Select Add ALAN and press Return.
The Add Additional LAN screen appears.
Name:
Enabled:
MAC Address:
Ethernet IP Address:
Ethernet Subnet Mask:
Define Additional Subnets...
IP Address Serving...
Rip Options...
Proxy Arp Enabled:
Multicast Forwarding...
VRRP Options...
Filter Set...
Remove Filter Set
COMMIT
Return accepts * ESC cancels * Left/Right moves insertion point * Del deletes.
Supply the following information:
•
Name – Enter a descriptive name for the ALAN or accept the assigned default.
•
Enabled – Toggles whether the ALAN is active or not. The default is Yes.
•
MAC Address – This field contains the MAC address of the interface. This is assigned automatically by the
system, and cannot be modified.
Additional LAN Configuration
Add ALAN...
Add Additional LAN
Additional LAN 1
Yes
00:00:00:00:00:00
0.0.0.0
0.0.0.0
No
None
CANCEL
