2 In the Label Style dialog, click the General tab.
3 Specify the desired information, and click OK.
Changing Label Style Annotation Properties
You can use the options on the Label Style Annotation tab to specify how the object information is displayed
in the label.
To set label style annotation properties
1 Select a label, and click Label tab
2 In the Label Style dialog, click the Label Style Annotation tab.
3 From the Options list, select one of the following options:
556 | Chapter 12 Creating Construction Documents
NOTE The name should be modified with caution. Avoid duplicate names to prevent confusion.
Option
Use Block graphics
Use Objects Properties
General panel Edit Style
Description
Use a specific block. You can also specify a scale factor to apply to
the block.
If you want the block to scale accordingly when the annotation
scale changes, select Use Annotation Scale for Block.
NOTE The Use Annotation Scale for Block setting, not the
Annotative property in the selected block definition, determ-
ines whether the label curve style is annotative. For more
information, see Scaling Annotation
The properties displayed in the label are different for different
objects in AutoCAD MEP. The ID is displayed for schematic sym-
bols, the designation is displayed for schematic lines, and the
properties of the closest connector are displayed for MvParts.
.
on page 549.
