Physical I/F-----Rx Bytes---Tx Bytes---Rx Pkts---Tx Pkts----Rx Err----Tx Err
Ethernet Hub
ATM ADSL 1
Network----------Rx Bytes---Tx Bytes---Rx Pkts---Tx Pkts----Rx Err----Tx Err
IP
VC Traffic Statistics...
Physical Interface
The top left side of the screen lists total packets received and total packets transmitted for the following data
ports:
•
Ethernet
•
DSL
Network Interface
The bottom left side of the screen lists total packets received and total packets transmitted:
•
IP (IP packets on the Ethernet)
The right side of the table lists the total number of occurrences of each of six types of communication
statistics:
Rx Bytes. The number of bytes received
Tx Bytes. The number of bytes transmitted
Rx Packets: The number of packets received
Tx Pkts. The number of packets transmitted
Rx Err: The number of bad Ethernet packets received
Tx Err: The number of errors occurring when Ethernet packets are transmitted simultaneously by nodes on the
LAN
General Statistics
1234567 123456
1234567 123456
1234567 123456
123456 123456
123456 123456
123456 123456
Monitoring Tools 9-7
123456 12345
123456 12345
123456 12345
