WebScale™
To install the NIC and its software driver, please follow the instructions supplied by the
hardware manufacturer. Be careful that the hardware resources needed by the card,
such as interrupt request levels (IRQ's) and IO ports, do not interfere with those used by
the already installed NIC.
Step 3: Install the WebScale Driver
Because WebScale is a standard Windows NT networking driver, it can be installed,
configured and removed through the Network component of the Windows NT Control
Panel. Although its installation is straightforward, it should be performed by a system
administrator who is familiar with installing and managing networking software.
To run the Windows NT Network setup dialog:
æ
Go to Start button on your taskbar and choose Control Panel under the Settings
entry.
æ
In the Control Panel folder, double-click on the Network icon.
You can also reach Network setup dialog by right-clicking on the Network
Neighborhood icon on your desktop and then choosing Properties. The following step-
by-step instructions will guide you through the rest of the installation process:
æ
Click on the Adapters tab to see the list of installed network adapters.
At this point, the following Network dialog will appear as follows:
14
User's Guide
