To save a parametric MvPart
2 On the toolbar, click
3 Specify whether to make the part available in the catalog:
To preview a parametric MvPart
4 To preview each part size, in the part browser, right-click Size Parameters and click Edit Values.
5 Click a row in the table to select the default part size.
6 Click
734 | Chapter 14 Customizing Catalog-Based Content
If you have errors in your model, the traffic light is red and a dialog is displayed listing the
errors. Review the errors, make necessary modifications and repeat this step until validation is
successful.
NOTE Warnings in the Part Family Validation Results dialog do not make the part invalid.
Once validation is successful, you can save the parametric MvPart.
Click Yes to make the part available to users.
Click No to keep the part hidden.
NOTE This prompt toggles the Hide Part option in the Options dialog in Content Builder.
The part is saved in the specified catalog location.
The Size Parameters dialog is displayed.
.
The Parametric Object Viewer is displayed.
Parametric Object Viewer dialog
.
