Summary of Contents for EUROCOM W860CU

  • Page 2 Preface Notebook Computer W860CU/W870CU Service Manual...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 4 Preface About this Manual This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W860CU/ W870CU series notebook PC.
  • Page 5 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 7: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 8: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 9 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on Disc This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 10: Table Of Contents

    Preface Contents Introduction ..........1-1 Top without Fingerprint (W860CU) ..........A-4 Bottom (W860CU) ................ A-5 Overview ..................1-1 LCD (W860CU) ................A-6 System Specifications ..............1-2 COMBO (W860CU) ..............A-7 External Locator - Top View with LCD Panel Open ......1-4 DVD-Dual Drive (W860CU) ............A-8 External Locator - Front &...
  • Page 11 Preface IBEXPEAK - M 8/9 ..............B-19 W870CU Multi I/O Board ............B-51 IBEXPEAK - M 9/9 ..............B-20 W870CU CIR Board ..............B-52 Clock Generator ................B-21 W870CU LED Board ..............B-53 Panel, Inverter ................B-22 W870CU RJ11 & TV Board ............B-54 DVI ....................

  • Page 12: Introduction

    Introduction Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W860CU/W870CU series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer. Operating systems (e.g.

  • Page 13: System Specifications

    Introduction System Specifications Memory Storage Processor Two 64-bit Wide DDRIII (DDR3) Data One Changeable 12.7mm(h) Optical Device Intel® Core i7-820QM Processor: Channels (CD/DVD) Type Drive (see Factory Options 1.73GHz for All Models on page 1-3) Two 204 Pin SO-DIMM Sockets Supporting 45nm (45 Nanometer) Process Technology, DDRIII (DDR3) 1333MHz For W860CU...
  • Page 14 Introduction Audio Communication Environmental Spec High Definition Audio Compliant Interface Built-In 56K Fax Modem V.90 & V.92 Compliant Temperature ° ° 3D Stereo Enhanced Sound System Operating: C - 35 Built-In 10/100/1000Mb Base-TX Ethernet LAN S/PDIF Digital Output Non-Operating: -20°C - 60°C Intel®...

  • Page 15: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Optional Built-In PC Camera 2. LCD 3. Power Button 4. Speakers 5. LED Hot Key Buttons 6. LED Status Indicators 7. Keyboard 8. Built-In Microphone 9.

  • Page 16: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power Indicators 2. Consumer Infrared Transceiver (for W860CU Optional TV Tuner) W870CU Figure 3 Right Side Views 1. Headphone-Out W860CU Jack 2. Microphone-In Jack 3. Line-In Jack 4.

  • Page 17: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. RJ-11 Modem Jack 2. USB 2.0 Port W860CU 3. Mini-IEEE 1394 Port 4. 7-in-1 Card Reader 5. Optical Device W870CU Drive Bay (for DVD Device) 6.

  • Page 18: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Component Bay Cover 3. Vent/Fan Intake/ Outlet 4. Speaker  Overheating W860CU W870CU To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use.

  • Page 19: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. South Bridge 2. KBC ITE IT8502E W860CU W870CU 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 20: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Card Reader Socket 3. Memory Slots DDR3 SO-DIMM 4. Mini-Card Connector (3G Module for W860CU and TV Module for W870CU) 5.

  • Page 21: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. USB Port 2. LCD Cable Connector 3. CCD Connector 4. Hotkey & LED Connector 5. Keyboard Cable Connector 6. TouchPad Cable W860CU Connector 7. Speaker Connector W870CU 1 - 10 Mainboard Overview - Top (Connectors)

  • Page 22: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. USB Port 2. CPU Fan Cable Connector 3. BT Cable Connector 4. CD-ROM Connector 5. System Fan Cable Connector 6. VGA Fan Cable Connector 7. HDD Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 23 Introduction 1 - 12...

  • Page 24: Disassembly

    Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W860CU/W870CU series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. Procedures such as upgrading/replacing the RAM, optical device and hard disk are included in the User’s Manual but are repeated here for your convenience.

  • Page 25: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 26: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 27: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Bluetooth Module: 1. Remove the battery page 2 - 5 1.

  • Page 28: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Slide the latch in the direction of the arrow. Battery Removal 3. Slide the latch in the direction of the arrow, and hold it in place. 4.

