7-40 Administrator's Handbook
•
Ethernet IP Address – The IP address of the additional LAN.
•
Ethernet Subnet Mask – The IP subnet mask address of the additional LAN.
•
Define Additional Subnets – Additional subnets for multi-homing (same as the primary interface). See
Address Pools" on page
•
IP Address Serving – Same as the global link to address serving. See
•
RIP Options – Same as the primary interface. See
•
VRRP Options – Same as the primary interface. Two Virtual routers can be added to each of the ALANs.
See "Virtual Router Redundancy (VRRP)" on page
•
Multicast Forwarding – Same as the primary interface. See
•
Filter Set – Attaches a defined filter set to the LAN. See
When you are finished, select COMMIT and press Return. Your ALAN is configured.
Note:
ALAN creation or deletion takes effect only upon reboot. See
you don't know how to do this.
Editing or Deleting ALANs
You can manage or edit your ALANs at any time. To modify or delete a configured ALAN, return to the IP Setup
screen and select Additional LANs.
The Additional LAN Configuration screen appears.
If you select either Show/Change ALAN or Delete ALAN, a pop-up window allows you to choose the ALAN you
want to modify or delete.
7-19.
Additional LAN Configuration
Show/Change ALAN...
Add ALAN...
Delete ALAN...
"IP Address Serving" on page
"RIP Options" on page
7-34.
"Multicast Forwarding" on page
"About Filters and Filter Sets" on page
"Restarting the System" on page
7-9.
7-32.
"IP
7-17.
10-20.
11-8, if
