System Specifications - EUROCOM W860CU Service Manual

Introduction

System Specifications

Processor
Intel® Core i7-820QM Processor:
1.73GHz
45nm (45 Nanometer) Process Technology,
8M L3 Cache &
FSB 1333MHz - TDP 45W
rPGA988A Package
Intel® Core i7-720QM Processor:
1.6GHz
45nm (45 Nanometer) Process Technology,
6M L3 Cache &
FSB 1333MHz - TDP 45W
rPGA988A Package
For W870CU Only:
Intel® Core i7-920XM Processor:
2.00GHz
45nm (45 Nanometer) Process Technology,
8M L3 Cache & FSB 1333MHz - TDP 55W
rPGA988A Package
Core Logic
Intel® PM55 Chipset
Display
W860CU
15.6" HD (1366 * 768) / HD+(1600 * 900) /
FHD (1920 * 1080) 16:9 Wide Screen LED
Panel
W870CU
17.3" HD+(1600 * 900) / FHD (1920 * 1080)
16:9 Wide Screen LED Backlit Panel
1 - 2 System Specifications
Memory
Two 64-bit Wide DDRIII (DDR3) Data
Channels
Two 204 Pin SO-DIMM Sockets Supporting
DDRIII (DDR3) 1333MHz
Memory Expandable up to 4GB Using 2GB
DDRIII Modules
Video Adapter
For W860CU & W870CU Computers:
nVIDIA® GeForce GTX 280M PCIe * 16 Video
Card
1GB GDDR3 Video RAM on board
Supports Microsoft DirectX ® 10
Supports HDCP
For W860CU only:
nVIDIA® GeForce GTX 260M PCIe * 16 Video
Card
1GB GDDR3 Video RAM on board
Supports Microsoft DirectX ® 10
Supports HDCP
BIOS
One 32Mb SPI Flash ROM
Phoenix™ BIOS
Keyboard & Pointing Device
Full Size WinKey Keyboard
Built-in TouchPad with Multi Gesture Function
Three Instant Keys (WWW, E-Mail, Silent
Mode)
Storage
One Changeable 12.7mm(h) Optical Device
(CD/DVD) Type Drive (see Factory Options
for All Models on page 1-3)
For W860CU
Easy Changeable 2.5" 9.5 mm (h) SATA
(Serial) HDD
For W870CU
Easy Changeable 2.5" 9.5 mm (h) SATA
(Serial) HDD (RAID 0/1 Support)
Card Reader
Embedded 7-in-1 Card Reader (MS/ MS Pro/
SD/ Mini SD/ MMC/ RS MMC/ MS Duo) Note:
MS Duo/ Mini SD/ RS MMC Cards require a
PC adapter
Slots
One ExpressCard/34/54 Slot
Two Mini-Card Slots (USB/PCIe):
Slot 1 for Half Mini-Card WLAN Module with
PCIe Interface (Factory Option)
For W860CU
Slot 2 for UMTS/HSPA 3.75G Module with
USB Interface (Factory Option)
For W870CU
Slot 2 for TV Tuner Card with USB Interface
(Factory Option)
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Fingerprint Reader Module (Factory Option)