  • Page 29: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 30 Disassembly 5. Lift the hard disk assembly out of the computer in the direction of arrow Figure 3 6. Remove the screws and the cover bracket from the harddisk HDD Assembly 7. Reverse the process to install a new hard disk (do not forget to replace all the screws and covers). Removal (cont’d.) c.
  • Page 31 Disassembly Removing the Hard Disk(s) in the Secondary HDD Bay (W870CU only) Figure 4 1. Turn off the computer, and turn it over and remove the battery. Secondary HDD 2. Locate the component bay cover and remove screws Assembly Removal 3.

  • Page 32: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 5 Optical Device 1. Turn off the computer, and remove the battery (page 2 - Removal 2. Locate the component bay cover and remove screws (W860CU) or (W870CU). 3. Carefully remove the component bay cover a.

  • Page 33: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 6 The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting RAM Module Removal DDR3 1333MHz. The main memory can be expanded up to 4GB. The SO-DIMM modules supported are DDRIII 1GB, and 2GB Modules.

  • Page 34: Remove The Battery

    Disassembly 5. Gently pull the two release latches & on the sides of the memory socket in the direction indicated by the Figure 7 arrows (Figure 7c). RAM Module Removal (cont’d.) c. Pull release latch(es). d. Remove the module(s). 6. The RAM module(s) will pop-up (Figure 7d), and you can then remove it.

  • Page 35: Removing And Installing The Processor

    Disassembly Removing and Installing the Processor Figure 8 Processor Removal Procedure Processor Removal 1. Turn off the computer, remove the battery (page 2 - 5), and component bay cover (page 2 - 10). & 2. Remove the CPU heat sink screws in the order (the reverse order as indicated on the label).
  • Page 36 Disassembly 4. Turn the release latch towards the unlock symbol , to release the CPU (Figure 9a). Figure 9 5. Carefully (it may be hot) lift the CPU up out of the socket (Figure 9b). Processor Removal 6. See page 2 - 14 for information on inserting a new CPU.
  • Page 37 Disassembly Processor Installation Procedure Figure 10 Processor 1. Insert the CPU , pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE IT!), and Installation turn the release latch towards the lock symbol (Figure 10b).

  • Page 38: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 11 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard.

  • Page 39: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 12 Bluetooth Module 1. Turn off the computer, remove the battery (page 2 - 5), and component bay cover (page 2 - 10). Removal 2. Locate the Bluetooth module, and remove the screw 3. Carefully separate the Bluetooth module from the connector and disconnect the cable a.

  • Page 40: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 13 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - 2. Locate the 3G module cover, and remove the screw a. Remove the screw. 3. Remove the 3G module cover and carefully disconnect the cable and remove the screw from the 3G...

  • Page 41: Removing The Keyboard (W860Cu)

    Disassembly Removing the Keyboard Figure 14 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 5), component bay cover (page 2 - 10), and processor (page 2 - 12). a. Press at point 1 to un- 2.
  • Page 42 Disassembly 8. W870CU: Remove the screw and press at point to unsnap the the hinge cover module. Figure 15 9. Turn the computer over, open the Lid/LCD and lift the hinge cover module and disconnect the cables & Keyboard Removal 10.
  • Page 43 Disassembly 2 - 20...

  • Page 44: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the W860CU/W870CU series notebook’s construction into a series of illustrations. The com- ponent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 45: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts W860CU W870CU Top with Fingerprint page A - 3 page A - 9 Top without Fingerprint page A - 4 page A - 10 Bottom...

  • Page 46: Top With Fingerprint (W860Cu

    Part Lists Top with Fingerprint (W860CU) Figure A - 1 Top with Fingerprint (W860CU) 壓克力 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 頭徑 頭厚 號 無鉛 無鉛 無鉛 黑色 無鉛 無鉛 無鉛 無鉛 頭厚 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛...

  • Page 47: Top Without Fingerprint (W860Cu

    Part Lists Top without Fingerprint (W860CU) Figure A - 2 Top without Fingerprint (W860CU) 壓克力 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 頭徑 頭厚 號 無鉛 無鉛 無鉛 (黑色) 無鉛 無鉛 無鉛 無鉛 頭厚 無鉛 無鉛 無鉛 無鉛 Ω 無鉛 無鉛...

