Kyocera TASKalfa 3050ci Operation Manual page 519

Cassette 6,7 (Option)
If a paper jam occurs in cassette 6 or 7 when you are using the optional side feeder (500-sheet x 3) or large
capacity side feeder (500, 1,500-sheet x 2), follow the steps below to remove the jam.
Side Feeder (500-sheet x3)
5
Pull out cassette 5.
6
Remove the jammed paper.
7
Push the cassette back in place securely.
8
Close the top cover and right cover 1.
9
Connect to the multifunction machine.
1
Pull up the release lever and separate the side
feeder from the multifunction machine.
2
Follow steps 2 to 5 on page 12-50 to remove the
jammed paper.
12-51
Troubleshooting
12
