Summary of Contents for Barco FLM R22+

  • Page 1 FLM R22+ User guide R9004500 R59770179/04 15/03/2010...
  • Page 2 Barco nv Media & Entertainment Division Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.36.883.86 E-mail: sales.events@barco.com Visit us at the web: www.barco.com Printed in Belgium...

  • Page 3: Software License Agreement

    GNU-GPL code If you would like a copy of the GPL source code contained in this product shipped to you on CD, please contact Barco. The cost of preparing and mailing a CD will be charged.
  • Page 4 The crossed-out wheeled bin symbol invites you to use those systems. If you need more information on the collection, reuse and recycling systems, please contact your local or regional waste administrator. You can also contact us for more information on the environmental performances of our products.

  • Page 5: Table Of Contents

    Table of contents TABLE OF CONTENTS 1. Safety ....................... .. 5 General .
  • Page 6 Table of contents 8. Input menu ......................59 Overview flow .
  • Page 7 Table of contents 12.3 Lens adjustment ........................119 12.4 Side keystone.
  • Page 8 Table of contents 14.7 Reset formatter ........................175 14.8 Save custom settings.

  • Page 9: Safety

    1. Safety 1. SAFETY General ARNING Ensure you understand and follow all the safety guidelines, safety instructions, warnings and cautions mentioned in this manual. ARNING Be aware of suspended loads. ARNING Wear a hard hat to reduce the risk of personal injury. ARNING Be careful while working with heavy loads.

  • Page 10: Important Safety Instructions

    1. Safety Important safety instructions To prevent the risk of electrical shock • This product should be operated from a mono phase AC power source. Power input voltage range must be between 200-240 VAC, 50–60 Hz, 18 amps at 230 VAC. •...
  • Page 11 Caution: High pressure lamp may explode if improperly handled. Refer servicing to qualified service personnel. The customer should never attempt to disassemble the lamp casing or to dispose of the lamp casing other than by returning it to Barco. •...
  • Page 12 If the product exhibits a distinct change in performance, indicating a need for service. • Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replace- ment parts. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.

  • Page 13: Important Warnings Concerning Flm Flight Cases

    1. Safety Important warnings concerning FLM flight cases Important warnings concerning stacking/transporting FLM rental flight cases • Stack maximum two (2) FLM rental flight cases high. Never higher. • Surface on which flight case is standing must be level to ensure that the total load is evenly spread out among the four wheels. The surface must also be able to support the load safely.
  • Page 14 1. Safety R59770179 FLM R22+ 15/03/2010...

  • Page 15: General

    Projector weight Do not underestimate the weight of one Barco FLM R22+, which is about ±100 kg (±225 lb.). Be sure that the table or truss installation on which the projector(s) has to be installed is capable of handling five (5) times the complete load of the complete system.

  • Page 16: Unpacking The Projector

    2. General Screens are rated by how much light they reflect (or transmit in the case of rear projection systems) given a determined amount of light projected toward them. The ‘GAIN’ of a screen is the term used. Front and rear screens are both rated in terms of gain. The gain of screens range from a white matte screen with a gain of 1 (x 1) to a brushed aluminized screen with a gain of 10 (x 10) or more.

  • Page 17: Box Content

    This check should confirm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and scratches, and that the meter face and operating panel are not scratched of cracked. The Barco sales and service office should be notified as soon as possible.

  • Page 18: Flm Flight Case

    2. General FLM flight case Introduction of the FLM flight case The FLM flight case is designed to transport the FLM R22+ in a safe and secure manner. The four caster wheels, provided with breaks, and the eight handles make the FLM flight case easy to handle. The floor of the flight case wagon is equipped with two small covered compartments to store the remote control and the rigging clamps.

  • Page 19: Rear Projection

    2. General AUDIENCE FLOOR Image 2-6 Rear projection The projector is installed, either in a table mount or ceiling mount configuration, at the other side of the screen opposite the audience. AUDIENCE BACKSTAGE FLOOR Image 2-7 R59770179 FLM R22+ 15/03/2010...

  • Page 20: Positioning The Projector

    2. General Positioning the projector SCREEN FLOOR Image 2-8 The projector should be installed at right angles (horizontally and vertically) to the screen at a distance PD. Note the distance (A) between lens centre and table surface is slightly variable. This distance (A) is nominal 35 cm in case all feet are turned in completely and the vertical lens shift is set to zero (0).
  • Page 21 2. General +90% SIDE VIEW +90% -57% +57% -90% -57% TOP VIEW -90% +57% Image 2-9 DMD. Field of view. It’s mechanical possible to shift outside the recommended field of view (±100% UP/DOWN and ±70% LEFT/RIGHT), but this will result in a slightly decline of image quality depending on the used lens and the zoom position of the used lens.

  • Page 22: Projector Air Inlets And Outlets

    Projector Toolset is only available in a download version, no CD can be ordered. Where to find the download file(s) The program and all necessary plug-ins, as well as the Reference manual can be downloaded for free from Barco’s Partnerzone, URLhttps:\\my.barco.com. Registration is necessary.

  • Page 23: Physical Installation

    3. Physical installation 3. PHYSICAL INSTALLATION About this chapter This chapter explains how to install and set up your FLM projector. If you are familiar with the projector and want to quickly set it up for temporary use, follow the “Quick setup” instructions below. For a more complete setup, follow the instructions and guides covered in the remaining subsections.

  • Page 24: Rcu Battery Installation

    3. Physical installation Overview • RCU battery installation • RCU rugged case installation • RCU XLR adaptor installation • Using the XLR adaptor of the RCU • RCU usage possibilities 3.1.1 RCU battery installation Where to find the batteries for the remote control ? The batteries are not placed in the remote control unit to avoid control operation in its package, resulting in a shorter battery life time.

  • Page 25: Rcu Rugged Case Installation

    3. Physical installation 3.1.2 RCU rugged case installation How to install the rugged case of the remote control ? 1. Slide the bottom of the RCU into the rugged case and then pull the top of the rugged case over the top of the RCU as illustrated. Image 3-5 3.1.3 RCU XLR adaptor installation...

  • Page 26: Rcu Usage Possibilities

    3. Physical installation Image 3-7 3.1.5 RCU usage possibilities Summarized possibilities Ref. Possibility description Comment RCU not wired RCU wired (mini-jack) Backlight illuminates continuously when wire is connected. Infra red disabled. RCU with rugged case not wired RCU with rugged case wired (mini-jack) Backlight illuminates continuously when wire is connected.

  • Page 27: Lenses

    3. Physical installation Lenses 3.2.1 Available lenses Available lenses for the FLM R22+ projector The TLD HB (High Brightness) lens series can be used on the FLM R22+ projector. Image 3-9 Image 3-10 Image 3-11 R9842040: TLD HB fixed lens (0.8 : 1) R9840770: TLD fixed lens (1.2 : 1) R9840775: TLD+ (1.2 : 1) fixed lens Image 3-12...

  • Page 28: Lens Formulas

    3. Physical installation 3. Use the lens formulas to find the best corresponding PD with regard to the measured projector-screen distance for the required screen width SW. Tip: Divide PD by SW to determine the approximate throw ratio. Choose a Lens, which captures the calculated throw ratio. Use the lens formula of the chosen Lens to recalculate exactly.
  • Page 29 3. Physical installation Image 3-17 4. Ensure that the lens holder stands in the On-Axis position (horizontal and vertical mid position). Note: The lens holder is placed default in the On-Axis position at factory. 5. Gently insert the lens in such a way that the lens connector matches the socket (B). Image 3-18 6.

  • Page 30: Lens Removal

    3. Physical installation AUTION Never transport the projector with a Lens mounted in the Lens Holder. Always remove the Lens before transporting the projector. Neglecting this can damage the Lens Holder and Prism. 3.2.5 Lens removal How to remove a lens from the projector lens holder ? 1.

  • Page 31: Alignment Of A Table Mount Flm Projector

    3. Physical installation Alignment of a table mount FLM projector How to align a table mount FLM projector ? 1. Place the projector in the desired location. Take into account the zoom range of the used lens and the size of the screen. 2.

  • Page 32: Suspension Of The Flm Projector With Rigging Clamps

    3. Physical installation When this is achieved, the projector is set horizontal and vertical at right angles to the screen. Image 3-25 5. Fasten the lock nut (B) of the rigging clamps. Suspension of the FLM projector with rigging clamps Rigging points and rigging clamps The carrying handle, at the bottom side of the projector, is provided with eight slots.
  • Page 33 3. Physical installation X mm Image 3-28 3. Turn in the rigging clamps (A) into the rigging points using a 17 mm open ended spanner and secure the rigging clamps by turning the safety nut (B) on the rigging clamp against the rigging point using a 17 mm open ended spanner. Warning: Always use four (4) rigging points, equally spread, to suspend the projector.
  • Page 34 3. Physical installation Image 3-31 6. Lift up the projector and hook the four rigging clamps over the support bars of the truss. 7. Lock all four rigging clamps. 8. Install a safety chain (S) around both sides of the carrying handle and around the truss. Image 3-32 9.

