Watch a demo
Lay Out a System
Draw Duct
Size Duct
Make changes to a duct system
Label system components and
generate schedules
Refine a Duct System

Flow Annotation

You can access flow annotation information for air terminals from the Flow Annotation tab in the Equipment
Properties dialog. You can specify up to 8 locations to place flow arrows around the air terminal. You can
select the block for the flow arrow, and you have the option of using the same block for all flow arrows or
selecting different blocks based on location. You can specify the rotation angle and the offset from the air
terminal for each flow arrow, and you can specify a flow value. The Flow Annotation tab is available only
after the air terminal has been added to the drawing.
View more information
Place diffusers, VAV boxes, coils, dampers, and
-----
other equipment by Adding HVAC Equipment
page 194
Connect the equipment using duct runs by
-----
Adding Duct on page 196
Verify flow values and calculate duct to properly
-----
size components by Calculating Duct Sizes for a
Duct System on page 203
Modify system layouts based on design changes,
-----
and recalculate sizes as necessary by
a Duct System on page 219
As you design, annotate systems for preliminary
design specifications and subsequent construction
-----
documents by Annotating a Duct System
218
Associative movement lets you modify and move
duct and equipment to accommodate design
-----
changes without breaking connections. See
Associative Movement on page 219
on
Modifying
on page
About
Flow Annotation | 165
