Main-Flip (System 5-MC Only)

A row of the CM408T module's knobs can be flipped onto its faders. The parameters
on the row of knobs appear on the faders and the parameters on the faders appear on the
row of knobs. Flip works across the entire console surface.
The Main-Flip Touchscreen shows eight buttons corresponding to the CM408T's eight
rows of knobs.
1. Touch a number once to flip that row.
The button stays lit while the row is flipped.
2. Touch a highlighted number to flip it back to normal.
The button extinguishes to show the row is no longer flipped.
The Flip buttons intercancel: Touch a new Flip button while a row is flipped to cancel
the first flip and flip the new row.
Figure 3-2 Main-Flip Touchscreen
