WebScale™
æ
Fill out the requested cluster, host, and licensing information in the dialog and
click on the Apply button to make use of the features enabled by your license key.
æ
Create port rules to specify how you want WebScale to handle network traffic for
specific TCP and/or UDP ports. Refer to the Port Rules section for more details.
æ
Click on the OK button to complete the WebScale Setup dialog.
æ
Select the Bindings tab in the Windows NT Network dialog and view the bindings
for all protocols.
æ
Bind the WebScale Driver protocol to the WebScale Virtual NIC adapter and to the
cluster adapter.
æ
Unbind the WebScale Driver protocol from the dedicated adapter (unless you are
using a single adapter, in which case you should leave the adapter bound).
æ
Bind the TCP/IP protocol and the WINS Client protocol to the WebScale Virtual
NIC adapter.
æ
Bind the TCP/IP protocol and the WINS Client protocol to the dedicated adapter
(unless you are using a single adapter, in which case you should unbind the
adapter).
æ
Unbind the TCP/IP protocol and the WINS Client protocol from the cluster adapter.
It will already be unbound if you have a single adapter.
æ
Move the WebScale Virtual NIC adapter below the dedicated adapter in the list of
adapters for the TCP/IP protocol and the WINS Client protocols.
æ
Close the Network setup dialog.
æ
Restart the computer.
After installation has been completed on all hosts in the cluster, you can control cluster
operations using the webscale.exe control program, which is described in the
Execution and Control section.
If you should need to disable the WebScale driver after installation:
æ
Unbind the WebScale Driver from all hardware adapters.
æ
Unbind the TCP/IP protocol and the WINS Client protocol from the WebScale
Virtual NIC adapter.
æ
Bind the TCP/IP protocol and the WINS Client protocol to the hardware adapters
as desired.