  • Page 35: Stacking Flm Projectors

    4. Stacking FLM projectors 4. STACKING FLM PROJECTORS General Three interlocking adapters at the top and at the bottom of the FLM projector allows an easy and fast stacking without using extra tools or accessories. ARNING Maximum stack three (3) FLM projectors in a table mount configuration. Maximum stack two (2) FLM projectors in a ceiling mount configuration.
  • Page 36 4. Stacking FLM projectors 4. Are these projectors stacked for a ceiling mount configuration? If yes, secure the projectors with safety chains as follows: a) Release the safety hook (H) at both sides of the lowest projector and guide the safety cable around its carrying handle (C) as illustrated.

  • Page 37: Aligning Stacked Flm Projectors

    4. Stacking FLM projectors ARNING Never open an interlocking adapter of a stacked projector which is still suspended. First place the stacked projectors on the floor. Aligning stacked FLM projectors Necessary tools 8 mm Allen key. How to align two stacked FLM projectors ? 1.
  • Page 38 4. Stacking FLM projectors Skew Image 4-8 6. Shift the hatch pattern horizontally and vertically until the outline of the hatch pattern is most symmetrically placed with respect to the reference hatch pattern. Note: Note that the “Shift” function is motorized, which means that you have to access the projector software, via the local keypad or remote control unit, to operate the “Shift”...

  • Page 39: Connections

    5. Connections 5. CONNECTIONS About this chapter This chapter describes more in detail the power (P), the input source (S) and the communication (C) connections of the FLM R22+. Image 5-1 Overview • Power connection • Input source connections • Communication connections Power connection AUTION...
  • Page 40 5. Connections The voltmeter (M) will immediately indicate the value of the mains voltage as soon as the projector is connected with the power net. Image 5-2 ARNING Do not attempt operation if the AC supply and cord are not within the specified voltage and power range.

  • Page 41: Input Source Connections

    5. Connections Input source connections General The input and communication unit is equipped with four input slots, which accept any type of input module designed for the FLM projector. The modularity of the input modules makes the FLM projector very flexible regarding input source connectivity. Note that the slot numbering is done from top to bottom.

  • Page 42: Communication Connections

    5. Connections The FLM R22+ is standard equipped with one 5 cable input module, one HDSDI - SDI input module and one DVI input module. Input slot number 4 (lowermost) is covered with a input cover plate. For more information about the FLM input modules see chapter “Specifications”. Communication connections Communication interface DIAGNOSTIC CODE...
  • Page 43 5. Connections female XLR output port (N). So, the following projector in the daisy chain will still receive his RC5 code. Note that the RC5 in/out signals are without carrier. Mini jack plug XLR – Remote CTRL in XLR – Remote CTRL out Pin Description Pin Description Pin Description...
  • Page 44 5. Connections RS232/422 input port RS232/422 output port Pin Description Pin Description CTS : Clear To Send — (not connected) — RI : Ring Indicator — (not connected) — Image 5-13 Pin numbering male DB–9 connector. Pin numbering female DB-9 connector. RS232 An Electronic Industries Association (EIA) serial digital interface standard specifying the characteristics of the commu- nication path between two devices using either D-SUB 9 pins or D-SUB 25 pins connectors.

  • Page 45: Usb Port

    5. Connections 10/100 Base-T — RJ45 port Pin Description — — USB port The communication interface is equipped with a master USB port, type “A” connector (H). This USB port will simplify the service procedures for taking backup files from the projector without network connection. An USB-stick is plugged into the USB port and files can be transferred from or to the projector using the local or remote control unit.
  • Page 46 5. Connections R59770179 FLM R22+ 15/03/2010...

  • Page 47: Getting Started

    6. Getting started 6. GETTING STARTED About this chapter This chapter describes the functions on the remote control and local keypad and gives an overview how to start up the projector. If gives also a brief overview of the direct adjustment possible with these controls. Overview •...
  • Page 48 6. Getting started MENU EXIT ENT ER PAUSE LENS TEXT EXIT MENU PHASE SHARP N PATTERN WINDOW LENS TINT ENTER RIGGING STBY PAUSE TEXT AUTO COLOR BRI GHTN CONTR LENS LENS ZOOM SHIFT LENS LENS SHIFT FOCUS Image 6-1 Local keypad & remote control Ind.

  • Page 49: Operating The Projector

    6. Getting started Ind. Key name Description PHASE Used to remove the horizontal instability of the image (usually for RGB source). It adjusts the phase of the pixel sampling clock relative to the incoming signal. FREEZE To freeze the actual projected image. Freeze sign is displayed in the upper left corner (a short press on the key).

  • Page 50: Errors, Warnings And Messages During Start Up

    6. Getting started The actual input voltage is indicated on the voltmeter just above the power switch. Starting image projection via the standby key. 1. Press Stand by key once on the local keypad or on the remote control. MENU EXIT ENTER TEXT...

  • Page 51: Switching Off

    6. Getting started Switching to Standby. When the projector is running and you want to go to standby, press the standby key for 2 seconds. Do not press any longer on the standby key otherwise the projector will restart. All custom settings are written to the internal backup device. A message ’Save data ...’ indicates this process. Never switch off the projector while this message is displayed.
  • Page 52 6. Getting started 5-cab le inp ut S yn c OK R /P r G/ Y/ Vi deo B/ Pb H/ S V/ Cs DV I i np ut S yn c OK HD SD I - SDI i np ut 1 2 3 4 5 ME N U EXI T...

  • Page 53: Quick Setup Adjustments

    6. Getting started Quick setup adjustments Overview • Text boxes ON or OFF • Quick Lens Adjustment • Quick picture in picture • Quick layout selection with Rigging key • Quick language selection 6.5.1 Text boxes ON or OFF Text toggle function The on-screen text boxes can be switched OFF so that an adjustment during the operation of the projector are not visible on the screen.

  • Page 54: Direct Lens Adjustment (Rcu)

    6. Getting started The shift menu will be displayed. Image 6-9 3. Push the cursor key ▲ or ▼ to shift the image up or down and ◄ or ► to shift the image left or right. 4. When finished, press EXIT key to return or ENTER to continue to zoom/focus. Press the LENS key to switch to another pattern.

  • Page 55: Quick Layout Selection With Rigging Key

    6. Getting started Image 6-11 6.5.4 Quick layout selection with Rigging key What can be done ? When the projector is playing, changing from one layout to another is possible without displaying any on screen selection menu. The current image is not disturbed as long no selection is made. Press the Rigging key followed by one or two digits to jump to a new layout.

  • Page 56: Projector Address

    6. Getting started The current active language is indicated with an asterisk (*). Image 6-15 Image 6-14 Image 6-13 Projector Address 6.6.1 Displaying and Programming addresses Displaying the Projector Address on the Screen. 1. Press Address key (recessed key on the RCU) with a pencil. The projector’s address is displayed as first item in the Identification screen.

  • Page 57: Controlling The Projector

    6. Getting started 6.6.2 Controlling the projector Projector address Address installed in the projector to be individually controlled. Common address Projector will always execute the command coming from a RCU programmed with that common address. Why a projector address ? As more than one projector can be installed in a room, each projector should be separately addressable with an RCU or computer.

  • Page 58: Controlling The Projector

    6. Getting started Controlling the Projector Picture Controls When an image control is pressed, a text box with a bar scale, icon and function name of the control, e.g. ’brightness...’ appears on the screen (only if text is ON). See example screen. The length of the bar scale and the value of the numeric indication indicate the current memorized setting for this source.

  • Page 59: Start Up Of The Adjustment Mode

    7. Start up of the Adjustment Mode 7. START UP OF THE ADJUSTMENT MODE Overview • About the adjustment mode • About the use of the remote control and the local keypad • Start up the adjustment mode • Navigation and adjustments •...

  • Page 60: Navigation And Adjustments

    7. Start up of the Adjustment Mode The main menu of the adjustment mode opens. Image 7-1 Navigation and adjustments How to navigate in the menu structure? Once in the menu structure, use the ▲ or ▼ keys on the remote control (or the ▲ or ▼ (+ or -) key on the local keypad) to scroll through the items in the displayed menu.

  • Page 61: On Screen Menus Versus Lcd Display Menus

    7. Start up of the Adjustment Mode How to use a shortcut key While in the operational mode, no menu selected, just press on the desired digit key to open the menu behind that shortcut key. How to create a shortcut key Scroll to the desired menu.
  • Page 62 7. Start up of the Adjustment Mode R59770179 FLM R22+ 15/03/2010...

