For information on adding custom data to parts using Catalog Editor, see
to Parts in Catalog Editor
Content Builder, see Sizes of a Parametric Part
to a Block-Based MvPart
2 Depending on the type of part, do one of the following:
If the part is parametric, in the part browser, right-click Size Parameters, and click Edit
Configuration. Then, in the Size Parameters dialog, click
If the part is block-based, in the MvPart Builder dialog, click the Properties tab, and click
Edit Properties. Then, in the Property Editor dialog, click
The Save a Custom Parameter Group dialog is displayed. It lists all of the custom parameters
that have been added to the part that is currently open.
Save a Custom Parameter Group dialog
3 Specify the parameters to save as a group:
If you want to...
save a custom parameter
save the current value for a custom paramet-
er
not save the value for a custom parameter
4 For File name, specify the file name and location of the XLS file in which to save the group of
custom parameters.
NOTE The file is saved in a default MEP Parameter Groups subfolder. However, you can optionall
ybrowse to a different folder location, such as a project-specific folder.
If you specify the file name and location of an existing file, the custom parameters in the file
are overwritten with your current selections.
on page 778. For information on adding custom data to parts using
on page 667 or
on page 763.
then...
Select Save in Group for that parameter. You can also click Select
All to save all of the custom parameters in the group.
Select Yes for Save Value(s) for that parameter. This saves the
value for the part that is currently open.
Select No for Save Value(s) for that parameter.
Saving Custom Parameters in Groups | 767
Adding Custom Data
Adding Property Set Information
(Save Custom Parameter Group).
(Save Custom Parameter Group).
