Euphonix Media Application Controller Operation Manual
7.1.2 On
The On key must be lit (active) to hear the channel. The channel is muted when the
strip's On button is unlit.
7.1.3

Record

Activate the Record key to enable (arm) a track for recording.
7.1.4

Chan Select Key

Press the Chan Select key to select the channel assigned to that strip. When lit, this
channel is selected in the DAW for editing.
Press the Chan Select key to select a workstation track; it lights when a track is selected.
The workstation's tracks or mixer window scrolls to show the most recently selected
track.
7.1.5

Select Key

When pressed by itself, the Select key toggles Write mode on/off for the entire track.
LEDs
The green R and red W LEDs are used to denote the automation modes shown in Table
7-1. To set the automation mode, press and hold the Wave key and press the Select key
to select from the popup menu. In Write mode, the red W LED blinks when writing au-
tomation and is solid otherwise.
Isolate
Read
Write
Read + Write
In Write mode, the red LED blinks when writing automation, and lights solid when the
transport is stopped.
NOTE: The yellow G LED is reserved for future use.
Table 7-1 Automation Modes
Mode R LED (green)
off
on
off
on
W LED (red)
off
off
on
on
60
Working with Channels