  • Page 63: Input Menu

    8. Input menu 8. INPUT MENU Overview • Overview flow • Slot module type • Input locking • Minimum delay • Native resolution • Source switching • No signal Overview flow Overview Level 1 Level 2 Level 3 Input 5-cable Slot module type HD-SDI - SDI DVI HDCP...

  • Page 64: Input Configuration

    8. Input menu AUTION Always install a cover plate on an unused input slot. This to prevent dust intrusion into the pro- jector. 8.2.2 Input configuration How to change? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Input and press ENTER. The Input menu is displayed.

  • Page 65: Input Locking

    8. Input menu Image 8-5 Press ENTER to toggle between [Analog] and [TTL]. For a HDSDI - SDI module When ENTER is pressed on a HDSDI or SDI module, the following menu appears: Image 8-6 Use the ▲ or ▼ key to select the desired configuration and press ENTER to select. When an input with priority is selected, then if a signal is connected to both inputs the input indicated has the priority.
  • Page 66 8. Input menu Image 8-8 Image 8-9 Image 8-7 When: Free run Output is locked on an internal sync (60 Hz) Automatic Output is locked on the selected input for the main window Input 1 Output is locked on source 1 Input 2 Output is locked on source 2 Input 3...

  • Page 67: Minimum Delay

    8. Input menu Genlock off (default position) locking done on input source of main window, when automatic was selected or on the selected input source when a specific input was selected. Projector detects automatically the vertical frequency and clock frequency of the input signal. A slightly difference with the source is possible. Genlock on locking done on indicated vertical frequency and clock frequency.
  • Page 68 8. Input menu Image 8-14 When the show native resolution function is in the ON position, the projector handles the source as follows: Source Projected image Name Ratio Resolution Ratio Resolution 1024x768 1024x768 image projected with black borders SXGA 1280x1024 1280x1024 image projected with black borders...

  • Page 69: Source Switching

    8. Input menu Source switching Switching from one source to another To minimize undesired effects when switching from one source to another one can use the switching mode, using the fade effect. Image 8-17 Example of fade effect Switching mode set up 1.

  • Page 70: Shutdown Setting

    8. Input menu 2. Use the ▲ or ▼ key to select Input and press ENTER. The Input menu is displayed. 3. Use the ▲ or ▼ key to select No signal and press ENTER to toggle between [Black] and [Blue]. Image 8-23 Image 8-22 Image 8-21...
  • Page 71 8. Input menu enter the desired value with the keyboard. When trying to exceed the maximum allowed value, the system will set it back to the maximum value. Image 8-29 Image 8-28 Image 8-27 R59770179 FLM R22+ 15/03/2010...
  • Page 72 8. Input menu R59770179 FLM R22+ 15/03/2010...

  • Page 73: Image Menu

    9. Image menu 9. IMAGE MENU Overview • Overview flow • How to select the image adjustments? • Image Settings • Aspect ratio • Timings • Image files services • Save custom settings Overview flow Overview Level 1 Level 2 Level 3 Level 4 Image...

  • Page 74: How To Select The Image Adjustments

    9. Image menu Level 1 Level 2 Level 3 Level 4 Vertical start Advanced settings Clamp delay Clamp width Field polarity Film mode detection Image file services Manual load Delete Delete all Rename Copy Options Load file Save custom settings How to select the image adjustments? Start up 1.

  • Page 75: Contrast

    9. Image menu 9.3.1 Contrast About Contrast The contrast function is used to adjust the contrast between the light and dark areas of the displayed image. How to change the contrast? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Image and press ENTER. 3.

  • Page 76: Saturation

    9. Image menu The higher the value, the higher the brightness. Image 9-8 Image 9-7 Image 9-9 Image 9-10 9.3.3 Saturation About (color) saturation The color function is used to adjust the color saturation levels. How to change the saturation? 1.

  • Page 77: Tint (Hue)

    9. Image menu 9.3.4 Tint (hue) About Tint The Tint function is used to adjust color hue to obtain true color reproduction and is only active for Video and S-Video when the NTSC color system is used. For PAL and SECAM sources, Tint is not accessible. How to change the saturation? 1.

  • Page 78: Sharpness

    9. Image menu How to change the phase? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Image and press ENTER. 3. Use the ▲ or ▼ key to select Image settings and press ENTER. 4.

  • Page 79: Noise Reduction

    9. Image menu Image 9-25 Image 9-24 Image 9-26 Image 9-27 9.3.7 Noise reduction About Noise reduction Reduces noise and pixel jitter in all video sources. How to change? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Image and press ENTER. 3.

  • Page 80: Color Temperature

    9. Image menu 9.3.8 Color temperature What can be done ? The color temperature can be selected according to the type of source: There are 5 different preset color temperatures: • Projector white • computer : 9300 K • Video : 6500 K •...

  • Page 81: Set A Custom Color Temperature

    9. Image menu Image 9-35 9.3.8.2 Set a custom color temperature How to enter a custom value? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Image and press ENTER. 3. Use the ▲ or ▼ key to select Image settings and press ENTER. 4.

  • Page 82: Input Balance

    9. Image menu 9.3.9 Input balance Overview • Introduction to Input Balance • Adjusting the input balance 9.3.9.1 Introduction to Input Balance Introduction: Unbalanced color signals When transporting signals, there is always a risk of deterioration of the information contained in the signals. In case of information contained in the amplitude of the signals which is the case of data color signals (R, G, B),image 9-41 , we are quite sure that the amplitude of these color signals is subject to alterations.

  • Page 83: Adjusting The Input Balance

    9. Image menu One can conclude here that a good data conversion can only be met by using three previously (input) balanced color signals The objective of input balancing The objective in input balancing is to “set” the same black level and the same white level for the three colors of a particular input source.

  • Page 84: Black Balance

    9. Image menu An alternative to a full screen White/black pattern is the standard gray scale pattern, the white bar will be used for white balance and the black bar for black balance. Image 9-45 Black balance 1. Press MENU to activate the menus. 2.
  • Page 85 9. Image menu The projected image should now be noisy full black If one uses a gray scale pattern, the bright spots should appear in the black bar. Performing White input balance 1. Connect the source you want to project. 2.

  • Page 86: Aspect Ratio

    9. Image menu Aspect ratio Aspect ratio Relation between the horizontal & vertical dimension in which the window will be displayed, e.g. 4 by 3 or 16 by 9. Can also be expressed as a decimal number, such as 1.77. The larger the ratio or decimal, the wider are less square the image.

  • Page 87: Timings

    9. Image menu How to select an Aspect ratio? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Image and press ENTER. 3. Use the ▲ or ▼ key to select Aspect ratio and press ENTER. The aspect ratio menu will be displayed.

  • Page 88: Advanced Settings

    9. Image menu How to start up? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Image and press ENTER. 3. Use the ▲ or ▼ key to select Timings and press ENTER. The timings menu will be displayed.
  • Page 89 9. Image menu Sync pulse Clamp pulse Clamp Clamp delay width Image 9-66 Field polarity The field polarity function is used for interlaced images. Both rasters of the image could be shifted in a wrong way (double lines are visible in the image). This can be corrected by forcing the field polarity to [neg] or [pos].

  • Page 90: Advanced Settings, Film Mode Detection

    9. Image menu How to change the field polarity? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Image and press ENTER. 3. Use the ▲ or ▼ key to select Advanced settings and press ENTER. The Advanced settings menu is displayed.
  • Page 91 9. Image menu 2:2 pull-down The process of transferring 24-frames/sec film format into video by repeating each frame (used for PAL DVD’s) as two video fields. ( AD ) Artefacts Undesirable elements or defects in a video picture. These may occur naturally in the video process and must be eliminated in order to achieve a high-quality picture.

  • Page 92: Image Files Services

    9. Image menu Image files services Overview • Files and file manipulations • Manual Load file • Delete file • Delete all custom files • Rename a file • Copy a file • File options 9.6.1 Files and file manipulations Connecting a new source.

  • Page 93: Delete File

    9. Image menu Image 9-82 Depending on the filter setup, the following is displayed: Fit: only fitting files for the selected source will be in the list All: all files in the system will be in the list. 5. Do you want to see only the fitting file in the manual load menu? If yes, Select Filter and use ►...

  • Page 94: Delete All Custom Files

    9. Image menu Image 9-86 No recovery possible ! 9.6.4 Delete all custom files How to delete? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Image and press ENTER. 3. Use the ▲ or ▼ key to select File services and press ENTER. The File service menu is displayed.

