Name Description
Tone Region Select the tone region according to your
country, if it does not have your country's
name in the dropdown list, please ask your
service operator which kind of tone region is
used in your area
Module Name The name of Module
Opermode Specifies On Hook Speed, Ringer Impedance,
Ringer Threshold, current
Limiting ,TIP/RING voltage adjustment,
minimum Operational Look Current and so
on. Please choose your country or your nearest
neighboring country
a-law override Specifies the codec to be used for analog line.
fxs honor mode This option allows the user to determine if
they would like opermode characteristics
applied to trunk(FXO) modules only, or both
trunk (FXO) and station(FXS) modules.
boostringer This option allows the user to define whether
they require normal ringing voltage(40v) or
maximum ringing voltage(89v) or analog
phones attached to station(FXS) modoules
fastringer This option sometimes used in conjunction
with the Low Power Option ,allows the user to
increase the ringing speed to 25HZ
lowpower This option generally used in conjunction with
the Fast Ringer Option ,allows the user to set
the peak voltage during Fast Ringer Operation
to 50V.
ring detect This option allows the user to choose from
normal ring detection or a full wave detection
MWI mode This option allows the user to specify the type
of Message Waiting indicator detection to be
done on trunk(FXO) interfaces

4.3 Trunks

To receive calls from PSTN and make calls to the outside world, users have to use trunks. Please
select the Trunks option from the vertical menu on the left of the main page.
www.atcom.cn
Type Default
ComboBox United
Status/North
America
Textbox wctdm24xxp
ComboBox USA
ComboBox ulaw
ComboBox FXO modules
ComboBox nomal
ComboBox nomal
ComboBox nomal
ComboBox standard
ComboBox none
