I
P
DENTIFYING
RINTER
Use the illustrations on the facing page to identify standard
parts for the SuperScript 1450 or 1450N.
Front View
•
Operator Panel—has two control buttons and four lights
(LEDs).
•
Hand Grips—used for lifting printer.
•
Top Cover—provides access to the Toner Cartridge (also
serves as the Main Output Tray).
•
Main Output Tray—holds up to 250 printed sheets.
•
Multipurpose Tray—drops open to hold various
amounts of paper, envelopes, labels, or transparencies.
Referred to as Tray 1 in the printer driver.
•
550-sheet Cassette—standard input tray. Referred to as
Tray 2 in the printer driver
•
Paper Level Indicator—a see through window showing
paper level.
14
Chapter 2, Getting Started
P
ARTS
Back View
•
Back Label—contains the printer's serial number
necessary for warranty registration.
•
Back Cover—serves as an output tray when opened.
•
Interface Panel—contains the Controller Board and any
added options such as a network interface card (NIC).
•
Power Cord Connector—for attaching the Power Cord.
•
Power Switch—for turning on and off the printer.
•
Back Vent—allows ventilation.
Back Internal View
•
Fuser Unit—uses heat and pressure to adhere image to
the paper.
•
Face-up Output Tray—receives heavier printed media.
•
Feed Roller—Feeds media to the Face-up Output Tray.