  • Page 95: Copy A File

    9. Image menu 2. Use the ▲ or ▼ key to select Image and press ENTER. 3. Use the ▲ or ▼ key to select File services and press ENTER. The File service menu is displayed. 4. Use the ▲ or ▼ key to select Rename and press ENTER. The rename window opens.

  • Page 96: File Options

    9. Image menu Image 9-97 Image 9-98 Image 9-96 Image 9-100 Image 9-99 9.6.7 File options How to set the options? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Image and press ENTER. 3.

  • Page 97: Save Custom Settings

    9. Image menu [Automatic]: correct file will be loaded automatically. [Manual]: correct file has to be loaded manually. [Custom only]: correct file will be loaded automatically out of the available custom files. Image 9-104 6. Use the ▲ or ▼ key to select Auto picture alignment and press ENTER to toggle between [Off], [Always] and [File load]. Image 9-105 [Off]: no auto picture alignment activated.
  • Page 98 9. Image menu R59770179 FLM R22+ 15/03/2010...

  • Page 99: Layout Menu

    10. Layout menu 10. LAYOUT MENU Overview • Overview flow • Main window • PIP window • Layout file services • Zoom - Focus 10.1 Overview flow Overview Level 1 Level 2 Level 3 Level 4 Layout Main window Source Size Position PIP window...

  • Page 100: Source Selection

    10. Layout menu Image 10-2 Image 10-1 The first character is highlighted. Use the ▲ or ▼ key to select the desired character and press key to select the next character in the name. Press EXIT to return. The new file is generated. 10.2.1 Source selection What can be done ? The source of the main window can be selected via the Main window menu.
  • Page 101 10. Layout menu Image 10-7 Size adjustment main window width adjustment height adjustment The size can be changed with respect to the original aspect ratio. How to adjust with respect to the original aspect ratio? 1. Press MENU to activate the menus. 2.

  • Page 102: How To Adjust Height And Width Separately

    10. Layout menu Image 10-11 [ ] = no lock between height and width. [x] = width and height are locked. 6. Use or▲ ▼ to adjust the size with respect to the original aspect ratio. When the desired size is reached, press EXIT. A Save window opens.

  • Page 103: Position Adjustment

    10. Layout menu Image 10-16 [ ] = no lock between height and width. [x] = width and height are locked. 6. Use the ▲ or ▼ key to adjust the height. Use the ◄ or ► key to adjust the width. When the desired size is reached, press EXIT.

  • Page 104: Pip Window

    10. Layout menu Use the ◄ or ► key to adjust left start point. When the desired size is reached, press EXIT. A Save window opens. Image 10-21 Image 10-20 Image 10-19 Image 10-23 Image 10-22 6. Select with the ▲ or ▼ key Save and press ENTER. Select with the ▲...

  • Page 105: Picture In Picture Activation

    10. Layout menu Image 10-24 Position of PiP Top position Left position 10.3.2 Picture in Picture activation How to activate PIP? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Layout and press ENTER. 3.

  • Page 106: Picture In Picture Size Of The Window

    10. Layout menu The source selection window opens. 5. Use the ▲ or ▼ key to select the desired source and press ENTER to activate this source. Image 10-29 Image 10-30 Image 10-28 Image 10-31 10.3.4 Picture in Picture size of the window What can be done? The width and height of the picture in picture window can be changed till the desired dimensions are obtained.
  • Page 107 10. Layout menu Image 10-33 Size PIP window remark How to change the size with respect to the aspect ratio? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Window and press ENTER. 3.

  • Page 108: How To Change The Height And Width Separately

    10. Layout menu A Save window opens. Image 10-38 7. Select with the ▲ or ▼ key Yes and press ENTER. Select with the ▲ or ▼ key No, when no save is desired and press ENTER. How to change the height and width separately? 1.

  • Page 109: Picture In Picture, Position Window

    10. Layout menu A Save window opens. Image 10-43 7. Select with the ▲ or ▼ key Yes and press ENTER. Select with the ▲ or ▼ key No, when no save is desired and press ENTER. 10.3.5 Picture in Picture, position window What can be done? The picture in picture window can be position on any place on the display just by changing its start coordinates.

  • Page 110: Layout File Services

    10. Layout menu 10.4 Layout file services Overview • Load layout • Rename a layout • Delete a layout • Copy / Save as a layout 10.4.1 Load layout When loading a layout which required two sources, the PIP window On/Off setting will be switched to ON. How to load? 1.

  • Page 111: Rename A Layout

    10. Layout menu 10.4.2 Rename a layout Only custom created layouts can be renamed. How to rename? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Window and press ENTER. 3. Use the ▲ or ▼ key to select Layout and press ENTER. The layout services window opens.

  • Page 112: Copy / Save As A Layout

    10. Layout menu The layout services window opens. 4. Use the ▲ or ▼ key to select Delete and press ENTER. The Delete window opens. Image 10-59 Image 10-58 Image 10-57 Image 10-60 The first 3 layouts are default layouts and cannot be delete. 5.

  • Page 113: Zoom - Focus

    10. Layout menu Image 10-63 Image 10-62 Image 10-61 Image 10-64 10.5 Zoom - Focus What can be done ? When changing from one layout to another, the zoom/focus settings can be different for each layout or they can be kept the same for all layouts.
  • Page 114 10. Layout menu Image 10-67 Image 10-66 Image 10-65 R59770179 FLM R22+ 15/03/2010...

  • Page 115: Lamp Menu

    11. Lamp menu 11. LAMP MENU Overview • Overview flow • Lamp power mode • Lamp power • Constant Light Output mode (CLO mode) • CLO target • Lamp Identification • Z-axis adjustment 11.1 Overview flow Overview Level 1 Level 2 Level 3 Level 4 Lamp...

  • Page 116: Lamp Power

    11. Lamp menu Image 11-2 Image 11-3 Image 11-1 Remarks When mode is set to [Normal], then CLO mode can be switched on and off. When switching the power mode to [Economic] while the CLO mode is On, then the CLO mode is switched to Off. When the power mode is [Economic] and the CLO mode is switched to the [On] mode, then the power mode will be switched to the [Normal] mode.

  • Page 117: Constant Light Output Mode (Clo Mode)

    11. Lamp menu 11.4 Constant Light Output mode (CLO mode) What can be done? Constant Light Output allows to force a constant light output (set in the CLO Target lumens item) of the projector over a certain period. This will eliminate uncontrolled light output drop caused by natural aging of the lamp. The light output is checked every 5 minutes, if the target is not met, the lamp power is adjusted.

  • Page 118: Clo Target

    11. Lamp menu Image 11-11 Image 11-12 Image 11-10 11.5 CLO target What must be done? The light output target for the CLO is set in this menu item. This value will be forced on the projector provided the CLO mode has been set On.

  • Page 119: Z-Axis Adjustment

    11. Lamp menu These parameters are useful when calling for a service intervention. How to display? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Lamp and press ENTER. 3. Use the ▲ or ▼ key to select Identification and press ENTER. The identification overview is displayed.
  • Page 120 11. Lamp menu R59770179 FLM R22+ 15/03/2010...

  • Page 121: Alignment Menu

    12. Alignment menu 12. ALIGNMENT MENU About this chapter This chapter describes the alignment of the projector once the physical installation is finished. Via the software, the image will be perfectly aligned on the screen. Overview • Overview flow • Orientation •...

  • Page 122: Orientation

    12. Alignment menu Level 1 Level 2 Level 3 Gamma Internal patterns Checker board Color bars Convergence Focus Full screen black Full screen blue Full screen green Full screen red Full screen white Hatch Outline Color space Projector SMPTE Custom ScenergiX Status White level...

  • Page 123: Lens Adjustment

    12. Alignment menu Image 12-3 Image 12-1 Image 12-2 For more information about the physical installation, see chapter “General”, “Projector configurations”. 12.3 Lens adjustment Quick way to enter the lens adjustment setting; press the lens button on the local keypad or the remote control. Access to the lens adjustments 1.

  • Page 124: Side Keystone

    12. Alignment menu 2. Use the ▲ or ▼ key to zoom the lens. Use the ◄ or ► key to focus the lens. 3. Press ENTER to go to the shift adjustments. Lens shift 1. Use the ▲ or ▼ key to select Shift and press ENTER or when in the Zoom/Focus menu press ENTER to toggle to the Shift menu. Image 12-10 Image 12-9 2.

  • Page 125: Warp Geometry Settings

    12. Alignment menu 2. Use the ▲ or ▼ key to select Alignment and press ENTER. 3. Use the ▲ or ▼ key to select Side keystone and press ENTER. The keystone dialog box appears. 4. Use the ◄ or ► key to adjust the keystone of the image. When the upper part of the image is wider than the lower part of the image, push the ◄...

