Euphonix Media Application Controller Operation Manual
9.8
Configuring SME Talkback
To configure SME Talkback:
1. Connect the MC Talkback Mic to a microphone preamp with 48V phantom
power (required).
2.
Connect the mic preamp's output to any input on your sound card.
3.
In the Config tab, enable the input that you connected the preamp to on your
sound card.
4.
In the Config tab Talkback section, Set the desired Level, Destination and
Action.
5. In the Hardware I/P Patch tab, route the Hardware Input to SME I/P "TB",
which appears at the bottom of the pull-down list (after channel 32).
Studio Monitor Express (Windows)
81
