WebScale™
interface cards.
Using a Single Network Interface Card
When installing WebScale in a system with a single network interface card (NIC), make
sure that you have read the topic on single network interface card limitations. Multicast
support is enable by default. However, if you disable multicast support, this hardware
configuration is not preferred because it limits networking performance and
functionality. However, WebScale always can be successfully configured with one
NIC.
To set the WebScale bindings for use with one network interface card:
æ
Select the Bindings tab in the Windows NT Network setup dialog.
æ
Select the bindings for the topic all protocols in the drop down list next to the
Show Bindings for: label.
You should see the following screen. It shows the correct bindings for the WebScale
driver. The instructions below explain how to set up these bindings. (In this example,
the 3Com Etherlink III Adapter is used to handle both cluster traffic and other network
traffic to the local host.)
41
User's Guide