  • Page 126: Warp Status

    12. Alignment menu Image 12-16 Image 12-17 Example 1 : distorted image Example 2 : distorted image The Warp functions can slow down the switching from one source to another when Input locking is set to automatic and there is a difference in frequency between both sources. 12.5.2 Warp Status Different modes The warp distortion can have 3 states:...

  • Page 127: Horizontal Keystone Correction

    12. Alignment menu 12.5.3 Horizontal keystone correction What can be done? Horizontal keystone adjustment is used to align the image if the projector is mounted at a non standard projection angle. In some cases, horizontal keystone has to be used in combination with vertical keystone. When adjusting the keystone adjustment, the aspect ratio of the image is not changed.

  • Page 128: Vertical Keystone Correction

    12. Alignment menu Image 12-25 12.5.4 Vertical keystone correction What can be done ? Vertical keystone adjustment is used to align the image if the projector is mounted at a non standard projection angle. In some cases, vertical keystone has to be used in combination with horizontal keystone. When adjusting the keystone adjustment, the aspect ratio of the image is not changed.

  • Page 129: Rotation

    12. Alignment menu Image 12-27 Image 12-28 Image 12-29 Image 12-30 12.5.5 Rotation What can be done ? A rotation is used to turn the image on the projection surface when the projector is slightly rotated around its axes. Image 12-31 Rotation How to rotate 1.

  • Page 130: Pincushion - Barrel Correction

    12. Alignment menu Image 12-32 Image 12-33 Image 12-34 Image 12-35 12.5.6 Pincushion - Barrel correction What can be done ? A barrel distortion or pincushion distortion can adjusted so that a normal image is displayed. Positive adjustments introduce more barrel distortion.

  • Page 131: Corner Correction

    12. Alignment menu Image 12-37 Image 12-38 Image 12-39 Image 12-40 12.5.7 4 corner correction What can be done ? Each corner of the image can be moved individually in the X and Y direction to correct a distortion. Take in account that the aspect ratio can be changed while moving one of the corners.

  • Page 132: Reset Warp Settings

    12. Alignment menu 5. Use the ▲ or ▼ key to select a corner and press ENTER. 6. Use ▲ or ▼ key to move the selected point in the X position and use ◄ or ► key to move the selected point in the Y position. Image 12-42 Image 12-43 Image 12-44...

  • Page 133: Load Warp File

    12. Alignment menu Image 12-47 Image 12-48 Image 12-49 12.5.9 Load warp file What can be done ? Special corrections which are not possible with the functions inside the projector are possible by loading a file which contains these corrections. This file should be created on an external computer and then stored on the projector using Projector Toolset. For more information about a free download of Projector Toolset, see "Free download of Projector Toolset", page 18.

  • Page 134: Contrast Enhancement

    12. Alignment menu Image 12-54 12.6 Contrast enhancement Purpose Increase the contrast for all video and data sources. How to change 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Alignment and press ENTER. 3.

  • Page 135: How To Adjust The Blanking

    12. Alignment menu Which blanking adjustments are available ? • top blanking • bottom blanking • left blanking • right blanking Image 12-59 Blanking Top blanking Bottom blanking Left blanking Right blanking The reset function brings all blanking settings back to zero. How to adjust the blanking? 1.

  • Page 136: Gamma

    12. Alignment menu 12.8 Gamma About Gamma Gamma is an image quality enhancement function that offers a richer image by brightening the already darker portions of the image without altering the brightness of the brighter portions (contrast feeling enhanced). How to adjust gamma? 1.

  • Page 137: Color Space

    12. Alignment menu The selected pattern is displayed. The following patterns are available: Checker board Color bars Convergence Focus Full screen black Full screen blue Full screen green Full screen red Full screen white Hatch Outline Purity ScenergiX 12.10 Color space Color space A color space or color standard is a mathematical representation for a color.

  • Page 138: Scenergix

    12. Alignment menu 6. When custom is selected, use the ► key to view the details. To adjust the custom values, select the desired color point using the ▲ or ▼ key and change the value with ◄ or ► key until the desired value is reached. When finished, press EXIT to return. Image 12-72 12.11 ScenergiX Overview...

  • Page 139: Preparations

    12. Alignment menu Adjustable overlapping area Light output per image 100% image 1 image 2 Total composite light output 100% image 1 image 2 Image 12-74 ScenergiX Basic Principle 12.11.2 Preparations ScenergiX Preparations To ensure proper ScenergiX adjustment, be sure that the following adjustments are done perfectly on all projectors: •...

  • Page 140: Scenergix Overlap Zone (Horizontal Scenergix)

    12. Alignment menu 12.11.4 ScenergiX overlap zone (horizontal ScenergiX) Definitions Image 12-78 ScenergiX set up Overlap : number of pixels that overlap Horizontal resolution of 1 projector Total horizontal screen resolution : [(horizontal resolution of 1 projector) x 2] minus overlap. Horizontal Resolution source : number of active pixels of the source.

  • Page 141: Scenergix Overlap Zone (Vertical Scenergix)

    12. Alignment menu How to set for the second projector 1. Go to Layout → Main window → Size 2. Enter the value for the Width as follow: Total horizontal screen resolution / 2 - 0.5 x overlap zone. 3. Position = original start + horizontal width of projector 1 - overlap zone Image 12-85 Image 12-84 Image 12-83...
  • Page 142 12. Alignment menu How to set for the first projector 1. Go to Layout → Main window → Size 2. Enter the value for the Height as follow: Total Vertical screen resolution / 2 - 0.5 x overlap zone. 3. Position remains the same. Image 12-91 Image 12-90 Image 12-89...

  • Page 143: Scenergix Size Adjustment (White Level)

    12. Alignment menu Image 12-97 Image 12-96 12.11.6 ScenergiX size adjustment (White level) What can be done with the white level menu? The white level menu contains top, bottom, left or right item to set the blending zone. The ScenergiX menu items are only accessible when status is [On]. How to set the blending zone? 1.
  • Page 144 12. Alignment menu A pattern with the different areas is displayed. Image 12-102 Width selections 6. Use the cursor keys to move the border of the overlap area to the desired position. Set first the width for the first projector and repeat for the second one. Image 12-103 Width set up for projector 1 R59770179 FLM R22+ 15/03/2010...

  • Page 145: Adjusting The Black Level Of The Images

    12. Alignment menu Image 12-104 Width set up for projector 2 12.11.7 Adjusting the black level of the images Why black level adjustment For dark images, the overlap zone will be brighter then the rest of the images. Typically for DLP projectors, next to the overlap zone, a brighter area is recognized.
  • Page 146 12. Alignment menu 5. Use the ▲ or ▼ key to select one of the four size adjustments and press ENTER. Image 12-108 Image 12-106 Image 12-107 Image 12-109 Image 12-110 DLP leakage area Overlap area DLP Leakage area 6. Use the cursor keys to move the green border line to the desired position. R59770179 FLM R22+ 15/03/2010...

  • Page 147: How To Adjust

    12. Alignment menu The leakage area for this overlap is defined and will be excluded during black level adjustment. How to adjust 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Alignment and press ENTER. 3.
  • Page 148 12. Alignment menu R59770179 FLM R22+ 15/03/2010...

  • Page 149: Projector Control

    13. Projector control 13. PROJECTOR CONTROL About this chapter This chapter explains the setup of the control part of the software such as projector address and all types of communication with the external world. Overview • Overview flow • Projector address •...

  • Page 150: Projector Address

    13. Projector control Level 1 Level 2 Level 3 Shortcut keys Menu position Menu Bar scale Local LCD Local LCD time out Local LCD contrast Language English Français Deutsch Español Italiano 13.2 Projector address Overview • Individual projector address • Common address 13.2.1 Individual projector address About individual projector address...

  • Page 151: Common Address

    13. Projector control Image 13-3 Image 13-2 Image 13-1 Image 13-4 13.2.2 Common address About common address A common address can be ’0’ or ’1’. Any command coming from a remote control programmed with that common address will be executed. How to change the common address? 1.

  • Page 152: Serial Communication

    13. Projector control Image 13-8 13.3 Serial communication Overview • Baud rate setup • Interface standard • RS422 termination 13.3.1 Baud rate setup What can be done? The baudrate for a serial connection with a computer can be set up. How to set up? 1.

  • Page 153: Rs422 Termination

    13. Projector control 3. Use the ▲ or ▼ key to select Serial communication and press ENTER. The serial communication menu opens. 4. Use the ▲ or ▼ key to select Interface standard and press ENTER to toggle between [RS232] or [RS422].. Default: [RS232] Image 13-14 Image 13-13...

