Euphonix Media Application Controller Operation Manual
7.4
CM408T Channel Strips (System 5-MC only)
The CM408T channel strip is similar to the strip on the standalone MC with faders, but
also have a four-character LED scribble strip display, and a high-resolution TFT display
to show additional channel information, metering, pan, and EQ graphs.
The CM408T channel strip has the following attributes:
NOTE: Press and hold the strip's left-top button then press the right button to navigate
back (up) one level.
See Channel Strips on page 59 for an explanation of these features.
All Key
Page L
Insert Master
Dyn Master
EQ Master
Chan Select Key
Main Layer Display
Record Key
Input Monitor
Auto Mode LEDs
Wave Key
Signal Meter
Figure 7-6 CM408T channel strip
68
Working with Channels
Back Buttons
Soft Knobs
Page R
Knobsets
Swap Key
Swap Layer Display
Solo Key
On Key
Auto Write Toggle
Touch LED
Fader
