOTING OPERATION 7-1 Basic Recording Operation (Cont'd) 8. 9. 10. Press the VTR trigger button on the GY-DV700W or lens to start recording. VTR trigger button Once recording has started, the BACK TALLY lamp on the rear section of the unit and the tally lamp on the viewfinder light red, and the REC indication in the viewfinder lights green.
-
Page 52: Vcr Save Mode
7. SHOOTING OPERATION 7-2 VCR Save Mode When a recordable videocassette is loaded, the GY-DV700W enters the record-pause mode. However, the record-pause operation condition differs depending on the setting of the VTR OPERATE/WARNING LIGHT RESET MONITOR FILTER SELECT COUNTER switch. 1 3200k ALARM 2 5600k+1/8ND... -
Page 53: Checking Recorded Contents In Record-Pause Mode (Recording Check Function)
7. SHOOTING OPERATION 7-4 Checking Recorded Contents in Record-Pause Mode (Recording Check Function) The recording check function is only valid in the standby mode (VTR switch set to STBY). In the record-pause mode, approximately 2 seconds of the last recorded portion can be played back. RET button •... -
Page 54: Playback Mode
8. PLAYBACK MODE 8-1 Playback Procedure EJECT switch EJECT OPERATE/WARNING LIGHT RESET MONITOR FILTER SELECT COUNTER 1 3200k ALARM 2 5600k+1/8ND 3 5600k 4 5600k+1/64ND SHUTTER STATUS MONITOR STOP PLAY STILL MENU CH-1 AUDIO CH-2 LEVEL AUTO IRIS FULL AUTO BLACK LOLUX BACK L STRETCH... -
Page 55: Fast-Forward, Rewind
8. PLAYBACK MODE 8-2 Fast-Forward, Rewind REW button FF button OPERATE/WARNING LIGHT RESET MONITOR FILTER SELECT COUNTER 1 3200k ALARM 2 5600k+1/8ND STOP PLAY STILL 3 5600k 4 5600k+1/64ND SHUTTER STATUS MONITOR MENU CH-1 AUDIO CH-2 LEVEL AUTO IRIS FULL AUTO BLACK LOLUX BACK L STRETCH... -
Page 56: Time Code Operation
9. TIME CODE OPERATION The GY-DV700W records EBU-standard time codes and user's bits. In the play or record mode, the reproduced time codes or user's bits are shown on the counter display. The LTC signal from the built-in time code generator is output through the TC OUT connector. In the play mode, the time code recorded on the tape is not output through the units connectors. -
Page 57: Time Code Presetting Procedure
9. TIME CODE OPERATION TIME CODE PRESETTING PROCEDURE Display the time code on the counter display. HOLD button SHIFT button Set the COUNTER switch to "TC". • Time code up to 23 hrs. 59 min. 59 sec. 29 frames can be preset. -
Page 58: Recording Time Codes By Slave-Locking The Built-In Time Code Generator With External Tcg
9. TIME CODE OPERATION 9-3 Recording Time Codes by Slave-Locking the Built-in Time Code Generator with the External TCG The built-in time code generator can be synchronized (slave-locked) with the SMPTE-standard LTC time code signal which is input through the TC IN connector. Once the slave locking has been carried out, the built-in time code generator runs even when the external time code input stops. -
Page 59: Recording Time Codes In Continuation Of Time Codes Recorded On Tape
9. TIME CODE OPERATION 9-4 Recording Time Codes in Continuation of Time Codes Recorded on Tape The GY-DV700W also incorporates a time code reader. Therefore, when the unit enters record mode from record-pause mode, it can read the time code data recorded on the tape and record time codes in continuation of the existing data. The recorded user's bit data is identical to the user's bit data recorded on tape. -
Page 60: Super Scene Finder) Function