  • Page 48: Bottom (W860Cu

    Part Lists Bottom (W860CU) 支鐵柱改為有"止滑溝"設計 無鉛 無鉛 凱碩 無鉛 亞旭 無鉛 無鉛 無鉛 無鉛)(增加GASKET) 相變化導熱片 無鉛 華力 無鉛 無鉛 無鉛 無鉛 Figure A - 3 無鉛 無鉛 無鉛 Bottom 惠貿 無鉛 無鉛)(PVT後設變修改) (W860CU) 無鉛 海華 無鉛 海華 無鉛 無鉛 惠貿 無鉛...

  • Page 49: Lcd (W860Cu

    Part Lists LCD (W860CU) Figure A - 4 (W860CU) 無鉛 無鉛 無鉛 銘板 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 非耐落 無鉛 惠貿 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 (改善品) 無鉛 無鉛 惠貿 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 (華力) 無鉛...

  • Page 50: Combo (W860Cu

    Part Lists COMBO (W860CU) Figure A - 5 COMBO (W860CU) 無鉛 無鉛 已內縮 無鉛 無鉛 *(非耐落) 無鉛 COMBO (W860CU) A - 7...

  • Page 51: Dvd-Dual Drive (W860Cu

    Part Lists DVD-Dual Drive (W860CU) Figure A - 6 DVD-Dual Drive (W860CU) 無鉛 無鉛 內縮 無鉛 無鉛 無鉛 *(非耐落) 無鉛 A - 8 DVD-Dual Drive (W860CU)

  • Page 52: Top With Fingerprint (W870Cu

    Part Lists Top with Fingerprint (W870CU) 無鉛 黑色 (無鉛) Figure A - 7 無鉛 無鉛 Top with 無鉛 無鉛 Fingerprint 導光 無鉛 無鉛 (無印刷) 無鉛 (W870CU) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Ω 無鉛 無鉛 無鉛 Ω...

  • Page 53: Top Without Fingerprint (W870Cu

    Part Lists Top without Fingerprint (W870CU) Figure A - 8 無鉛 Top without 黑色 (無鉛) 無鉛 Fingerprint 無鉛 無鉛 (W870CU) 無鉛 導光 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Ω 無鉛 無鉛 無鉛 Ω 無鉛 無鉛...

  • Page 54: Bottom (W870Cu

    Part Lists Bottom (W870CU) 無鉛 無鉛 無鉛 無鉛 凱碩 無鉛 亞旭 無鉛 無鉛 非耐落 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 海華 無鉛 Figure A - 9 無鉛 無鉛 無鉛 Bottom (加一缺口,不遮蔽 無鉛 相變化導熱片 無鉛 無鉛 (W870CU) (左旋) 無鉛...

  • Page 55: Lcd (W870Cu

    Part Lists LCD (W870CU) Figure A - 10 (W870CU) 無鉛 無鉛 無鉛 無鉛 壓克力 無鉛 壓克力 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 惠貿 無鉛 非耐落 無鉛 無鉛 無鉛 無鉛 惠貿 無鉛 無鉛 中性 電鑄薄膜鍍亮鉻(字體連結) 無鉛...

  • Page 56: 2Nd Hdd (W870Cu

    Part Lists 2nd HDD (W870CU) Figure A - 11 2nd HDD (W870CU) 無鉛 無鉛 無鉛 2nd HDD (W870CU) A - 13...

  • Page 57: Combo (W870Cu

    Part Lists COMBO (W870CU) Figure A - 12 COMBO (W870CU) 無鉛 無鉛 已內縮 無鉛 已內縮 無鉛 已內縮 無鉛 無鉛 無鉛 無鉛 A - 14 COMBO (W870CU)

  • Page 58: Dvd-Dual Drive (W870Cu

    Part Lists DVD-Dual Drive (W870CU) Figure A - 13 DVD-Dual Drive (W870CU) 無鉛 無鉛 內縮 無鉛 無鉛 無鉛 DVD-Dual Drive (W870CU) A - 15...
  • Page 59 Part Lists A - 16...

  • Page 60: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the W860CU/W870CU notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1 Schematic System Block Diagram - Page B - 2 Clock Generator - Page B - 21...

