System Map: Model A - Front View with LCD Panel Open

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices (e.g. WLAN or
Bluetooth) aboard aircraft
is usually prohibited.
Make sure any wireless
modules are OFF if you
are using the computer
aboard aircraft.
Use the appropriate func-
tion key combination (see
Table 1 - 4, on page 1 -
11) to toggle power to any
wireless modules, and
check the LED indicators
to see if any modules are
powered on or not (see
Table 1 - 2, on page 1 -
9).
1
2
3
5
6
7
9
System Map: Model A - Front View with LCD Panel Open 1 - 7
Front View - LCD Panel Open
1. Optional Built-In PC Camera
2. LCD
3. Ap-Key Buttons
4. Power Button
5. Keyboard
6. TouchPad and Buttons
7. Audio "DJ" Controls
8. Built-In Microphone
9. Audio "DJ" LED Display
Panel (Including LED
4
Indicators)
Audio "DJ" & Power Button
Make sure that the Audio "DJ"
player is off before pressing the
8
7
power button to turn the computer
on.
Quick Start Guide
Figure 1 - 2
1