10. S.S.F. (Super Scene Finder) FUNCTION 10-1 Explanation of the S.S.F. Function During recording, the S.S.F. function records the time code data at the point of time of a desired recorded scene in the unit's memory. Using the S.S.F. data stored in memory during after-processing of the recorded image allows efficient use of the tape. The S.S.F. -
Page 61: How To Use The S.s.f. Function
10. S.S.F. (Super Scene Finder) FUNCTION 10-2 How to Use the S.S.F. Function ZEBRA SKIN AUTO AREA WHITE TAKE button ACCU FOCUS AUDIO TAKE LEVEL CH-1 VTR trigger button CUE Mode MARK Mode Set the S.S.F. mode as MARK mode. Set the S.S.F. -
Page 62: Deleting S.s.f. Data
10. S.S.F. (Super Scene Finder) FUNCTION 10-3 Deleting S.S.F. Data The S.S.F. data recorded in the unit's memory can be deleted in the record mode and the record-pause mode. This function is only valid in the MARK mode. In the record mode, press the NG button after the IN point or OPERATE/WARNING OUT point has been stored. -
Page 63: Writing S.s.f. Data To Tape
10. S.S.F. (Super Scene Finder) FUNCTION 10-5 Writing S.S.F. Data to Tape S.S.F. data stored in the unitís memory can be written to the beginning of tape. Precautions when writing S.S.F. data STOP PLAY STILL • When S.S.F. data stored in the memory of the GY- STOP button DV700W is written to the beginning of the rewound tape, approximately 5 seconds of recorded video and/or sound... -
Page 64: Using External Components
11. USING EXTERNAL COMPONENTS 11-1Connecting a Video Component with DV Connector Rear section of GY-DV700W Video component with DV Connector CH-1 AUDIO IN CH-2 TALLY EARPHONE LINE LINE +48V +48V DC INPUT DC OUTPUT DV connector DV connector DV cable When connecting the GY-DV700W to other component with DV connector, be sure to observe the following procedure. -
Page 65: Connecting A Pc
RS-232C converter cable. Or connect the GY-DV700W’s DV connector and the DV connector of the non-linear editing controller using a DV cable. For compatible non-linear editing controller, consult with your JVC dealer. Settings • To remote control the PC or non-linear editing controller by means of RS-232C, set the VCR Setup Menu item No. 050 REMOTE SELECT to "RS232C". -
Page 66: Setup Menu
12. SETUP MENU 12-1 VCR Setup Menu The setup menus for the VCR section can be set while observing the menu in the viewfinder and on the unit's counter display. The set contents are stored in the memory and retained even after the power is switched OFF. VCR SETUP MENU CONFIGURATION The VCR Setup Menu is a two-layer construction. -
Page 67: Displaying And Setting Vcr Setup Menus
12. SETUP MENU 12-1 VCR Setup Menu (Cont'd) DISPLAYING AND SETTING VCR SETUP MENUS CH-1 AUDIO CH-2 TC GENERATOR LEVEL CH-1 CH-2 PRESET FREE AUTO REGEN MANUAL AUDIO SELECT OPERATE/WARNING LIGHT AUDIO INPUT RESET CH-1 CH-2 CONTINUE MENU MONITOR FRONT FILTER SELECT COUNTER... -
Page 68: Vcr Setup Menu Contents
12. SETUP MENU 12-1 VCR Setup Menu (Cont'd) VCR SETUP MENU CONTENTS Setting Item Factory Value Group Contents Setting Upper row: Viewfinder display Lower row: Counter display indication SERVO 050: REMOTE SELECT LOCAL Selection of the method for remote control of the VCR. LOCAL /SYSTEM IEEE1394... - Page 69 12. SETUP MENU 12-1 VCR Setup Menu (Cont'd) Setting Item Factory Value Group Contents Setting Upper row: Viewfinder display Lower row: Counter display indication SYSTEM 302: BACK SPACE STANDARD STAND- Selection of amount of back space for recording pause. QUICK STANDARD : Normally use this setting.
