  • Page 1 F(L)35, FS35 IR, F85 ASCII Commands Protocol Reference Manual 601–0381–00/00 21/10/2015...
  • Page 2 Barco Fredrikstad AS Habornveien 53, N-1630 Gamle Fredrikstad, Norway Phone: +47 6930 4550 Fax: +47 6930 4580 Support: Support.fre@barco.com Visit us at the web: www.barco.com Printed in NO...
  • Page 3 Changes Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war- ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.

  • Page 5: Communication Settings

    Connect the projector and host using a standard straight through serial cable (host : female, projector : male). Pin 2 connects to Pin 2, Pin 3 connects to Pin 3, and Pin 5 connects to Pin 5. 601–0381–00 F(L)35, FS35 IR, F85 21/10/2015...
  • Page 6 1. Communication settings Maximum length of the RS-232 cable is 15.25m (50ft). 601–0381–00 F(L)35, FS35 IR, F85 21/10/2015...

  • Page 7: Serial Communications Protocol

    The header informs the projector (in case of transmission) or the computer (in case of reception) that a new data transfer will take place. Message body The message body defines the action to be performed. The message body is built up of several fields: 601–0381–00 F(L)35, FS35 IR, F85 21/10/2015...
  • Page 8 ASCII space Numeric Carriage address value of error Return (Hex 0x0D) Example Space POWR Space !00001 Error code Error message Description !00001 Access denied User does not have sufficient access rights to perform this command. 601–0381–00 F(L)35, FS35 IR, F85 21/10/2015...

  • Page 9: Set Commands

    :BRIG ?N’CR’ Acknowledge get minimum value brightness %001 CNTR 000000’CR’ GET commands with target Command Description Get aspect trigger behavior 16:10 :TATB ? 3 Acknowledge get aspect trigger behavior 16:10 %001 TATB 000001 ’CR’ 601–0381–00 F(L)35, FS35 IR, F85 21/10/2015...
  • Page 10 3. ASCII Command Sets Operations Command Description Platforms Level Value Target Comments supported Power POWR Power GP3, GP4 Get, Set End User 0 - power off, 1 - power on Power state GP3, GP4 End User See value table POST POST Source selection Set source abs values...
  • Page 11 3. ASCII Command Sets Picture->Advanced Horizontal positon GP3, GP4 End User Only for analog sources HPOS Get, Set VPOS Vertical position GP3, GP4 Get, Set End User Only for analog sources Frequency GP3, GP4 End User Only for analog sources FREQ Get, Set PHSE...
  • Page 12 3. ASCII Command Sets DSYG Desired Yellow Gain GP3, GP4 Get, Set End User Desired White Gain GP3, GP4 End User DSWG Get, Set DFRX Factory Desired Red X GP3, GP4 Get, Set Manufacturing Factory Desired Red Y GP3, GP4 Manufacturing DFRY Get, Set...
  • Page 13 3. ASCII Command Sets MFBX Factory Measured Blue X GP3, GP4 Get, Set Manufacturing Factory Measured Blue Y GP3, GP4 Manufacturing MFBY Get, Set MFBL Factory Measured Blue GP3, GP4 Get, Set Manufacturing Luminance Factory Measured White X GP3, GP4 Manufacturing MFWX Get, Set...
  • Page 14 3. ASCII Command Sets Installation->Lamp Eco Mode GP3, GP4 End User 0 - disable, 1 - enable ECOM Get, Set LPW1 Lamp1 Power GP3, GP4 Get, Set End User Lamp2 Power GP3, GP4 End User LPW2 Get, Set LMOD Lamp Mode GP3, GP4 Get, Set End User...
  • Page 15 3. ASCII Command Sets Settings->Set date and time Real Time Clock Hour GP3, GP4 End User RTCH Get, Set RTCM Real Time Clock Minute GP3, GP4 Get, Set End User Real Time Clock Second GP3, GP4 End User RTCS Get, Set RTCD Real Time Clock Day GP3, GP4...
  • Page 16 3. ASCII Command Sets IR control->IR adjustments IR LED power GP3 LED IR End User AUXD Get, Set GAB1 Set Gamma abs value IR channel GP3 LED IR Get, Set End User See value table GABS WUXGA sub channel mapping GP3 LED IR End User 0 - RGB->RGB, 1 - R->RGB, 2...
  • Page 17 3. ASCII Command Sets Menu navigate Menu Navigate Toggle OSD GP3, GP4 End User MENU Menu NVUP Menu Navigate Up GP3, GP4 End User Menu Navigate Down GP3, GP4 End User NVDW NVLF Menu Navigate Left GP3, GP4 End User Menu Navigate Right GP3, GP4 End User...
  • Page 18 3. ASCII Command Sets INDG Internal sensor duration value GP3 LED Power User green Internal sensor duration value GP3 LED Power User INDB blue Thermal THRM Thermal Status GP3, GP4 Power User Fan Speed 1 GP3, GP4 Power User FAN1 Fan Speed 2 GP3, GP4 Power User...
  • Page 19 3. ASCII Command Sets Lamp data Lamp data mailbox Manufacturing Data 0 - Lamp 1, 1 LMBX Get, Set - Lamp 2 LMBP Lamp data mailbox position Get, Set Manufacturing Data 0 - Lamp 1, 1 - Lamp 2 Lamp data mailbox checksum Manufacturing Data 0 - Lamp 1, 1 LMBC...
  • Page 20 3. ASCII Command Sets Value tables IABS Set source abs values Value Description VGA 1 VGA 2 DVI 1 Component HDMI 1 DVI 2 HDMI 2 Dual Head DVI Dual Head HDMI Dual Head XP2 XP2 A XP2 B SABS Set scaling abs values Value Description...
  • Page 21 3. ASCII Command Sets DSCR Desired Coords Mode Value Description RGBCMY ORIE Select Orientation abs value Value Description Desktop front Ceiling rear Desktop rear Ceiling front OSDC OSD Enable Value Description OSD off OSD show only warnings OSD on LMOD Lamp Mode Value Description...
  • Page 22 3. ASCII Command Sets LEST Status LED state Value Description Green/Blue On Green/Blue Flash Yellow On Yellow Flash Red On Red Flash DCSP Digital colorspace Value Description YPbPr 709 YpbPr 601 TRGx Trigger mode Value Description Screen Aspect TATB Aspect trigger behavior Target Description Value...
  • Page 23 3. ASCII Command Sets BAUD Trigger mode Value Description 4800 4800 9600 9600 19200 19200 38400 38400 57600 57600 115200 115200 TBOS 3D BNC sync-out signal Value Description 3D glass sync 3D display sync Passthrough FLSS Framelock signal status Value Description free running locked...
  • Page 24 3. ASCII Command Sets LVCE bit wise error code for LED voltage calibration Description Set red input voltage failed Read red ADC current failed Read red drop out voltage failed Desired red input voltage out of range Red loop count exceed max value Set green input voltage failed Read green ADC current failed Read green drop out voltage failed...