  • Page 154: Introduction To A Network Connection

    13. Projector control 13.4.1 Introduction to a Network connection DHCP Dynamic host configuration protocol. DHCP is a communications protocol that lets network administrators manage centrally and automate the assignment of IP addresses in an organization’s network. Using the Internet Protocol, each machine that can connect to the Internet needs a unique IP address.

  • Page 155: Ip-Address Set Up

    13. Projector control [ON] = DHCP is activated. Automatic assigning of an address is activated. [OFF ] = DHCP is deactivated. A fixed address will be used. Image 13-20 Image 13-19 Image 13-18 13.4.3 IP-address set up How to set up? 1.

  • Page 156: Default Gateway Set Up

    13. Projector control 2. Use the ▲ or ▼ key to select Projector control and press ENTER. 3. Use the ▲ or ▼ key to select Network and press ENTER. The Ethernet menu opens. 4. Use the ▲ or ▼ key to select Subnet mask and press ENTER to select. Note: An address contains 4 octets with a maximum value of 255.

  • Page 157: Ir Control Switching

    13. Projector control Image 13-31 Image 13-30 Image 13-29 Image 13-32 6. Press EXIT to return. 13.5 IR control switching What can be done? Each IR receiver inside the projector can be activated or deactivated. When an IR receiver is deactivated, no IR signal send to this IR receiver will be processed.

  • Page 158: Dmx Address

    13. Projector control Overview • DMX address • DMX universe • DMX monitor • DMX mode • Art-Net activation • Home lens at startup Art-Net DMX When using a DMX console compatible with Art-Net, the Ethernet network serves as the link for DMX control. Make sure that your lighting desk and all projectors are within the same IP address range.

  • Page 159: Dmx Monitor

    13. Projector control How to set a DMX universe 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Projector control and press ENTER. 3. Use the ▲ or ▼ key to select ART DMX and press ENTER. 4.

  • Page 160: Dmx Mode

    13. Projector control Image 13-46 Image 13-45 Image 13-44 Image 13-47 When selecting DMX monitor and no DMX device is connected, the message “No DMX data, check connection <ENTER> to display channels” appears on the screen. When ENTER is pressed the same window appears as DMX Monitor but without values.

  • Page 161: Art-Net Activation

    13. Projector control Image 13-50 Image 13-49 Image 13-48 13.6.5 Art-Net activation What can be done ? DMX via Art-Net can be activated [On] or blocked [Off]. Default value : off How to toggle 1. Press MENU to activate the menus. 2.

  • Page 162: Buttons

    13. Projector control [On] : home lens will be executed during power on. [Off] : home lens will not be executed during power on. Image 13-56 Image 13-54 Image 13-55 13.7 Buttons Functionality Some buttons on the RCU or local keypad can have a different functionality depending on the need of the projector owner. Overview •...

  • Page 163: Apa (Auto) Button

    13. Projector control 13.7.2 APA (auto) button What can be done? The function of the APA (auto) button can be configured according the wishes of the user. The function can be: • Align only (only aligning of the preview window is executed) •...

  • Page 164: Menu Position

    13. Projector control Image 13-66 13.8 Menu position Overview • On screen menu • Bar scale 13.8.1 On screen menu What is possible? The on screen menu can be positioned on 3 different places on the screen but always vertically centered on the screen. The horizontal position can be: •...

  • Page 165: Bar Scale

    13. Projector control 13.8.2 Bar scale What is possible? The bar scale can be positioned on 3 different places on the screen but always vertically on the right side. The horizontal position can be: • Centered • Top aligned • Bottom aligned Brightness: 60 Brightness: 60...

  • Page 166: Local Lcd Contrast

    13. Projector control Image 13-77 Image 13-76 Image 13-75 13.9.2 Local LCD contrast What is possible? The contrast of the local LCD can be adapted the needs of the environment. How to change? 1. Press MENU to activate the menus. 2.

  • Page 167: How To Change The Language

    13. Projector control The following languages are available: • English • French • German • Spanish • Italians All available languages are indicated in the language of the country. The current active language is indicated by an asterisk (*). How to change the language 1.
  • Page 168 13. Projector control R59770179 FLM R22+ 15/03/2010...

  • Page 169: Service Menu

    14. Service menu 14. SERVICE MENU About this chapter This chapter refers to the Service menu in which the customer can find valuable information when calling the Barco help desk. Overview • Overview flow • Identification • Diagnosis • Convergence •...

  • Page 170: Identification

    14. Service menu 14.2 Identification What can be seen on the identification screen? The identification screen shows the general information about the projector. The following items will be displayed: • Projector address • Type of projector • Package • Configuration •...

  • Page 171: Diagnosis

    14. Service menu 14.3 Diagnosis What can be seen? The diagnosis menu gives the possibility to get an overview of the working of the projector. 14.3.1 How to start up the diagnosis? Start up 1. Press MENU to activate the menus. 2.

  • Page 172: Voltages

    14. Service menu Image 14-11 Use the ▲ or ▼ item in the menu to select the previous or next page with information. 14.3.3 Voltages How to display an overview? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Service and press ENTER. The service window opens.

  • Page 173: I²C Diagnosis

    14. Service menu Use the ▲ or ▼ item in the menu to select the previous or next page with information. 14.3.4 I²C diagnosis How to select? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Service and press ENTER. The service window opens.

  • Page 174: Fan Speeds Overview

    14. Service menu The Temperature overview menu will be displayed. Image 14-22 Image 14-20 Image 14-21 Image 14-23 Use the ▲ or ▼ item in the menu to select the previous or next page with information. 14.3.6 Fan speeds overview How to get an overview? 1.

  • Page 175: Spi

    14. Service menu Image 14-26 Image 14-24 Image 14-25 Image 14-27 Use the ▲ or ▼ item in the menu to select the previous or next page with information. 14.3.7 SPI How to get an overview 1. Press MENU to activate the menus. 2.

  • Page 176: Error Logging Overview

    14. Service menu Image 14-31 14.3.8 Error logging overview How to get an overview? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Service and press ENTER. The service window opens. 3. Use the ▲ or ▼ key to select Diagnosis and press ENTER. The diagnosis screen will be displayed.

  • Page 177: Internal Service Patterns

    14. Service menu The convergence pattern is displayed. Press ENTER to toggle to another pattern. Press EXIT to return to the menu. Image 14-37 Image 14-35 Image 14-36 5. To adjust the convergence of the selected pattern, use the ◄ or ► for a horizontal adjustment and ▲ or ▼ for a vertical adjust- ment.

  • Page 178: Restore Factory Defaults

    14. Service menu The internal service pattern window opens. 4. Use the ▲ or ▼ key to select the desired patterns and press ENTER. When a pattern is selected, press ENTER to toggle to other patterns of the selected type. Press EXIT to return to the internal service pattern menu.

  • Page 179: Reset Formatter

    14. Service menu How to return to the default settings 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Service and press ENTER. The service window opens. 3. Use the ▲ or ▼ key to select Restore factory defaults and press ENTER. The factory defaults confirmation window opens.

  • Page 180: Save Custom Settings

    14. Service menu 14.8 Save custom settings What is done? The current custom settings can be saved to the internal backup device in the same way as it would be done when the projector was switched to standby. How to save 1.

  • Page 181: Broadcast Mode

    14. Service menu Yes will switch the projector in refill mode. When No is selected, the projector stays in normal mode. Image 14-56 Image 14-54 Image 14-55 AUTION Restart of the projector is necessary to terminate the refill mode. Before restarting, switch off the projector and reinstall first the cooling circuit.

  • Page 182: Usb Memory

    14. Service menu When Broadcast mode ON, switch also Genlock to ON (Input → Input locking → Automatic + Options) and enter the correct values for this source. 14.11 USB memory What is possible with an USB device? An USB device, FAT 16 formatted can be used, to save custom settings from the projector or to load custom settings to the projector. This function is very handy to clone projectors.
  • Page 183 14. Service menu The custom settings on the projector are stored on the USB device together with the serial number of the projector. Different saves can be made from different projectors on the same USB device. When there is no USB device connected to the USB slot, a message, No USB device found, is displayed. Image 14-61 Image 14-59 Image 14-60...
  • Page 184 14. Service menu R59770179 FLM R22+ 15/03/2010...

  • Page 185: Maintenance

    15. Maintenance 15. MAINTENANCE About this chapter This chapter contains detailed maintenance procedures like dust filter replacement, lens cleaning etc. These procedures can easily be performed by the operator of the projector. AUTION All HEPA filters of the projector must be replaced on a regular basis, depending on the environment conditions of the projector.

