The Monitor Setup key opens the Monitor Touchscreen, which controls the source for
each Studio feed. Each Studio feed has its own tab (Monitor A–D), and each tab lists
the possible sources (External Input, Main, and Aux busses). To select a source for a
Studio bus, touch the tab of the desired bus then touch the source to assign; source se-
lections intercancel.
11.2.4

Talkback

Once the Talkback bus is set up (see page 93), pressing the MC's Talkback button au-
tomatically dims all output bus levels and routes the Talkback bus output to all output
busses with TE enabled in the Nuendo Control Room Mixer (green when enabled). To
utilize the MC's built-in talkback mic, connect the XLR talkback mic output on the rear
panel to an input on your Nuendo workstation's hardware (ASIO sound card), then select
that input as the source for the Talkback bus (Device Port in the Studio tab of the VST
Devices window). The MC's built-in talkback mic is a condenser microphone and re-
quires 48-V phantom power.
NOTE: The rear panel Foot Switch jack can be used to toggle Talkback on/off (see
page 16).
11.2.5

Nuendo-Specific MC Controls

This section discusses MC controls that have a unique function within Nuendo.
Soft Keys
Soft Keys may be programmed with three Nuendo-specific commands by selecting MC
type commands.
• Parameter Collect: Stores automation data into the MC's internal memory
buffer for punching into Nuendo's automation system at specified locations.
• Parameter Punch: Transmits automation data collected into the MC's internal
memory.
• Read/Write All Automation: Used in conjunction with Parameter Collect and
Parameter Punch to isolate automation system from automation being collected
into the MC's internal memory buffer.
Multiple Track Selection
Multiple track selection from the surface depends on the Track Selection mode pref-
erence found on the General Preferences page. Track Selection mode can be set to In-
tercancel or Sum.
• Intercancel: Multiple track selection from the surface is not possible.
• Sum: Multiple track selection is accomplished by pressing Chan Select either
from the MC Touchscreen or on the channel strips. De-select a selected track
by pressing Chan Select again.
