Page 1: User Guide
User Guide PowerMax10 Fully supervised wireless alarm control system... -
Page 2: Table Of Contents
C.6 Setting the Time & Time Format..... 25 Remote control devices ........5 C.7 Setting the Date & Date Format ..... 26 2. Operating the PowerMax10-G2 System..7 C.8 Enabling / Disabling Auto-Arming... 27 Security-Related Pushbuttons ......7 C.9 Setting the Auto-Arming Time....27 Preparing to Arm ..........7... -
Page 3: Introduction
IMPORTANT! All you need to know to secure your premises can be found in Chapter 2 of this manual. The PowerMax10-G2 is governed by a control panel (Fig. 1) designed to collect data from various sensors If you are not familiar with some of the terms used that are strategically located within and along the here, refer to Appendix A at the end of this guide. -
Page 4: Users And Codes
Figure 2. Typical System Configuration • Access from remote telephones: You may messages. If such a message is overdue, the access the PowerMax10-G2 from a remote PowerMax10-G2 displays an ‘inactivity’ trouble telephone and Arm/Disarm it or receive system message. Your installer can disable this feature if status information. -
Page 5: Internal Sounder
When enabled and system is in a state of trouble. no key is pressed for more than 30 seconds, the display will read “PowerMax10-G2” and the LEDs do not light or indicate any status. The normal display resumes when pressing the button. -
Page 6: Remote Control Devices
INTRODUCTION INDICATORS POWER CHIME TROUBLE DISPLAY NEXT MOVE BACK SHOW / OK ARMING “HOME” DISARMING ARMING “AWAY” CHIME ON/OFF CANCEL ENTRY DELAY PA RT ITIO N EVENT LOG SELECTION* EMERGENCY FIRE (hold (hold for 2 sec.) for 2 sec.) PRESS BOTH FOR PANIC ALARM * Not included in all models Figure 3. - Page 7 INTRODUCTION A. Arming the system in the INSTANT mode: The sounds you will hear while using the control panel Pressing the AUX button immediately after are: arming, during exit delay, causes the system to Single beep, heard whenever a key is be armed without an entry delay.
-
Page 8: Operating The Powermax10-G2 System
Since this operation reduces the security level, the one by one. PowerMax10-G2 will ask you to key in your master It is highly recommended to fix the open zone(s), thus user code or user code, thus making sure that you restoring the system to the state of “ready to arm”. -
Page 9: Arming Away 'Instant
OPERATING THE POWERMAX10-G2 SYSTEM PRESS RESULTANT DISPLAY Arming AWAY ‘Instant’ ENTER CODE _ _ _ _ You may arm AWAY or HOME without an entry delay - any detection in any zone will trigger an ARMING AWAY immediate alarm. If you wish to arm AWAY-INSTANT, proceed as PLEASE EXIT NOW follows. -
Page 10: Initiating A Panic Alarm
OPERATING THE POWERMAX10-G2 SYSTEM Initiating a Panic Alarm PRESS RESULTANT DISPLAY CODE _ _ _ _ You can generate a panic alarm manually in the disarmed and armed states alike. The sequence will be as shown: READY HH:MM PRESS RESULTANT DISPLAY... -
Page 11: Siren Behavior
OPERATING THE POWERMAX10-G2 SYSTEM Siren Behavior ARM indicator extinguishes and sounds once per minute, The total siren time does not exceed the maximum To find out what kind of trouble is being sensed, time as configured by the installer. see Chapter 3. The TRBL display will disappear,... -
Page 12: Reviewing Troubles And Alarm Memory
Alarm & Tamper Memory EXAMPLE 2: An alarm was triggered because the garage door - zone No. 12 – was opened and remained The PowerMax10-G2 retains in its memory alarm open. and “tamper” events that occurred during the last arming period. -
Page 13: Reviewing Memory & Troubles At The Same Time
REVIEWING TROUBLES AND ALARM MEMORY PRESS RESULTANT DISPLAY IMPORTANT! If the trouble beeps bother you, disarm the system again (even though it is already disarmed). READY HH:MM This will cancel the trouble beeps for 4 hours. Reviewing Memory & Troubles at Z09 MISSING the Same Time (alternating) - Page 14 REVIEWING TROUBLES AND ALARM MEMORY Fault What it means The control panel cannot configure or control the device. 1-WAY Battery consumption increases. A device was not installed or not installed correctly, or, cannot NOT NETWORKED establish communication with the control panel after installation. A device or detector has not reported for some time to the MISSING control panel.
-
Page 15: Menus And Functions
MENUS AND FUNCTIONS 4. Menus and Functions This chapter explains the programming features of your PowerMax10-G2 system and allows you to tailor the PowerMax10-G2 system according to your specific needs. The chapter is divided into three sections, as follows: Part A – Provides you with a general description of available User Setting options. -
Page 16: Entering The User Settings Menu & Selecting A Setting Option
MENUS AND FUNCTIONS B.1 Entering the User Settings Menu & Selecting a Setting Option The following procedure describes how to enter and move within the User Settings menu. Detailed descriptions of the User Setting options are provided at the end of the procedure. To exit the User Settings menu –... - Page 17 MENUS AND FUNCTIONS C. User Setting Options Menu To select the displayed setting option – press the button. Use to set the Zone Bypass Scheme i.e. to bypass (exclude) faulty or unsecured SET ZONE BYPASS zones, or to clear a bypassed zone (unbypass). For further details and programming procedure see section C.1.