  • Page 61: Schematic Diagrams

    Schematic Diagrams System Block Diagram W870CU TOUCH SENSOR W860CU POWER BUTTON W86/870CU System Block Diagram BOARD BOARD 14 .31 8 M Hz W860CU LED BOARD VDD3,VDD5 Clock Generat or Me mory Termi natio n SLG8SP585V Clarksfield 1.1VS_VTT W860CU MULTI I/O BOARD 80 0/106 7/133 3 MHz DD R3 / 1.5V DDRIII...

  • Page 62: Processor 1/7

    Schematic Diagrams Processor 1/7 PROCESSOR ( DMI,PEG,FDI ) P E G _R X N [ 0 . . 1 5] P E G _R X P [ 0. . 15 ] P E G _ R X N [ 0 . . 1 5 ] 2 4 P E G_ R X P [ 0 .

  • Page 63: Processor 2/7

    Schematic Diagrams Processor 2/7 PROCESSOR ( CLK,MISC,JTAG ) Processor Compensation Signals U 3 4 B H _ C O MP 3 A T 23 DDR3 Compensation Signals C OM P 3 A 1 6 B C LK B C L K _C P U _ P 1 6 H _ C OM P 0 H _ C O MP 2 R 4 04...

  • Page 64: Processor 3/7

    Schematic Diagrams Processor 3/7 PROCESSOR ( DDR3 ) U34C U34D A A6 S A _CK [0] M _CLK _DD R0 9 A A7 M _A _DQ[63:0] S A _CK #[0] M _CLK _DD R#0 9 M _B _DQ [ 63:0] SB _CK [0] M _C LK_D DR2 10 SA _CK E [0]...

  • Page 65: Processor 4/7

    Schematic Diagrams Processor 4/7 PROCESSOR ( POWER ) U34F PR OCE SSOR CO RE P OWER PR OCES SOR UNC ORE POW ER 1.1V S_V T T VCO RE A G35 A H14 VC C1 VT T 0 _1 A G34 A H12 VC C2 VT T 0 _2...

  • Page 66: Processor 5/7

    Schematic Diagrams Processor 5/7 PROCESSOR ( GRAPHICS POWER ) U3 4G AT 21 V A X G1 V A X G_S E NS E AT 19 AR 22 R415 * 0_04 V A X G2 V AX G _S EN SE AT 18 AT 22 V S SA X G_ SE NS E...

  • Page 67: Processor 6/7

    Schematic Diagrams Processor 6/7 PROCESSOR ( GND ) U 34H U3 4I AT2 0 AE34 VS S1 VSS81 AT1 7 AE33 VS S2 VSS82 AR3 1 AE32 VS S3 VSS83 VSS16 1 AR2 8 AE31 VS S4 VSS84 VSS16 2 AR2 6 AE30 VS S5...

  • Page 68: Processor 7/7

    Schematic Diagrams Processor 7/7 PROCESSOR ( RESERVED ) R 319 * 0_04 D03C U3 4E A J13 AO 3402L RS V D32 V RE F _CH _A _DIM M A J12 M VR E F_D Q_D IM 0 RS V D33 PCI-Express Configuration Sele ct A P 25 R SV D1...

  • Page 69: Ddriii So-Dimm_0

    Schematic Diagrams DDRIII SO-DIMM_0 SO-DIMM A CHANGE TO STANDARD JD I M M1 A M _ A _A [ 15 : 0 ] M_ A _ A 0 M_ A _ D Q 0 M _A _ D Q[ 6 3 : 0 ] 4 D Q0 M_ A _ A 1 M_ A _ D Q 1...

  • Page 70: Ddriii So-Dimm_1

    Schematic Diagrams DDRIII SO-DIMM_1 SO-DIMM B CHANGE TO STANDARD JD I MM 2 B J D I MM 2A M _ B _ A [ 1 5: 0 ] M _ B _ D Q [ 63 : 0 ] 4 M _B _A 0 M _B _ D Q0 D Q 0...

  • Page 71: Ibexpeak - M 1/9

    Schematic Diagrams IBEXPEAK - M 1/9 R T C V C C IBEXPEAK - M (HDA,JTAG,SATA) 20m ils 20m ils V D D 3 C 2 1 2 1 u _ 6. 3 V _ Y 5 V _ 0 4 C 19 7 15 p _5 0 V _ N P O _ 04 D 1 9...
  • Page 72 Schematic Diagrams IBEXPEAK - M 2/9 3 . 3 V IBEXPEAK - M (PCI-E,SMBUS,CLK) P C I E C L K R Q 5 # R 4 7 0 1 0 K _0 4 P E G_ B _ C LK R Q # R 4 6 4 1 0 K _0 4 U 12 B...