-
Page 70: Camera Menu Screen Flow
12. SETUP MENU 12-2 Camera Menu Screen Flow Camera Menu Screen Flow As illustrated below, the Camera Menu is a menu screen comprising several layers. The first layer of the CAMERA MENU screen is for choosing and setting the menus required in accordance with functions or purposes. The unit also allows the contents of menu settings to be stored in three files (SCENE FILE A, B, OFF). -
Page 71: How To Select From The Camera Menu
12. SETUP MENU 12-3 How to Select from the Camera Menu Press the STATUS button for 1 second to display the CAMERA MENU screen in the viewfinder. Choose the file with the camera menu settings to be used. (SCENE FILE A, B or OFF) OPERATE/WARNING LIGHT RESET... -
Page 72: Vf Display Screen
12. SETUP MENU 12-4 VF Display Screen Item Function, Operation Variation Range Initial Setting F NO. Selects whether or not the F-number of the lens iris is displayed on the DISPLAY Status 1 screen. ON ......F-number is displayed. OFF ....... F-number is not displayed. AUDIO Selects whether or not the audio indicator is displayed on the Status 1 DISPLAY... -
Page 73: Operation Screen
12. SETUP MENU 12-5 OPERATION Screen Item Function, Operation Variation Range Initial Setting ASPECT Sets the image size of the video signal. 16:9 16:9 RATIO 16:9 ..... 16:9 aspect ratio image output. When this setting is selected, an ID signal for identifying the WIDE screen mode is also output. 4:3 .... -
Page 74: Process Screen
12. SETUP MENU 12-6 PROCESS Screen Item Function, Operation Variation Range Initial Setting MASTER Adjusts the pedestal level (master black), which is the reference of black. MAX (100) NORMAL BLACK • To increase the pedestal level ..Increase the number. (UP) •... -
Page 75: Advanced Process Screen
12. SETUP MENU 12-7 ADVANCED PROCESS Screen Item Function, Operation Variation Range Initial Setting COLOR Sets the color matrix MATRIX OFF ..Deactivates the color matrix function ON ..The color reproducibility is enhanced, but noise increases. CAUTION: During the LOLUX operation, COLOR MATRIX is fixed to the OFF setting and "FIX"... -
Page 76: File Manage Screen
12. SETUP MENU 12-9 FILE MANAGE Screen The unit has three files that can be used for storing camera menus. The FILE MANAGE screen is for performing the operations for saving the set CAMERA MENU. • When menu settings are made using SCENE FILE A or B, the contents of the settings will be invalid if the storage operations are not performed on this screen. -
Page 77: Setup Screen
12. SETUP MENU 12-10 SETUP Screen Item Function, Operation Variation Range Initial Setting H PHASE For adjusting the horizontal phase of the unit in relation to the signal (external sync signal) input through the SYNC IN connector on the left side of the unit. -
Page 78: Resetting Of Camera Menu Setting Values
12. SETUP MENU 12-11 Resetting of Camera Menu Setting Values Using the FILE MANAGE screen, the CAMERA MENU settings can be reset to the initial setting values. On the FILE MANAGE screen, select the file of the CAMERA MENU to be reset, and then perform the resetting operation. Reset Operation Press the STATUS button for about 1 second to display the CAMERA MENU screen. -
Page 79: Features Of The Camera Section
13. FEATURES OF THE CAMERA SECTION 13-1 Full-Time Auto White Balance (FAW) The FAW function adjusts the white balance - - - OPERAT I ON - - - value automatically as the lighting condition SCENE F I L E A changes. -
Page 80: Iris (Brightness) Adjustment
13. FEATURES OF THE CAMERA SECTION 13-2 IRIS (Brightness) Adjustment ADJUSTMENT OF LENS IRIS The lens iris can be adjusted using any of the following three methods. • Automatic adjustment Set the iris mode switch to "A" (Auto). Iris ring The iris is adjusted automatically according to the brightness of the object. -
Page 81: Shooting The Screen Image On A Computer Monitor
13. FEATURES OF THE CAMERA SECTION 13-3 Shooting the Screen Image on a Computer Monitor Outline The following operation allows the alignment of the shutter speed of the camera with the variable scanning rate of a computer monitor or display. Band When a computer monitor screen or display is shot with the camera, a bright horizontal line indicating excessive exposure... -
Page 82: Gain (Sensitivity) Adjustment
13. FEATURES OF THE CAMERA SECTION 13-4 Gain (Sensitivity) Adjustment The gain should be switched when the brightness is insufficient due to poor lighting conditions. GAIN SWITCHING This switch allows the gain to be boosted when the illumination GAIN switch of the subject is insufficient. -
Page 83: Switch Setup According To Illumination And Subject
13. FEATURES OF THE CAMERA SECTION 13-5 Switch Setup According to Illumination and Subject Various switch settings are performed to accommodate the conditions of the illumination and the subject when shooting. SWITCH FUNCTIONS 1AUTO IRIS LEVEL switch This switch allows the reference value for the auto iris adjustment to be changed according to the lighting condition. -
Page 84: How To Use Skin Tone Detail
13. FEATURES OF THE CAMERA SECTION 13-6 How to Use Skin Tone Detail The contour emphasis in the skin color areas of the video signal can be controlled and made to appear gentle and smooth. Setting the Color and Range of the Skin Tone Detail Function OPERATE/WARNING LIGHT... - Page 85 13. FEATURES OF THE CAMERA SECTION 13-6 How to Use Skin Tone Detail (Cont’d) Confirming the color tone area adjusted with the Skin Tone Detail function When the ZEBRA switch on the front section is pressed to the “SKIN AREA” side, the color tone areas adjusted with Skin Tone Detail are displayed in the viewfinder.
