Motorola Netopia Embedded Software Handbook page 261

To view Backup Management/Statistics, from the Main Menu select Statistics & Logs then
Backup Management/Statistics and press Return.
Main
Menu
The Backup Management/Statistics screen appears.
Current Gateway:
Backup State:
Reason:
Time Since Detection:
Switchover Time:
•
Current Gateway is a display-only field that shows which port is currently in operation.
•
Backup State is a display-only field that shows the current state of Backup or Recovery.
•
Reason becomes visible when a failure of or recovery to the Primary interface is in progress.
During backup, the following reasons may appear:
Loss of Layer 1
Loss of Layer 2
Loss of Layer 2 (ping)
Loss of Layer 2 (Protocol Failure)
Statistics & Logs
Backup Management/Statistics
Primary
Primary Port Failure in Progress
Loss of Layer 1
0:12
2:00
FORCE RECOVERY
Indicates a loss of sync on the Primary link
Indicates connection profile cannot come up
Indicates Backup Ping Address not responding
Indicates Primary link not responding to Protocol check
(LCP Echo, LMI Status Request)
Line Backup 8-17
Backup Management/
Statistics