  • Page 73: Ibexpeak - M 3/9

    Schematic Diagrams IBEXPEAK - M 3/9 IBEXPEAK - M (DMI,FDI,GPIO) A ub ur nda le G ra ph ic s Dis ab le G ui de li ne U 1 2 C I n ad dit io n, F DI _R XN _[7 :0 ] an d FD I_ RXP _[ 7: 0] c an b e l ef t B A 1 8 F D I _R X N 0 f lo at ing o n th e PC H.

  • Page 74: Ibexpeak - M 4/9

    Schematic Diagrams IBEXPEAK - M 4/9 IBEXPEAK - M (LVDS,DDI) U 1 2 D DDI Port B Detect T 4 8 B J 4 6 L _ B K L T E N S D V O _T V C L K I N N T 4 7 B G 46 L _ V D D _ E N...

  • Page 75: Ibexpeak - M 5/9

    Schematic Diagrams IBEXPEAK - M 5/9 IBEXPEAK - M (PCI,USB,NVRAM) DMI Termination Voltage U 12 E N V _C E [ 0 ] # Se t to Vs s wh en L OW H 4 0 A Y 9 NV_CLE A D 0 N V _C E # 0 N 3 4...

  • Page 76: Ibexpeak - M 6/9

    Schematic Diagrams IBEXPEAK - M 6/9 IBEXPEAK - M (GPIO,VSS_NCTF,RSVD) R11 8 1 0K_ 04 B M B U SY # U 12F 3.3V S B M B U SY # A H 45 B M B U SY # / G PIO 0 CLK OU T _P CIE 6N A H 46 C LK OUT _P C I E 6P...

  • Page 77: Ibexpeak - M 7/9

    Schematic Diagrams IBEXPEAK - M 7/9 IBEXPEAK - M (POWER) VCCA _DAC_1.2 3.3 V S 1.1V S POWER U12G HCB 1608 K F-121T25 1. 432A 69m A AB 2 4 A E50 V CCCORE [ 1] VC CADA C[1 ] AB 2 6 V CCCORE [ 2] C 6 18...

  • Page 78: Ibexpeak - M 8/9

    Schematic Diagrams IBEXPEAK - M 8/9 IBEXPEAK - M (POWER) PO WE R M L4 1 . 1 V S _ V C C A _ C L K U 1 2J 1 . 1 V S * H C B 10 0 5 K F -1 21 T 2 0 52mA A P 5 1 V 2 4...

  • Page 79: Ibexpeak - M 9/9

    Schematic Diagrams IBEXPEAK - M 9/9 U 12 I IBEXPEAK - M (GND) AY 7 H 49 VS S[ 15 9] V SS [ 2 59] B 11 VS S[ 16 0] V SS [ 2 60] B 15 J 24 VS S[ 16 1] V SS [ 2 61] B 19...

  • Page 80: Clock Generator

    Schematic Diagrams Clock Generator CLKGEN POWER CLOCK GENERATOR Sheet 20 of 57 C L K _ V C C 1 C L K _ V C C 2 C L K _ V C C 1 3 . 3V S Clock Generator V D D _ D OT V D D _ S R C _I / O...

  • Page 81: Panel, Inverter

    Schematic Diagrams Panel, Inverter LED PANEL L V D S _ D D C _ D A T 2 4 L V D S _ D D C _ C LK 2 4 J _L C D 1 3 . 3 V S S Y S 15 V S Y S 15 V N V _ LV D S -U C L K N...

  • Page 82: Dvi

    Schematic Diagrams 3 . 3 V S 5 V S 3 . 3 V S R 10 3 R 10 6 3 . 9K _ 0 4 3 . 9 K _ 04 D 1 2 D 13 D 14 B A V 9 9 D02 ? ? B A V 99 B A V 99...

  • Page 83: Hdmi

    Schematic Diagrams HDMI 3. 3V S 5 V S _ H D MI HDMI CONNECTOR D04 A DD R5 67,R 568 H D M I _C C L K # _ C 5 V S R 5 6 7 R 56 8 C 5 2 4 0.

