Chapter 4 Configure IP4G by Web GUI

4.1 System Status

In the system status screen, it displays the functions users configured, such as: trunks, extensions,
conference and so on. The following table is the options description of trunks.
Name Description
Status The register status of trunks
Trunk The name of trunks
Type The type of trunks
Username The username of SIP/IAX trunk
Port/Hostname/IP IP Address/port
1.The register status of trunks include three kinds: Unregistered, Request Sent, Registered.
2.The type of trunks : VoIP trunk including SIP and IAX; Analog trunk; Service Provider.
The parameter of extensions in the following table:
Name Description
Extension The status of users
Name/label The name of users
Status Display voice message
Type SIP users/IAX users/Analog users
1. There are four kinds status of users, when the light of "Extension" list displays gray , means the
user does not register that is Unavailable; when the light of "Extension" list displays green ,
means the user is Free; when the light of "Extension" list displays orange , means the user is
Ringing; when the light of "Extension" list displays red , means the user is Busy.
2. Status: This parameter displays if other users leave messages, Messages : 0/0, the figure front of
" / " displays the new messages amount; the figure behind of displays the old messages
amount.

4.2 Configure Hardware

In the configure hardware page, it includes the following components: analog hardware, tone
region, advanced settings. Pay attention that some browsers do not display the configure, it is
unimportant.
Analog Hardware
When users boot the IP4G, which will detect the FXO and FXS modules automatically, the analog
hardware component displays the modules which are detected correctly.
