IPPBX IP01 User Manual
2) Extension Preference.
Defines the range for VOIP / FXS / Ring Group / Voice Menu / Paging Group / Conference / Queue Extensions.
The extension length must be between 3 and 9 digits. The maximum quantity can be supported for each are as
below:
VOIP extension
FXS extension
Ring Group
Voice menu/IVR
Paging Group
Conference
Queue

4. Create SIP trunk to communicate with VoIP provider

In this page, we can also configure the 'service provider' trunk, which doesn' t need the use name and
password for authorization, when you have bought a trunk from provide with IP address only, please choose
'service provider' trunk .

Create SIP trunks

4.1
Go to PBX Settings -> Trunks, Click
Type
SIP
Trunk Name
A unique label to help you identify the trunk.
100
8
9
16
9
9
9
to add a new SIP trunk.
~ 22 ~