  • Page 84: Mxm Pci-E

    Schematic Diagrams MXM PCI-E P W R _S R C P W R _ S R C MXM 3.0 J _ MX M1 A 5V S P J1 6 5 V R U N E 1 - 1 E 2 -1 O P E N -3 m m P W R _ S R C P W R _ S R C...

  • Page 85: Ec-It8502E

    Schematic Diagrams EC-IT8502E K B C _ A V D D L 2 6 H C B 1 0 05 K F - 1 2 1T 2 0 V D D 3 J _L E D 1 V D D 3 C 6 4 7 C 1 7 6 C 1 9 0...

  • Page 86: Usb, Esata, New Card

    Schematic Diagrams USB, eSATA, New Card U S B V C C 0 1 U S B V C C 0 1 _0 60 mil U S B _O C # 1 ML 1 H C B 3 2 1 6K F -8 0 0 T3 0 U S B _O C # 1 J E S A T A 1 C 1 2...

  • Page 87: Mini Card

    Schematic Diagrams Mini Card MINI-PCIE CARD For WLAN 20 mil 3 . 3 V 1 . 5 V S J_ W L A N 1 W LA N 1 . 5V S D02 B OM DE L P C I E _ W A K E # 1 .

  • Page 88: Bt, Tpm, Mdc, Lid

    Schematic Diagrams BT, TPM, MDC, LID 3 . 3 V S TPM 1.2 3 . 3 V D 02 TPM Function ? ? ? CLICK(M/B side) U 17 C 2 59 C 6 48 C 2 21 C 2 54 5V TP 1 1, 25 L P C _ A D 0...

  • Page 89: B - 30 Lan, Rtl8111L, Rj45

    Schematic Diagrams LAN, RTL8111L, RJ45 RTL8111DL F OR R TL81 02EL/ 8103 EL FO R RT L810 2EL/ 8103 EL ? ? ? 3 . 3V R 7 3 *0 _ 06 L A N _ V D D 3 mus t be wit hin H C B 1 6 08 K F -1 2 1 T2 5 mu st b e wi thin...

  • Page 90: Fan, Ccd, Led, Screw Hole

    Schematic Diagrams Fan, CCD, LED, Screw Hole CPU FAN CONTROL CASE FAN CONTROL 5 V S U 1 8 5V S U 1 5 R 2 0 8 * 10 K _ 0 4 F ON 3# F ON GN D R 1 6 9 * 10 K _ 0 4 F ON 1#...

  • Page 91: Azalia Codec Alc888

    Schematic Diagrams Azalia Codec ALC888 R 3 3 0 * 1 0m i l _ s h ort R 24 2 *1 0 mi l _ sh o rt C 3 09 0. 1u _ 10 V _ X 7R _ 04 3.

  • Page 92: Srs-Ap8202, Sata Odd & Hdd

    Schematic Diagrams SRS-AP8202, SATA ODD & HDD D0 2 SR S FU N CT I O N D I SA B L E R 2 6 3 * 10 m i l _ s ho rt Z 27 0 1 R 2 4 9 0 _ 04 LI N E _ OU T _ L...

  • Page 93: Amp-Tpa6017, Subwoofer

    Schematic Diagrams AMP-TPA6017, Subwoofer FRONT R/L 4ohm ? ? : 500~ 1000Hz ( ? ? ? ? ? ) 5 V S REAR R/L 1.5W 4ohm L 3 1 5V S ? ? : 2000Hz ? ? (? ? ? ? ) D03B C249 ,C25 3,C234,C23 9 5 V S _ A MP H C B 1 0 0 5K F -12 1 T 20...

  • Page 94: 3.3V, 3.3Vs, 5Vs, 1.5Vs

    Schematic Diagrams 5V, 3.3V, 3.3VS, 5VS, 1.5VS P D 16 S C S35 5V S YS 5V V IN1 V DD3 V IN PM O S 150mA P D 15 P R8 8 S C S35 5V P C 156 P Q5 0 A O3 409 10 K_0 4...

  • Page 95: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 P C 1 2 2 S Y S 5 V 0 . 0 1 u_ 5 0 V _ X 7 R _ 0 4 L GA T E 1 Z 3 6 1 3 P D 8 F M0 5 4 0 -N S Y S 1 0 V V I N 1...