-
Page 18: Returning To The Previous Step Or Exiting The User Settings Menu
During the setting process it is frequently necessary to return to the previous setting step or option (i.e. "to go one level up") or to exit the User Settings menu. To facilitate these actions, the PowerMax10-G2 system offers you two alternative methods to choose from. -
Page 19: Setting The Zone Bypass Scheme
♦ Here you can set the Zone Bypass Scheme i.e. to scroll through the list of registered (enrolled) sensors to your PowerMax10-G2 system and to Bypass (deactivate) faulty or disturbed sensors (either READY or NOT-READY) or to Clear (reactivate) BYPASSED zones (sensors). -
Page 20: Reviewing The Zone Bypass Scheme
MENUS AND FUNCTIONS B. To Clear a Bypassed Zone Repeat steps above. Z04: BYPASSED When the zone you wish to clear bypass appears on the display (for Z04: Kitchen example, "Z04"), press to confirm. The display now reads [<#> TO CLEAR]. <#>... - Page 21 MENUS AND FUNCTIONS Additional Information (section C.1 – C.3) For detailed instructions on how to select the Setting Options – refer to section B.1 and section B.2. a. The STATUS to the right of the zone number indicates whether the zone is READY, NOT-READY or BYPASSED.
-
Page 22: Programming User Codes
C.4 Programming User Codes The PowerMax10-G2 system allows you to authorize up to 8 people to arm and disarm the system by providing each with a unique 4 digit personal security code, and assigning them with different security levels and functionalities. - Page 23 MENUS AND FUNCTIONS a) To program or edit the code, use the numerical keypad to enter the 4 user code 4 digit code (e.g. 5327) at the position of the blinking cursor. b) When done, press to confirm. ☺ A "Happy Tune" sounds.
-
Page 24: Add / Delete Keyfob Transmitters
MENUS AND FUNCTIONS C.5 Add / Delete Keyfob Transmitters Each of the 8 PowerMax10-G2 users may be provided with a portable keyfob transmitter to exercise better, quicker and safer arming/disarming and other control functions. Each keyfob should be assigned with a serial No. - Page 25 MENUS AND FUNCTIONS To delete the keyfob press the key. ☺ A "Happy Tune" sounds and the display reads [ DELETE KEYFOB DELETE KEYFOB ☺ Additional Information (section C.6) For detailed instructions on how to select the Setting Options – refer to section B.1 and section B.2. The display shows the 1st Keyfob (Keyfob No.1) of the 8 keyfobs.
-
Page 26: Setting The Time & Time Format
MENUS AND FUNCTIONS C.6 Setting the Time & Time Format ♦ Here you can program or adjust the built-in-clock to show the correct time in the desired time format. ♦ You can select between a 24 hour and a 12 hour (AM/PM) time format. Carefully read the section titled "Additional Information"... -
Page 27: Setting The Date & Date Format
MENUS AND FUNCTIONS C.7 Setting the Date & Date Format ♦ Here you can program or adjust the built-in-calendar to show the correct date in the desired date format. ♦ You can select between a "mm/dd/yyyy" and a "dd/mm/yyyy" date format. Carefully read the section titled "Additional Information"... -
Page 28: Enabling / Disabling Auto-Arming
C.8 Enabling / Disabling Auto-Arming The PowerMax10-G2 system can be programmed to automatically arm itself on a daily basis at a predetermined time. This feature is useful especially in commercial applications, such as in stores, to ensure that the system is always armed and without having to assign security codes to employees. - Page 29 MENUS AND FUNCTIONS Additional Information (section C.07 - section C.08) For detailed instructions on how to select the Setting Options – refer to section B.1 and section B.2. a. The display shows the current setting format (indicated by a symbol), for example, " Disable ".
-
Page 30: Programming Private Phone Numbers
MENUS AND FUNCTIONS C.10 Programming Private Phone Numbers The PowerMax10-G2 system allows you to determine which event groups will be reported to private telephone subscribers. The PowerMax10-G2 system can also be programmed by the installer to report various event messages such as alarm, arming or trouble, to 4 private telephone subscribers and to 4 SMS telephone numbers either instead of or in addition to the reports transmitted to the monitoring company. - Page 31 MENUS AND FUNCTIONS b) When the desired SMS phone number appears on the display, press 4th SMS tel # to confirm. a) To program or edit the phone No. Use the numerical keypad to 032759641 enter the SMS phone number digits (e.g. 8032759333) at the position of the blinking cursor.
