Mainboard Overview - Top (Connectors)
Figure 9
Mainboard Top
Connectors
1. USB Port
2. LCD Cable
Connector
3. CCD Connector
4. Hotkey & LED
Connector
5. Keyboard Cable
Connector
6. TouchPad Cable
Connector
7. Speaker
Connector
1 - 10 Mainboard Overview - Top (Connectors)
1
2
4
5
6
W860CU
1
2
4
5
6
W870CU
3
7
3
7