  • Page 96: Power 1.8Vs, 1.1Vs

    Schematic Diagrams Power 1.8VS, 1.1VS V I N P R 54 E N _ 1 . 1V M P D 1 1 0 0 K _ 1% _ 0 4 P C 15 0 P C 1 4 9 P C 1 5 1 P Q 4 P C 2 7 F M 0 54 0 -N...

  • Page 97: Power 1.5V/0.75V

    Schematic Diagrams Power 1.5V/0.75V V I N 3 . 3V V D D Q P R 10 3 P R 1 0 6 P D 5 P R 1 12 1 . 5 M_ 0 4 1 0_ 0 6 1 0 0 K _0 4 F M0 5 4 0 -N P U 7...

  • Page 98: Power 1.1Vs_Vtt

    Schematic Diagrams Power 1.1VS_VTT CONTROL 1.1VS_VTT H_V TTVID 1 = LOW, 1.1 V H_V TTVID 1 = HIGH, 1.0 5V H _VT TVID1 +1.05V +1.1V 3 . 3V P R 58 3 . 3 V 1 0 K _0 4 P R 52 V I N P R 4 7...

  • Page 99: Power Vcore

    Schematic Diagrams Power VCore C S _ P H 1 P R 17 9 1 2 4K _ 0 6 C S _ P H 2 P R 18 0 1 2 4K _ 0 6 S G N D 2 V I N P R 1 8 1 1 K _ 04 V I N...

  • Page 100: Ac_In, Charger

    Schematic Diagrams AC_In, Charger P R 9 4 P Q5 7 P 20 0 3E V G P 20 0 3 E V G 0 _ 0 4 V I N Ch ar ge Cu rr ent 3 .0A P Q3 6 P Q 22 6- 2 0 - B3 4 9 0- 1 0 3 P 2 0 03 E V G...

  • Page 101: Usb 3.0

    Schematic Diagrams USB 3.0 3 . 3V 3 . 3V A 1. 0 V 3. 3 VA L3 7 C 31 5 H C B 16 08 K F -12 1T 25 C 35 7 C 3 66 C 3 28 0 .

  • Page 102: Power Button Board

    Schematic Diagrams Power Button Board FOR POWER SWITCH BOARD B_5VS POWER BJ_PWR1 BSW1 BUTTON BJ_PWR1 B_BTN# B_BTN# TJG-533-S-T/ R 88266-03001 BDGND PIN5,6=BDG ND 6-20-63130-103 BDGND Sheet 42 of 57 Power Button B_5VS Board POWER BR 1 BUTTON 1K_06 680_06 D02 BOM change Z 3901 Blue LED BD 1...

  • Page 103: Led Board

    Schematic Diagrams LED Board LS_ 3. 3VS L S_3.3 VS WLAN / BT LED LSJL ED 1 LS_SATA_L ED# L S_3.3VS LS_ 3. 3VS LS_3 .3VS L SR5 LSR 6 LS_L ED_ WL AN LS_L ED_ BT_EN 150 _0 4 15 0_ 04 LSR 3 L SR2...

  • Page 104: Multi I/O Board

    Schematic Diagrams Multi I/O Board IEEE1394 S V C C _ C A R D S R 5 1 0 K _ 0 4 S S D W P S 13 9 4 _T P B I A S 0 S C 2 2 0 .

  • Page 105: Touch Sensor Board

    Schematic Diagrams Touch Sensor Board S R J _ L E D 1 S R U 1 S R J _ LE D 2 S R _ S A T A _L E D # S R _S A T A _ L E D # S R _ L E D _ W L A N S 19 S R _ L E D _ B T _ E N...

  • Page 106: Left-Led Board

    Schematic Diagrams Left-LED Board K_5V S K_5VS KJ_PW R1 KJ_ PWR1 KR 2 680_06 68 0_06 88266-03 001 Sheet 46 of 57 Left- LED Board K DGND KD 2 HT-150N B-DT H T-150NB- DT KDGND KH 1 C5 1D51N Left-LED Board B - 47...

  • Page 107: Fingerprint Board

    Schematic Diagrams Fingerprint Board FP J T1 F R EG_ OU T F R EF_ OS C FP U 1 F BD R I VE 1 F U SB_ C ON N F BD R I VE 2 FAV D D U SB _C ON N E CT F BE ZEL1 F BD R I VE1...