  • Page 186: Replacement Of The Dust Filter On The Bottom Side

    15. Maintenance AUTION Never install a used HEPA filter. Always install a new HEPA filter. 15.2 Replacement of the dust filter on the bottom side Necessary parts • New HEPA dust filter for the bottom side (R9854480). • 2.5 mm Allen key. How to replace the HEPA dust filter on the bottom side of the projector ? 1.

  • Page 187: Replacement Of The Dust Filter On The Top Side

    15. Maintenance Image 15-4 7. Reinstall the side cover of the projector, see "Installation of the side cover", page 197. AUTION Never install a used HEPA filter. Always install a new HEPA filter. 15.3 Replacement of the dust filter on the top side Necessary parts New HEPA dust filter for the top side (R9854480).

  • Page 188: Cleaning The Lens

    15. Maintenance 2. Check the pressure indicated on the internal manometer of the liquid cooling circuit. Image 15-6 3. This pressure should be between 0,5 and 1 bar. If the pressure, indicated on the manometer, is out of range, inform the respon- sible and qualified technicians, so they may take necessary corrective action.

  • Page 189: Servicing

    ARNING AUTION Never attempt to disassemble the lamp from its housing or to dispose of it. Return it to Barco. Due to its high internal pressure, the lamp may explode in either hot or cold states if improperly handled. Necessary tools 7 mm flat screw driver.

  • Page 190: Removal Of The Input & Communication Unit

    16. Servicing 4. Clasp the lamp house by the handles and pull the lamp house out of the projector. Image 16-2 While starting up the projector, the electronics detect if a lamp is installed. If no lamp is installed, it is not possible to start up the projector.

  • Page 191: Removal Of An Input Module

    16. Servicing Image 16-4 16.3 Removal of an input module The procedure below is applicable to all input modules of the input & communication unit of the projector. Necessary tools Phillips screw driver PH1. How to remove an input module out of the input & communication unit of the projector ? 1.

  • Page 192: Installation Of The Lamp House

    This procedure may only be performed by qualified technical service personnel. AUTION Never attempt to disassemble the lamp from its housing or to dispose of it. Return it to Barco. Due to its high internal pressure, the lamp may explode in either hot or cold states if improperly handled.

  • Page 193: Installation Of The Input & Communication Unit

    16. Servicing 4. Push the lamp house forward until it slides fully into the projector. 5. Secure the correct position of the lamp house by tightening all three spring lock screws as illustrated. Image 16-8 6. Reinstall the lamp cover of the projector, see "Installation of the lamp cover", page 198. While starting up the projector, the electronics detect if a lamp is installed.

  • Page 194: Installation Of An Input Module

    16. Servicing Image 16-9 4. Push the input & communication unit forward until you feel the connectors of the unit fit in their sockets. The back of the front plate of the unit must touch the chassis of the projector. 5.

  • Page 195: Realignment Of The Lamp In Its Reflector

    16. Servicing Image 16-11 3. Push the input module forward until you feel that the connector of the input module fit in the socket of the input slot. The back of the front plate of the module must touch the front plate of the input & communication unit. 4.
  • Page 196 16. Servicing Image 16-13 5. Switch off the projector, wait five minutes and unplug the power cord at the projector side. 6. Reinstall the cover of the lamp, see "Installation of the lamp cover", page 198. R59770179 FLM R22+ 15/03/2010...

  • Page 197: Removal Of The Projector Covers

    17. Removal of the projector covers 17. REMOVAL OF THE PROJECTOR COVERS About this chapter Most maintenance and servicing procedures demand removing one or more of the projector covers to gain access to the parts to maintain or to service. To avoid redundancy, all procedures about cover removing or installing are grouped together in this chapter. The maintenance and servicing procedures also refer to this chapter if required.

  • Page 198: Removal Of The Side Cover

    17. Removal of the projector covers Image 17-2 17.2 Removal of the side cover AUTION Remove the side cover of the projector only in a clean and dust free area. Never remove the side cover in an area which is subject to airborne contaminants such as that produced by smoke machines or similar.

  • Page 199: Removal Of The Lamp Cover

    17. Removal of the projector covers 17.3 Removal of the lamp cover ARNING This procedure may only be performed by qualified technical service personnel. Necessary tools 7 mm flat screw driver. How to remove the lamp cover of the projector ? 1.

  • Page 200: Installation Of The

    17. Removal of the projector covers Image 17-7 2. Remove the input cover from the projector doing the following: a) gently pull out the right bottom corner (A) of the input cover, b) then gently pull out the right top corner (B) of the input cover, c) then move the input cover away from the projector (C).

  • Page 201: Installation Of The Side Cover

    17. Removal of the projector covers Image 17-9 4. Secure the front cover by locking the captive screw in the middle at the bottom of the front cover. Image 17-10 5. Reinstall the rubber dust ring around the lens holder. See image 17-10. 17.6 Installation of the side cover Necessary tools 7 mm flat screw driver.

  • Page 202: Installation Of The Lamp Cover

    17. Removal of the projector covers Image 17-12 4. Secure the side cover by locking the captive screw in the middle at the bottom of the side cover. Image 17-13 17.7 Installation of the lamp cover Necessary tools 7 mm flat screw driver. How to install the lamp cover of the projector ? 1.

  • Page 203: Installation Of The Input Cover

    17. Removal of the projector covers 17.8 Installation of the input cover Necessary tools 7 mm flat screw driver. How to install the input cover of the projector ? 1. Install the input cover of the projector doing the following: a) Bring the input cover towards its final position (A), b) then gently push the locking stud at the right top corner (B) into its receiver, c) then gently push the locking stud at the right bottom corner (C) into its receiver.
  • Page 204 17. Removal of the projector covers R59770179 FLM R22+ 15/03/2010...

  • Page 205: Dimensions

    18. Dimensions 18. DIMENSIONS Overview • Dimensions of the FLM R22+ • Dimensions of the FLM flight case • Dimensions of the rigging clamps 18.1 Dimensions of the FLM R22+ Dimensions 14.8 676.1 771.1 Image 18-1 Dimensions given in millimeters. R59770179 FLM R22+ 15/03/2010...

  • Page 206: Dimensions Of The Flm Flight Case

    18. Dimensions Point of gravity Image 18-2 Dimensions given in millimeters. 18.2 Dimensions of the FLM flight case Dimensions 1194 1175 Image 18-3 Dimensions given in millimeters. R59770179 FLM R22+ 15/03/2010...

  • Page 207: Dimensions Of The Rigging Clamps

    18. Dimensions 18.3 Dimensions of the rigging clamps Dimensions SW17 26.5 Image 18-4 Dimensions given in millimeters. R59770179 FLM R22+ 15/03/2010...
  • Page 208 18. Dimensions R59770179 FLM R22+ 15/03/2010...

  • Page 209: Standard Source Files

    19. Standard Source Files 19. STANDARD SOURCE FILES 19.1 Table overview Table overview The following standard image files are pre-programmed in the projector. Name Fvert FHor Fpix Ptot Pact Ltot Lact 640x350@85 85,079 37,860 31,500 640x400@85 85,079 37,860 31,500 640x480@60 59,940 31,668 25,175...
  • Page 210 19. Standard Source Files Name Fvert FHor Fpix Ptot Pact Ltot Lact 1400x1050RB@60 59,946 64,742 100,997 1560 1400 1080 1050 1600x1200@60 60,001 75,002 162,004 2160 1600 1250 1200 1600x1200@65 64,998 81,248 175,496 2160 1600 1250 1200 1600x1200@70 69,997 87,497 188,993 2160 1600 1250...

  • Page 211: Dmx Chart

    20. DMX chart 20. DMX CHART Overview • DMX chart, basic • DMX chart, Extended • DMX chart, Full 20.1 DMX chart, basic Overview Chan- Function Value Action Intensity 0 - 5 Mechanical shutter 0 - 255 Electronic contrast Function selection 0 - 7 no function 8 - 15...

  • Page 212: Dmx Chart, Extended

    20. DMX chart 20.2 DMX chart, Extended Overview Chan- Function Value Default Actions Intensity 0 - 5 Mechanical shutter closed 0 - 255 Contrast 0 - channel 3 Brightness 0 - 255 Adjusts the brightness between 0 and 100% (SLM/XLM doesn’t adjust on DVI) Contrast 0 - 255...

  • Page 213: Dmx Chart, Full

    20. DMX chart Chan- Function Value Default Actions Zoom (LSB) 0 - 255 Fine zoom adjustment Control 0 - 7 Lamp power 100% 8 - 15 Lamp power 98% 16 - 23 Lamp power 96% 24 - 31 Lamp power 94% 32 - 39 Lamp power 91% 40 - 47...
  • Page 214 20. DMX chart Chan- Function Value Default Action Input selection 0 - 7 No function 8 - 15 Layout 1 (execution takes 5 sec) 16 - 23 Layout 2 (execution takes 5 sec) 24 - 31 Layout 3 (execution takes 5 sec) 32 - 39 Layout 4 (execution takes 5 sec) 40 - 47...
  • Page 215 20. DMX chart Chan- Function Value Default Action Lamp Power 0 - 26 Powered at 100% 27 - 52 Powered at 98% 53 - 79 Powered at 96% 80 - 105 Powered at 94% 106 - 131 Powered at 91% 132 - 157 Powered at 89% 158 - 183...
  • Page 216 20. DMX chart R59770179 FLM R22+ 15/03/2010...

