2 Verify that the viewport in which the object will display is on.
3 If you are using
Under certain circumstances, the Display Manager can assist you in troubleshooting object display problems.
Check the display configurations to:
Identify the display set applied to the viewport
Verify that a display representation is selected in that display set
View the display properties to confirm that the components are turned on

AutoCAD MEP Templates

Once you establish project standards, you can create custom templates that are unique to your project. You
can create a custom template in several ways:
(Recommended) Modify an existing template.
Save a drawing as a template.
Create the template from scratch.
RELATED See "Use a Template File to Start a Drawing" in the AutoCAD Help.

Default Drawing Templates

Drawing templates store default preferences, controls, and content common to all drawings in a project.
You can start on a project immediately by using a template. This saves time and provides consistency when
creating multiple drawings.
AutoCAD MEP includes several default templates in metric or imperial units. Most notably:
Aecb Model, a template for designing building systems
Aecb Sheet, a template for plotting building systems
The templates have specified drawing units, drawing scales, and annotation size. They also have defined
layout tabs,
model space and paper
Using default templates helps you become more familiar with the software to create new drawings and
incorporate them into your project standards. Later, you can modify the default templates or create your
own to meet specific company or project requirements.
Perform the action associated with one of the following components:
Layer structures
1 Click Home tab
2 Click Layer Standards
3 Click Import/Export. For more information, see Importing Layer Standards in the AutoCAD Architecture
Help.
156 | Chapter 5 Working with Projects
referenced drawings
configuration.
display representations, and plotting setups, which serve as a guide to the recommended use of
space.
Layers panel
.
(xrefs), confirm the method of attachment and the xref
Layer Properties .
