2.2 Support SSH protocal

Logging into IP-2G4A by SSH, you can configure IP-2G4A by Linux command.

2.3 Console Port Access to IP-2G4A

If you do not have network connection between IP-2G4A and PC, you can try to access to
IP-2G4A by console port. Please try to do as the following steps:
1. Connect the console port of IP-2G4A to your PC's console port with RS232 console cable.
2. Run your HyperTerminal, and set up the console port like the following:
Bits per second: 115200
Data bits : 8
Parity: None
Stop bits: 1
Flow control: None
3. Change the IP Address by HyperTerminal
The default IP address of IP-2G4A is 192.168.1.100. Your network may have a different IP
address segment such as 192.168.10.xx. In this situation, you cann't access to IP-2G4A by putty
and browser if you do not change the IP-2G4A IP address. So you have to change the IP address
for IP-2G4A by HyperTerminal to make it in the same network segment as your LAN.
After you have accessed to IP-2G4A by HyperTerminal, please use the following command to
change the IP address for IP-2G4A.
root:~> ifconfig eth0 192.168.1.151(the IP address what you want to set for IP-2G4A)
By this way, the IP address you set for IP-2G4A is temporary, it will recover to the original default
IP address after rebooting. If you want to give a static and permanent IP address for IP-2G4A, you
can try to set it in web GUI, for detail steps please refer to chapter 3.