  • Page 217: Troubleshooting

    21. Troubleshooting 21. TROUBLESHOOTING 21.1 Error codes Overview When the error code is preceded by a ’-’ sign, then the error means a real error for the projector. When the error code is preceded by a ’+’ sign, then the error code means a warning. The projector does not fail yet, but take care for the warning and try to resolve the problem.
  • Page 218 21. Troubleshooting Error Description Error Warning Action Caused by code 2802 LPS start failed LPS (address 0x28) Replace LPS 2203 BOOST start LPS (address 0x20) Replace LPS failed 2503 BOOST start LPS (address 0x22) Replace LPS failed 2803 BOOST start LPS (address 0x28) Replace LPS failed...
  • Page 219 21. Troubleshooting Error Description Error Warning Action Caused by code 7694 Red front DMD High temperature on red DMD Check if air slots are free. temp high Clean air filters. If problem persists, call a qualified service engineer 7693 Red front DMD Temperature sensor on Red DMD Call a qualified service engineer temp open...
  • Page 220 21. Troubleshooting Error Description Error Warning Action Caused by code 7664 Blue block High temperature on blue DMD Check if air slots are free. temp high cooling block Clean air filters. If problem persists, call a qualified service engineer 7663 Blue block Temperature sensor on blue DMD Call a qualified service engineer...
  • Page 221 21. Troubleshooting Error Description Error Warning Action Caused by code 7980 Blue DMD high temperature on dmd check if air slot are free; clean air temp high filters If problem persists, call a qualified service engineer 7978 Lamp temp high temperature lamp check if air slot are free;...
  • Page 222 21. Troubleshooting Error Description Error Warning Action Caused by code 7954 VTEC voltage supply voltage for DMD cooling too If problem persists, call a qualified high high service engineer 7953 VMTR voltage supply voltage for motors too low If problem persists, call a qualified service engineer 7952 VMTR voltage...
  • Page 223 21. Troubleshooting Error Description Error Warning Action Caused by code 9398 Maximum Reaching the maximum allowed Delete some unnecessary files image files number of files reached 10498 Unsupported Module with obsolete firmware Call a qualified service engineer module R59770179 FLM R22+ 15/03/2010...
  • Page 224 21. Troubleshooting R59770179 FLM R22+ 15/03/2010...

  • Page 225: Specifications

    22. Specifications 22. SPECIFICATIONS Overview • Specifications FLM R22+ • Specifications FLM 5 cable input (multi purpose) • Specifications FLM HDSDI – SDI input • Specifications FLM DVI input • Specifications FLM DVI HDCP input 22.1 Specifications FLM R22+ Overview Light Output 22.000 Center Lumen Resolution...

  • Page 226: Specifications

    22. Specifications Network connection 10/100 base-T Picture-in-picture 2 sources simultaneous Input source compatibility Max. input: up to QXGA (2048 x 1536) Inputs Modular Inputs: • Configurable 5 cable (BNC) • • (HD)SDI (+ loop through) Throw Ratio Lens Throw ratio TLD (HB) 0.8 0.75 TLD (HB) 1.2...
  • Page 227 22. Specifications On board display server Ethernet control standard remote control projector over ethernet via Projector Toolset Outputs HDSDI/ SDI loop out Communication • 1x RS-232C IN (D-9 connector) • 1x RS-232C OUT (D-9 connector) • 1x RS-232C IN (XLR connector) •...

  • Page 228: Specifications Flm 5 Cable Input (Multi Purpose)

    22. Specifications TLD (HB) 1.2+ R9840775 TLD (HB) 1.6 - 2.0 R9842060 R9842080 TLD (HB) 2.0 - 2.8 TLD (HB) 2.8 - 5.0 R9842100 TLD (HB) 5.0 - 8.0 R9842120 Sealed DLP™ core Standard Convergence Max allowed convergence drift is 0.5 pixel. This is checked on vertical and horizontal midlines only.

  • Page 229: Specifications Flm Hdsdi - Sdi Input

    22. Specifications Input signal R / P G / Y / VIDEO B / P H / S V / C — Component Video / (R - Y) / (B - Y) - SS composite sync or VIDEO as sync —...

  • Page 230: Specifications Flm Dvi Input

    22. Specifications Specifications • SD SMPTE 259M-C and HD SMPTE 292M input data • 2 inputs (BNC), 1 active loop-through output (BNC) of selected input • Automatic selection of active input with manual override • 10 bit digital output • Diagnostic LED’s on front panel: Green LED: Lights up in case input module is selected Yellow LED: Lights up in case sync detected...

  • Page 231: Specifications Flm Dvi Hdcp Input

    22. Specifications 22.5 Specifications FLM DVI HDCP input Input front view HDCP DVI input Sync OK Image 22-4 Specifications • DVI type: DVI-I (DVI-Integrated), but the analog signals are not supported. Single-link configuration. • Supports UXGA Resolution (1600 x 1200) (Output Pixel Rates up to 165 MHz) •...
  • Page 232 22. Specifications R59770179 FLM R22+ 15/03/2010...

  • Page 233: Order Information

    23. Order information 23. ORDER INFORMATION 23.1 Spare part order info Order info: Order info Description R9854490 FLM/SLM adaptor plate (for stacking an SLM projector upon an FLM projector). R9854420 FLM lamp house (3kW lamp included). R9854520 FLM lamp house refurbish (3kW lamp included). R9854430 5 Cable input module.
  • Page 234 23. Order information R59770179 FLM R22+ 15/03/2010...

  • Page 235: Glossary

    Glossary GLOSSARY 2:2 pull-down The process of transferring 24-frames/sec film format into video by repeating each frame (used for PAL DVD’s) as two video fields. ( AD ) 3:2 pull-down Method used to map the 24 fps of film onto the 30 fps (60 fields) or 25 fps (50 fields), so that one film frame occupies three video fields, the next two, etc.
  • Page 236 Glossary HDCP High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection developed by Intel Corporation to protect digital audio and video content as it travels across DisplayPort, Digital Visual Interface (DVI), High-Definition Multimedia Interface (HDMI), Gigabit Video Interface (GVIF), or Unified Display Interface (UDI) connections. The specification is proprietary, and implementing HDCP requires a license.

  • Page 237: Index

    Index INDEX Address Background color Program No signal Blanking Adjustment 49–50 Box content Quick set up 49–50 Brightness Lens Broadcast mode Lens functions Buttons 158–159 Lens key Auto Adjustment mode 55–57 Shortcut keys About Standby LCD display menus Local keypad Menu memory Navigation Card bus...
  • Page 238 Index Full File manipulations DMX mode File options DMX monitor Files DMX universe Rename file Download plug-in Image settings 70–76, 78–79 Download Projector Toolset Brightness Dust filter 181–183 Color saturation Bottom Color temperature Front Contrast Input balance Input balance adjusting Noise reduction Phase Error codes...
  • Page 239 Index Projector weight Screen type Maintenance Internal pattern Menu memory Selection Menu position 160–161 IR communication Bar scale IR control On screen menu Minimum delay Keystone Native resolution Navigation Adjustment mode Network 149–152 Lamp 111–115, 191 Identification DHCP Gateway Overview flow Introduction Power 112–114...
  • Page 240 Index Art-Net DMX 153–157 Replace 181–183 Art-Net activation Dust filter 181–183 DMX address Bottom DMX mode Front DMX monitor DMX universe Reset formatter Home lens at startup Restore factory defaults Buttons 158–159 Rigging clamps Rigging key Auto Quick layout selection Shortcut keys Rigging points Standby...
  • Page 241 Index Side keystone Troubleshooting Size Error codes Main window Source Connection Source files Unpacking Source selection USB memory Source switching USB port Source timings Spare parts Spare power plug Specifications 221, 224–227 Versions 5 cable input Start up DVI HDCP Volt meter DVI input Voltages...
  • Page 242 Index R59770179 FLM R22+ 15/03/2010...
  • Page 243 Revision Sheet Barco nv Media & Entertainment Division/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11, Fax: +32 56.36.88.24 E-mail: service.mne@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R59770179/04): page wrong correct R59770179 FLM R22+ 15/03/2010...

Table of Contents
