VLAN ID (1-4094):
VLAN Type...
VLAN Name:
VLAN Network:
Inter-VLAN-Routing...
802.1x:
Return accepts * ESC cancels * Left/Right moves insertion point * Del deletes.
Select Add Port Interface and press Return.
The Add Port Interface screen appears. The Add Port Interface screen varies depending on the types of ports
available on your Motorola Netopia
SSIDs, and the Easy Setup Connection Profile that was created in your initial configuration of a 4-port wireless
VGx model.)
Port Interface...
TOS-Priority:
IPTOS-Promote:
COMMIT
Up/Down Arrow Keys to select, ESC to dismiss, Return/Enter to Edit.
From the Port Interfaces pop-up menu, select the port(s) that you want to associate with this VLAN.
You specify the characteristics of the VLAN by setting the next three parameters:
•
Tag – The Tag option is only available on global type ports. Packets transmitted from this port through this
VLAN must be tagged with the VLAN VID. Packets received through this port destined for this VLAN must be
tagged with the VLAN VID by the source.
Display/Change VLAN...
Add Port Interface...
®
Router. (The example below shows the four Ethernet ports, four wireless
Add Port Interface...
1
port-based
Network A
Easy Setup Profile
1, 2
No
+-NAME-----------------TYPE----+
+------------------------------+
| Eth 0/1
| Eth 0/2
| Eth 0/3
| Eth 0/4
| SSID 1
| SSID 2
| SSID 3
| SSID 4
| Easy Setup Profile
|
|
|
|
|
|
+------------------------------+
CANCEL
System Configuration 3-21
Port |
Port |
Port |
Port |
Port |
Port |
Port |
Port |
Profile |
|
|
|
|
|
|
