are placed onto analog lines and the PSTN, so one should strip 1 digit from the front before the
call is placed.
3. The way of outgoing calling rules works:
Every time you dial a number, asterisk will do the following in strict order:
• Examine the number you dialed.
• Compare the number with the pattern that you have defined in your first outgoing rule and if
matches, it will initiate the call using that trunk. If it does not match, it will compare the number
with the pattern that you have defined in the second outgoing rule and so on.
• Pass the number to the appropriate trunk to make the call.

4.5 Dial Plans

A DialPlan is a set of Calling Rules that can be assigned to one or more users. Please select the
Dial Plans option, Click on New DialPlan button, the following table displays the parameters of
Dial Plans .
Name Description
DialPlan Name The name of DialPlan, which is a unique label to
help you identify the dial plan
Include Outgoing Select outgoing call rule which you use
Calling Rules
Include Local Local context is used for general using
Contexts configuration.

4.6 Users

Users component is used to add or remove Analog, SIP, IAX extension.
Click on Create New User button in the web of IP4G, users can create SIP/IAX User and Analog
User.
Name Description
Extension The numbered extension
Name A character-based name for this user
DialPlan DialPlans are sets of calling rules and can be managed
form the \"Dial Plans\" panel
CallerID The Caller ID (CID) string used when this user calls
another internal user.
OutBound Caller ID that would be applied for out bound calls
CallerID from this user. Note that your ability to manipulate
your outbound Caller ID may be limited by your VoIP
provider.
Enable Check this box if the user should have a voicemail
www.atcom.cn
Type Default
Textbox DialPlan1
selected Not seclect
check box Select all
Type Default
Textbox 6001
Textbox Null
ComboBo Null
x
Textbox Null
Textbox Null
Selected Not