  • Page 108: Click Board

    Schematic Diagrams Click Board T 3 . 3 V T +5 V S T C 1 *0 . 1 u _1 6 V _ 04 T + 5 V S T R 1 * 10 m i l _ s h or t T J _ TP B 1 Z 4 0 0 1 T R 2 6...

  • Page 109: W870Cu Second Hdd Board

    Schematic Diagrams W870CU Second HDD Board OJ_ODD1 O J _SAT A1 OSATA_TX P0 OSATA_TX N0 O SATA_TX P0 O SATA_TX N0 OSATA_RXN0 HSATA_TX P0 OSATA_RXP0 HSATA_TX N0 O SATA_RXN0 O SATA_RXP0 HSATA_RX N0 HSATA_RX P0 O GND EODD_EDTECT# O_5VS EO DD_EDTECT# O_5VS O _3.3VS C18512- 100B...

  • Page 110: W870Cu Multi I/O Board

    Schematic Diagrams W870CU Multi I/O Board IEEE1394 W V C C _C A R D W R 6 1 0 K _0 4 W S D W P W 1 39 4 _ TP B I A S 0 W C 2 2 0 .

  • Page 111: W870Cu Cir Board

    Schematic Diagrams W870CU CIR Board V_VDD5 V_VDD5 VJ_CIR1 FOR W87 Sheet 51 of 57 V_CIR_RX 100_1%_04 W870CU CIR Board IR5V 88287-04001 6-21-94A50-104 VGND GND1 GND1 0.1u_16V_Y5V_04 *4.7u_25V_08 10u_10V_Y5V_08 GND2 GND2 VGND IRM-V038/T R1-P VGND VG ND V_CIR_RX H6_0D3_0 H6_0D3_0 H6_0D2_2 H6_0D2_2 VGND VGND...

  • Page 112: W870Cu Led Board

    Schematic Diagrams W870CU LED Board L _3. 3VS L _3. 3VS WLAN / B T LED NJ L ED1 L _SA TA_ LED # L _3 .3VS L _3. 3VS L_ 3 .3VS NR 5 N R6 L _L ED _W LAN L _L ED _BT_EN 1 50_04 1 50 _0 4...

  • Page 113: W870Cu Rj11 & Tv Board

    Schematic Diagrams W870CU RJ11 & TV Board TV ANTENNA M5 70u CON Sheet 53 of 57 HJANT2 HJMO DEM1 W870CU RJ11 & TV HJ_RJ1 C10171-10204-Y HJ ANT1 HG ND HTIP HCB1608KF-121T25 6-21-B4P30-102 HRING HCB1608KF-121T25 RING Board Z3644 85205-02701 FR-005D 6-20-41100-002 20279-001E-01 6-21-B4010-104 6-20-H1000-103...

  • Page 114: W870Cu Power Button Board

    Schematic Diagrams W870CU Power Button Board FOR POWER SWITCH BOARD Y _5VS POWER YJ_ PWR 1 YSW 1 PJ _PWR1 BOTTOM P_BTN # P_BTN # TJG -533- S-T/ R YD G N D PIN5,6=BDGND 88 266-0 3001 D02A Y DG N D 6-20-63130-103 Sheet 54 of 57 W870CU Power...

  • Page 115: W870Cu Right-Logo Board

    Schematic Diagrams W870CU Right-Logo Board R_5 VS R_5VS RJ_P WR1 Sheet 55 of 57 W870CU Right- RLR1 Logo Board 680_06 88266-0 400 6-20-63110-104 R DGND HT-SV1 16BP White LED RDGN D B - 56 W870CU Right-Logo Board...

  • Page 116: W870Cu Left-Logo Board

    Schematic Diagrams W870CU Left-Logo Board L_5V S L_5VS LJ_P WR1 Sheet 56 of 57 W870CU Left-Logo Board 680_06 88266-0 400 6-20-63110-104 L DGND HT-SV1 16BP White LED LDGN D W870CU Left-Logo Board B - 57...

  • Page 117: W870Cu Touch Sensor Board

    Schematic Diagrams W870CU Touch Sensor Board H K J_ L E D 2 H K _ S A T A _ L E D # H K J _ L E D 1 H K U 1 H K _ S A T A _L E D # H K _ L E D _ W L A N S 19 H K _ L E D _ C A P #...

This manual is also suitable for:

W870cu

Table of Contents
