SPS LED Indications

LEDs

The SPS has the following LEDs:
LED1 (yellow). Illuminates when NAC 1 is ON or in Fault.
LED2 (yellow). Illuminates when NAC 2 is ON or in Fault.
LED3 (yellow). Illuminates when NAC 3 is ON or in Fault.
LED4 (yellow). Illuminates to indicate a communications loss with the system CPU;
normally off. If this LED is blinking, try re-loading the software to FLASH.
LED5 (yellow). Indicates IDNet status.
•
Slow blink: Class A open circuit Fault.
•
Fast blink: Short circuit Fault.
•
On steady: No devices detected/ channel failure.
•
Normally off.
LED6 (yellow). Indicates power supply status.
•
Single blink: Positive earth fault.
•
Double blink: Negative earth fault.
•
Triple blink: Battery Fault.
•
Quadruple blink: Charger Fault.
•
On steady: Overcurrent fault.
•
Normally off.
LED7 (green). Illuminates when the power supply is powered from the AC line. Off
when the power supply is de-energized, or when it is using battery backup power.
6-5