- Page 32 MENUS AND FUNCTIONS E. To Program the Acknowledge Signal a) From the Voice Report sub-menu, click the button until the display reads [Tel. acknowledge]. Tel. acknowledge b) When the display reads [Tel. acknowledge] press a) Click the button until the display reads the single ack desired acknowledge signal, for example, "all ack".
-
Page 33: Enabling / Disabling The Squawk Option
The PowerMax10-G2 system (and its wireless sirens) can be set to produce a short "Squawk" of audible feedback to assist you when you use your keyfob to arm (1 beep) and disarm (2 beeps) the PowerMax10-G2 system (operates in a similar manner to a car alarm). -
Page 34: Programming The Scheduler
MENUS AND FUNCTIONS C.12 Programming the Scheduler The PowerMax10-G2 system includes a Home Automation option that enables activation of a PGM output according to a programmable weekly time schedule. ♦ Here you can schedule for the PGM up to 4 different ON/OFF time activations per any desired day or days of the week. - Page 35 MENUS AND FUNCTIONS Additional Information (section C.12) For detailed instructions How to select the Setting Options – refer to section B.1 and section B.2. If you wish to activate the selected device on every day of the week at the same time(s), use the "Daily" option.
-
Page 36: Special Functions
45-second time limit. other necessities. Upon doing so, the bedroom, When the 45 seconds are up, the PowerMax10-G2 bathroom and kitchen motion detectors will detect his will disengage the line and call the next private movement. -
Page 37: Event Notifications By Sms
“ST <code>” the user! Note: House ID includes up to 16 characters, for Note: The PowerMax10-G2 may react with a delay example, JOHN'S HOUSE. to received SMS messages if a GPRS session is in progress at the same time. -
Page 38: Weekly Maintenance
WEEKLY MAINTENANCE 6. Weekly Maintenance Periodic Test The components of your security system are designed to be maintenance-free as much as possible. Nevertheless, it is mandatory to perform a “walk-test” at least once a week and after an alarm event to verify that all system detectors function properly. - Page 39 WEEKLY MAINTENANCE C. To Periodic Test a Device DEVICES TEST Press . The display reads [DEVICES TEST]. Press . The display now reads [NOT TESTED NNN]. NNN indicates the number of enrolled devices in the control panel that NOT ACTIVE NNN have not been tested.
-
Page 40: Maintenance
2. Battery connection V Lithium battery. If the battery is weak when reading Figure 10. Battery Replacement the PowerMax10-G2 event log the display will read, Caution: Battery pack connector can be can be for example, "C01 Low Battery" (meaning there is a connected in one direction only. -
Page 41: Cleaning The Control Panel
When the PowerMax10-G2 display reads [ENTER CODE: _], enter ENTER CODE: _ the current master user code. CODE The "Happy Tuns" will sound and the PowerMax10-G2 display will LIST OF EVENTS read [LIST OF EVENTS]. (see Important Note!) Click the button. -
Page 42: Exiting The Event Log
MAINTENANCE Exiting the Event Log Click the button from anywhere within the event log. The PowerMax10-G2 display will read [<OK> TO EXIT]. <OK> TO EXIT Click the button. The system reverts to the normal operating mode. READY 00:00 D-302757... -
Page 43: Appendix A. Glossary
APPENDICES APPENDIX A. GLOSSARY Control Panel: The control panel is a cabinet that This list of terms is arranged in alphabetical order. incorporates electronic circuitry Any term indicated by cursive (italic) letters within microprocessor that control the alarm system. It the explanatory text can be looked up separately. - Page 44 Status: AC fail, low battery, trouble, etc status signals to the control panel. After transmission, User Codes: The PowerMax10-G2 is designed to it stands by to sense further motion. obey your commands, provided that they are...
-
Page 45: Appendix B. Home Fire Escape Planning
APPENDICES APPENDIX B. HOME FIRE ESCAPE PLANNING • Agree on an outside meeting place where Fire can spread rapidly through your home, leaving everyone can meet after they’ve escaped. you a short time to escape safely. Your ability to get Remember to get out first, and then call for help. -
Page 46: Fcc Statement
Class B digital If the “PowerMax10-G2” causes harm to the sensor, pursuant to Part 15 of the FCC Rules. These telephone network, the telephone company will notify... - Page 47 D-302757...
- Page 48 D-302757...
- Page 49 Email: info- dach@visonic.com VISONIC IBERICA: ISLA DE PALMA, 32 NAVE 7, POLÍGONO INDUSTRIAL NORTE, 28700 SAN SEBASTIÁN DE LOS REYES, (MADRID), ESPAÑA. TEL (34) 91659-3120, FAX (34) 91663-8468. www.visonic-iberica.es www.visonic.com INTERNET ©VISONIC LTD. 2010 POWERMAX10-G2 USER GUIDE D-302757 Rev 0 (8/10)
- Page 50 Fully supervised wireless alarm control system Fully supervised reless alarm control system Fully supervised wireless alarm control system Fully pervised wireless alarm control system Fully supervised wireless alarm control system lly supervised wireless alarm control system Fully supervised wireless alarm control www.visonic.com...