-
Page 86: Others
• Signal is disturbed when the unit is subject to a violent shock. In other cases, please consult the person in charge of professional video equipment at your nearest JVC-authorized service agent. Lights in case of video head clogging. Operation : Continues. (Counter display) - Page 87 14. OTHERS 14-1 Troubleshooting (Cont'd) Alarm Indications (Cont'd) Depending on the alarm conditions, the warning indicators in the LCD display, the WARNING indicator, the TALLY lamp, alarm tones and the viewfinder appear as shown in the following table. Alarm Indications Viewfinder WARNING Lamp TALLY...
-
Page 88: Warnings In Viewfinder
14. OTHERS 14-1 Troubleshooting (Cont'd) WARNINGS IN VIEWFINDER Viewfinder Warning Lamps Function Failures When an abnormality occurs in the unit or an improper opera- tion is performed, one of the following warning messages will appear in the viewfinder. • VTR WARNING (HEAD): Lights in case of video head clogging. - Page 89 POWER switch to ON again after a few minutes. consult the person in charge of professional video equipment at your nearest JVC-authorized service agent. * If the display operates abnormally, Press the RESET switch inside the lithium battery case, and then set the POWER switch to ON again.
-
Page 90: Troubles With Error Code Outputs
3300 Tape unloading impossible. Operation stops. All operations situation. Please consult the person are rejected. in charge of professional video equipment at your nearest JVC- 4100 Irregular eject operation. Operation stops. All operations authorized service agent. are rejected. 4200 Cassette housing abnormality. -
Page 91: Troubles Without Error Code Outputs
14. OTHERS 14-1 Troubleshooting (Cont'd) TROUBLES WITHOUT ERROR CODE OUTPUTS Symptoms Remedy Power cannot be switched ON. • Is power supply connected properly? • Is battery pack recharged? • When the lithium battery is depleted, it may not be possible to turn on the power. •... -
Page 92: Hour Meter Display
14. OTHERS 14-2 Hour Meter Display The unit can display the accumulated running time of the head drum as hour meter data on the counter display. The hour meter can be displayed by selecting HM (HOUR METER) on the VCR Setup Menu. Use this as a guide for periodical maintenance. See page 7. -
Page 93: Specifications
14. OTHERS 14-3 Specifications CAMERA SECTION INPUT/OUTPUT SIGNALS Image pickup devices: 2/3-inch 16:9 interline CCD x 3 Video signal output : 1 V (p-p), 75 ohms (BNC) Color separation optical system: unbalanced composite output. F1.4 3-color separation prism YC output : Y 1 V (p-p) 75 ohms unbalance Number of effective pixels: C 0.286 V (p-p) 75 ohms... -
Page 94: Optional Accessories
14. OTHERS 14-3 Specifications OPTIONAL ACCESSORIES Viewfinder : VF-P116W Power zoom lens : A19 x 8.7BW, A19 x 8.7B12 (FUJINON) YJ18 x 9BK12 (CANON) AC power adapter : AA-P250 Microphone : MV-P615 Microphone holder : KA-A50 EXTERNAL DIMENSIONS (unit: mm) PUSH OPEN OPERATE/WARNING LIGHT... - Page 95 VICTOR COMPANY OF JAPAN, LIMITED ® is a registered trademark owned by VICTOR COMPANY OF JAPAN, LTD. ® is a registered trademark in Japan, the U.S.A., the U.K. and many other countries. Printed in Japan © 2001 VICTOR COMPANY OF JAPAN, LIMITED SC96991-001...
