4 To specify where the label is placed relative to the curve, select one of the following options:
Offset option
Auto-Adjust for 2 Line
Auto-Adjust for 1 Line
Force Outside of Bounding Box
None
5 If desired, enter a value for Clear Distance Paper Offset.
When labels have a clear distance paper offset and Auto-Adjust for 2 Line is specified, the offset
is calculated from the outer edge of the curve to the bottom of the text.
When Labels have a clear distance paper offset and Auto-Adjust for 1 Line is specified, the offset
is calculated from the centerline of the curve to the bottom of the text.

Labels

You can annotate objects with labels that consist of text or block definitions. The information in the label
comes from object properties, such as connection size. Labels anchor to objects, yet you can still move a
label without releasing it from its object. It is recommended that you add labels to construct drawings.
Adding Labels
For information on adding labels, see
to Pipe on page 317. In addition to duct and pipe, you can add labels to plumbing lines, wires, cable tray,
conduit, and schematic lines.
Modifying Labels
For more information on modifying labels on pipe objects, see
332.
Changing the Label Style
You can change the label style for an existing label in a drawing. For example, you can change a standard
size label to a system label.
1 Double-click a label to open the Properties palette.
NOTE Alternatively, select a label and then click Home tab
drop-down
2 On the Design tab, expand General under Basic.
3 Choose a label style for Style.
Description
Use this option to adjust the label display for objects using a 2-line
display configuration.
Use this option to adjust the label display for objects using a 1-line
display configuration.
Use this option to display the label above the curve.
Use this option when you want to insert the label at the specified
point.
Adding a Label to a Duct
Properties .
on page 218 and Adding Labels or Flow Arrows
Modifying a Label or Flow Arrow
Build panel Tools
on page
Annotation | 559
