Motorola Netopia Embedded Software Handbook page 105

6. Choose None as the value for Underlying Encapsulation...
7. Local WAN IP Address and Local WAN IP Mask can be left at 0.0.0.0 if WAN interface can receive IP
Address from a DHCP server
8. Select NEXT SCREEN
9. Primary Domain Name Server and Secondary Domain Name Server can be left at 0.0.0.0, if dynamic
address is used on WAN
10. Select RESTART DEVICE
Set up administrative interface access restriction
(See "Telnet Tiered Access – Two Password Levels" on page 10-1
1. Go to System Configuration...
2. Select Security... and then Superuser Configuration
3. Type desired username and password. You will be asked to re-enter password. Navigate to 'ADD
SUPERUSER' to add 'Superuser' and restrict access to administrative console.
4. Once 'Superuser' is created, you can add further users, if desired, by going to Add Access Name/Pass-
word...
5. Escape once back to Main Menu
Setting up an encrypted communication channel: (PPTP with MS-CHAP/MPPE)
(See "Virtual Private Networks (VPNs)" on page 5-1
1. From the Main Menu, Go to Quick Menus...
2. Select ATMP/PPTP Default Profile
3. Set Answer ATMP/PPTP Connections: to Yes
4. Under PPTP Configuration Options set Receive Authentication... to MS-CHAP
5. Escape once back to Quick Menus
6. Scroll up to Add Connection Profiles and press Enter
7. Supply a descriptive Profile Name.
8. Set the Encapsulation Type... to PPTP and press Enter
9. Enter Encapsulation Options...
a. Enter the PPTP Partner IP Address - this can be set to 0.0.0.0
b. For Authentication... select MS-CHAP
c. For Data Encryption... select MPPE
d. Enter the Receive Host Name and Receive Secret the client will be entering as their username and
password in their Dial-up Networking VPN profile.
e. Set Initiate Connections to No.
f. Adjust the Idle Timeout (seconds) to whatever you prefer. The default value is 300 seconds.
for more information.)
for more information.)
System Configuration 3-61
