4 Click OK twice.

Attaching Notes and Files to a Style

General style properties include name, description, and notes. You can use general style properties to assign
property set information
1 Select an object in your drawing, and then choose one of the following procedures:
2 In the Styles dialog, click the General tab.
3 Enter a name and description.
4 Click Notes.
5 In the Notes dialog, click the Notes tab, and enter the note text.
If you want to...
change style-specific display settings
to objects such as MvParts, which typically have associated schedules.
Click the object's contextual ribbon tab
NOTE The General Panel shows an Edit System Style drop-down menu for some objects, which
you can then open to choose from several Edit Style commands.
Right-click and click the Edit Style command from the context menu.
NOTE The name is predefined by the object and should be modified with caution. Avoid duplicate
names to prevent confusion.
To select all notes, click Select All. You can use the context menu to access the standard
®
Windows cut, copy, paste, and delete commands for selected text.
then...
select the display representation, click Edit Display
Properties, and then click the Other tab to make
changes. The Other tab is displayed only in some
display representations.
General Panel Edit Style command.
Attaching Notes and Files to a Style | 611
