2.2 Support SSH protocal

Logging into IP4G by SSH, users can configure IP4G by Linux command.

2.3 Console Port Access to IP4G

If it does not connect between IP4G and PC, users can try to access to IP4G by console port.
Please try to do as the following steps:
1. Connect the console port of IP4G to your PC's console port with RS232 console cable.
2. Run the HyperTerminal, and set up the console port like the following:
Bits per second: 115200
Data bits : 8
Parity: None
Stop bits: 1
Flow control: None
3. Change the IP Address by HyperTerminal
The default IP address of IP4G is 192.168.1.100. Users may have a different IP address segment
such as 192.168.10.xx. In this situation, users cann't access to IP4G by putty and browser unless
change the IP4G IP address. Users can change the IP address for IP4G by HyperTerminal to make
it in the same network segment as their LAN.
After users have accessed to IP4G by HyperTerminal, please use the following command to
change the IP address for IP4G.
root:~> ifconfig eth0 192.168.1.151(the IP address what users want to set for IP4G)
By this way, the IP address users set for IP4G is temporary, it will recover to the original default IP
address after rebooting. If users want to give a static and permanent IP address for IP4G, users can
try to set it in web GUI, for detail steps please refer to chapter 3.
