Viewing Policies and Rules

Rule Editor Window

When a policy is opened from either the local files or from a switch or when a new policy is created, the
Rule Editor Window is displayed.
The following screen shows the Rule Editor Window and the elements unique to this window. They
include:
Tree Structure Panel, discussed
●
Rule Editing and Viewing Panel, discussed
●
Rule Properties Panel, discussed
●
Tree Structure Panel

Hide and Show the Panels

The different window panels can be hidden or shown by:
Clicking the up, down and side "arrow points" adjacent to the Tree Structure, and Status panels
●
Clicking the X in the upper right corner of the Rule Properties and Status panels
●
From the Menu Bar, selecting and deselecting the boxes from the View > Status Panel, Rule
●
Properties Panel, and Tool Bar submenus
When a panel is hidden using these methods, the remaining panels expand to fill the window.
26
on page 26
on page 27
on page 28
Rule Editing and Viewing Panel
Rule Properties Panel
Extreme Networks Policy Manager (EPM) 1.2 User Guide
