3. Attension: in the textbox of Extension, the value users set is limited to a range, they can adjust
the range in the Options option to meet their requirement.

4.7 Ring Groups

Define Ring groups to dial more than one extension simultaneously, or to ring more than one
phone sequentially. This feature may also be called Hunt groups.
Please select the Ring Groups option from the vertical menu on the left of the main page, then
they can get the following screen:
Name Description
Ring Group Ring group name use in pbx
Name
Extension for Ring group No.，dial the No. if you want to join , change
this ring group boundary value in options
Ring Group The ring group of numbers
Members
Available The entire Users
Users
Strategy Ring all simultaneously:
Ring in order
Seconds to Seconds to ring each member
ring each
member
If not
If not answered go to
Operator：Go to operator 。Extension: a call to user.
answered Goto
Voicemail: Go to IVR 。Conference: join a conference.
Call queue: Go to a call queue.
1. ring group application: Dial(channel type/${EXTEN}| channel type/${EXTEN}|20|i)
2. ring group up after please a call
3. non-ring if ring group user off hook or non-user registered
4. only one man can connected in coming call

4.8 Music on hold

'Music On Hold' need users customize audio tracks for different queues, parked calls etc.
Name Description
Upload an 8 KHz Support codec: g711a/g711u
Mono Music file
New music on hold Add a new music on hold
1. Music on hold Dir: /persistent/sounds/moh/
www.atcom.cn
, hang up: hang up the calling channel。
Type default
Str*
Int 6400
{EXT1,EX
T2,EXT3,
...}
{EXT1,EX
T2,EXT3,
...}
{ Ring in Ring in
Order ,ting Order
all
Extensions
}
Time 20
{Hang-up, Hang up
Operator...
.}
Type default
Upload
